Fingerprint Lock User Manual
Version: 1.0
Date: April 2010
About This Manual
This manual introduces the fingerprint lock interface and menu operations. For the
fingerprint lock installation, see the animated installation instructions.
Our products are subject to update from time to time, so our
company will neither make a commitment to guarantee the
consistency between the actual products and this document, nor
assume any responsibility for any dispute arising out of the
discrepancy between the actual technical parameters and this
manual. This document is subject to change without prior notice.

Advertisement

Table of Contents
loading

Related Manuals for ZKTeco L5000

Summary of Contents for ZKTeco L5000

  • Page 1 Fingerprint Lock User Manual Version: 1.0 Date: April 2010 About This Manual This manual introduces the fingerprint lock interface and menu operations. For the fingerprint lock installation, see the animated installation instructions. Our products are subject to update from time to time, so our company will neither make a commitment to guarantee the consistency between the actual products and this document, nor assume any responsibility for any dispute arising out of the...

  • Page 2: Table Of Contents

    Table of Contents 1 Instruction for Use.................. 1 1.1 Introduction to Fingerprint Lock Functions ........1 1.2 List of Installation Accessories............2 1.3 Installation Requirements ..............4 1.4 Front and Rear Views ..............7 1.5 Precautions..................10 1.6 User Privileges ................11 1.7 Set Time..................
  • Page 3 3.2 Language Settings ................. 34 3.3 FP Card Password................35 3.4 Advanced Settings ................. 35 3.5 Browse System Information............36 3.6 Browse Logs ................. 37 3.7 USB Pen Drive Management ............38 4. Conventions on Other Functions ............41 4.1 Routine Operation Indications............

  • Page 4: Instruction For Use

    Fingerprint Lock User Manual V1.0 1 Instruction for Use Functions marked with “★” in this manual are only supported by a specific product or a tailor-made product and will be described below. 1.1 Introduction to Fingerprint Lock Functions By leveraging the perfect combination of biometrics and cryptography, our fingerprint locks ensure double security through the fingerprint + password unlocking feature.

  • Page 5: List Of Installation Accessories

    Fingerprint Lock User Manual V1.0 Feature an electric clutch handle design which helps effectively prevent the fingerprint lock failure caused by damage to the internal structure as a result of the forced destruction of the handle. 1.2 List of Installation Accessories...
  • Page 6 Fingerprint Lock User Manual V1.0 List of Installation Accessories Name Quantity Unit Remarks Front panel assembly Lock cylinder Square shaft of handle Lock body Battery cover Four pieces of alkaline AA Batteries batteries Rear panel assembly Reserve two screws and Screw select proper screw size based on the door thickness...

  • Page 7: Installation Requirements

    Fingerprint Lock User Manual V1.0 1.3 Installation Requirements Precautions: The fingerprint lock is applicable to doors of 35–50 mm in thickness. Be sure to list your special requirements or remarks for fingerprint locks to be installed on doors in excess of 50 mm in thickness before placing an order. The gap between the lock body and the box keep cannot exceed 4 mm;...
  • Page 8 Fingerprint Lock User Manual V1.0 Ensure the central point of the handle is about 1m above the floor. Ensure the marker dot of clutch is right above the clutch.
  • Page 9 Fingerprint Lock User Manual V1.0 Marker dot is right above the clutch Please follow the animated instructions to install fingerprint locks. Recommended Tools You may need the following tools while following the instructions to install fingerprint locks:  A ruler. ...

  • Page 10: Front And Rear Views

    Fingerprint Lock User Manual V1.0 1.4 Front and Rear Views Front view...
  • Page 11 Fingerprint Lock User Manual V1.0 Rear view Battery Battery cover USB interface Band switch Handle ESC key: Press this key to exit current operation and press and hold this key to power off the fingerprint lock. ESC key doubles as the number key “1”.
  • Page 12 Fingerprint Lock User Manual V1.0  key: This key is used to manually decrease (when held, this key will rapidly decrease display values) the setup value or navigate among menu options.  key doubles as the number key “3”. Start key: This key can be used to start the fingerprint lock;...

