Installation Guide
Model: LH1000
Lock Body: American Standard Mortise with 5 Latches
Version: 1.0
Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency
betweenthe actual product and the written information in this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LH1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKTeco LH1000

  • Page 1 Installation Guide Model: LH1000 Lock Body: American Standard Mortise with 5 Latches Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency betweenthe actual product and the written information in this manual.
  • Page 2 Precautions Please read this Installation Guide carefully or contact the Customer Care for any queries regarding installation. Installation is recommended to be performed by a professional to avoid any additional service charges that may cause due to improper product installation. A new lock is always in open mode until it is unlocked once by a RFID S50/S70 IC Card (13.56Mhz).
  • Page 3: Table Of Contents

    Table of Contents What's in the Box......................1 Installation Diagram.......................2 Installation Procedure....................2 1. Door Opening Direction.....................2 2. Drill Holes on the Door........................3 3. Install the Mortise.............................3 4. Install Outdoor Unit..........................4 5. Install Strike Plate and Box.......................6 6. Test the Lock by Mechanical Key......................6...
  • Page 4: What's In The Box

    What's in the Box Outdoor Unit Indoor Unit Cylinder Battery Box Mortise Spindle B Strike Plate and Box Keys Vacuum Sucker Hex Wrench Spindle A Screw A Screw B Screw C Screw D Spindle A Screw C Door Thickness Spindle B 35 mm to 54 mm 40 mm 55 mm...
  • Page 5: Installation Diagram

    Installation Diagram Battery Box Spindle A Battery Cylinder Cylinder Cover Outdoor Unit Screw C Spindle A Spindle B Mortise Door Screw A Indoor Unit Strike Plate and Box Installation Procedure Door Opening Direction The handle position is determined by the swing (opening) direction of the door. Below is the graphical representation of handle in reference to your location outside the room.
  • Page 6: Drill Holes On The Door

    Drill Holes on the Door Place the Installation template on the door at the desired handle height. Mark the holes to be drilled and drill the marked places. Center line of handle Install the Mortise Keep the two triangles on the clutch facing each other and then secure the mortise with screw A.
  • Page 7: Install Outdoor Unit

    Secure the cylinder with screw B by hex wrench. Make sure the cylinder is facing towards the outdoor unit. Insert the spindle A into the clutch facing towards outdoor unit and make sure the two triangles are horizontal and facing each other. Screw B Hex Wrench Spindle A...
  • Page 8 Insert the rest spindles into the mortise forward indoor unit. Secure the lower section of the outdoor unit with screw C. Spindle B Spindle A Screw C Connect the battery box cable and insert four Alkaline AA batteries. Then, insert the battery box into the indoor unit.
  • Page 9: Install Strike Plate And Box

    Install Strike Plate and Box Make sure that the strike box is aligned with the latch bolt. Then, use the Installation template to drill holes. Align the strike plate and box with the drilled holes and secure them with screw A. Screw A 25 mm Test the Lock by Mechanical Key...
  • Page 10 Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 11 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2024 ZKTECO CO., LTD. All Rights Reserved.