  • Page 13: Precautions

    Fingerprint Lock User Manual V1.0  Note: When you cannot power off the fingerprint lock due to the exception of program, press and hold the ESC key to power off and then restart the fingerprint lock. It is not recommended to power off the fingerprint lock by pressing and holding the ESC key when the fingerprint lock operates normally.

  • Page 14: User Privileges

    Fingerprint Lock User Manual V1.0 When installing a fingerprint lock, connect the plug to the socket properly. Improper connection may lead to fingerprint lock failure. 1.6 User Privileges The user privileges are classified into three types: Super administrators, administrators and ordinary users. Super administrators: refer to users who have access to all system functions and modify all system settings.
  • Page 15 Fingerprint Lock User Manual V1.0 ↓ Menu 2) Press and hold the Menu key for three seconds to User Manage access the menu interface. Press ▼ to select ►Options “Options” and press OK to display the setting PenDrive Mng interface. Options 3) Press ▼...

  • Page 16: Enrollment And Verification

    Fingerprint Lock User Manual V1.0 2. Enrollment and Verification 2.1 Enroll an Administrator If the fingerprint lock has no administrator, you must at least enroll one administrator before enrolling ordinary users. To enroll an administrator, proceed as follows: 2009-11-24 1) Power on the fingerprint lock by pressing the Start key to open up the initial interface.

  • Page 17: Enroll A Fingerprint

    Fingerprint Lock User Manual V1.0 2.1.1 Enroll a Fingerprint ↓ Enroll Admin ► Enroll FP 4) Press ▼ to select “Enroll FP” and then press OK. Enroll Pwd Reg RFID 5) Press ▲/▼ to select “Admin Accredit”, and then Admin Accredit “Supervisor”...

  • Page 18: Enroll A Password

    Fingerprint Lock User Manual V1.0 The system returns to the “New Enroll” interface upon successful enrollment. You can continue or exit the fingerprint enrollment.  Note: The last digit in “00001–0” refers to the fingerprint count. “0” refers to the first fingerprint, “1” refers to the second fingerprint and so on and so forth. 2.1.2 Enroll a Password ↓...

  • Page 19: Enroll An Rf Id Card

    Fingerprint Lock User Manual V1.0 New Enroll 8) Input a password by pressing the number keys ———— and press OK to confirm your input. New Enroll 9) Input the password again by pressing the number keys and press OK to confirm your input. Press OK ****** after successful password enrollment to return to the —...
  • Page 20 Fingerprint Lock User Manual V1.0 ↑ Enroll Admin Enroll FP 4) Select “Reg RFID” and press OK. Enroll Pwd ►Reg RFID Admin Accredit 5) Press ▲/▼ to select “Admin Accredit”, and then Supervisor select “Supervisor” (Super administrator) or “Admin” (Administrator). Press OK to confirm your selection, as shown in the figure on the left.

  • Page 21: Enroll An Ordinary User

    Fingerprint Lock User Manual V1.0 New Enroll 9) The displayed card number is shown in the figure CARD: 16650449 on the left. UserID: 00010 10) Press OK to proceed to the next step. The New Enroll interface displayed is shown in the figure on the left. 000010-C Note: The last letter “C”...
  • Page 22 Fingerprint Lock User Manual V1.0 3) The system displays the prompt “Error Pwd.” on the screen and return to the “Admin Affirm” interface for re-verification. The following menu Error Pwd. interface is displayed upon successful verification. ↓ Menu ►User Manage 4) Press OK to display the user management Options interface.

  • Page 23: Backup Enrollment

    Fingerprint Lock User Manual V1.0 2.3 Backup Enrollment On the "New Enroll?" interface, if you press ESC to cancel new enrollment, then the “Backup Enroll” interface will be displayed, as shown in the figure on the right. Enroll FP Backup Enroll Press ESC UserID 00009...

  • Page 24: Set User Verification And No Status

    Fingerprint Lock User Manual V1.0 2.4 Set User Verification and NO Status 1) Press the Start key to display the initial interface. 2009-11-24 The fingerprint sensor is in active state. FP LOCK 2) Press your finger with fingerprint already enrolled or enter your password (press OK after entering password.) Note: You can only match fingerprints when the...

  • Page 25: Fp Card Management

    Fingerprint Lock User Manual V1.0 5) If you press OK, the interface as shown in the figure on the left will be displayed, indicating Normal Open successful NO setting. In the meantime, the buzzer will beep three consecutive times. If fingerprint or password verification is unsuccessful, the system will display a prompt “Please press your finger again”...

  • Page 26: Create A Pin Card

    Fingerprint Lock User Manual V1.0 Create PINCard: This option is used to create an ID card for a user who has already been enrolled in the fingerprint lock. You can verify your ID card instead of your fingerprint (only after the parameter “Card Only”...
  • Page 27 Fingerprint Lock User Manual V1.0 2) When prompted to enter the user ID number, Create PINCard press ▲/▼ to select the desired user ID, and press OK. The system then prompts you to “Show the Show the card card” (If the selected user ID does not exist in the system, the system will display a prompt “No Enroll”), as shown in the figure on the left: 3) Swipe your FP card through the card reader.

  • Page 28: Enroll An Fp Card

    Fingerprint Lock User Manual V1.0 2 Verify the PIN Card  Note: Set the parameter “Card Only” to “Yes”. If you set the parameter “Card Only” to “No”, you cannot verify with the created PIN card. Set Opt. 1) Select “Set”  “Set Opt.” from the main menu. Verify Mode The interface as shown in the figure on the left is Normal Open...
  • Page 29 Fingerprint Lock User Manual V1.0 2) Press ▲/▼ to select an ID and then press OK to Enroll FPCard 00003-0 confirm your selection and proceed to the next step. Place Finger… Place one of your fingers on the fingerprint sensor. Enroll FPCard 3) Place the same finger on the fingerprint sensor 00003-0...

  • Page 30: Create An Fp Card

    Fingerprint Lock User Manual V1.0 1) On the initial interface, swipe an enrolled FP card through the card reader. The interface as 00003 shown in the figure on the left is displayed: Place Finger… 2) Place one of your fingers with fingerprint enrolled on the fingerprint sensor window properly.

  • Page 31: Purge An Fp Card

    Fingerprint Lock User Manual V1.0 2) Press OK and the interface as shown in the Create FPCard figure on the left is displayed. Show the card 3) Swipe your card through the card reader until Create FPCard the interface as shown in the figure on the left is displayed.

  • Page 32: Delete User Data

    Fingerprint Lock User Manual V1.0 2) Swipe your card through the card reader until Empty Card the interface as shown in the figure on the left is Write succ displayed. Now the FP card is purged successfully. 2.6 Delete User Data Warning: It is prohibited to power off the fingerprint lock while deleting user data so as to prevent the program from accidentally deleting other data.
  • Page 33 Fingerprint Lock User Manual V1.0 3) The system displays the prompt “Error Pwd.” on the screen and returns to the “Admin Affirm” interface for re-verification. If you pass the Error Pwd. verification, you can access the “Menu” interface. ↓ Menu 4) Press OK to display the “User Manage”...
  • Page 34 Fingerprint Lock User Manual V1.0 Del User 9) Confirm the deletion of this user. Press OK to 00002 confirm the deletion, or press ESC to return to the “User Manage” interface. 10) After deleting the user data, you can restart the fingerprint lock and match the deleted fingerprints again to check whether the user data is deleted for sure.

  • Page 35: Lock Function Information And Settings

    3. Lock Function Information and Settings 3.1 Operation Settings Select "Options"  "Set Opt.” from the main menu to display the following information: Set Opt. Verify Mode Illega Alarm Normal Open Illega Cnt. Card Only Lock The options under “Set Opt.” include: Illega Alarm, Illega Cnt., Lock, Verify Mode, Normal Open, and Card Only.
  • Page 36 Lock: This parameter is used to set the duration from successful matching to unlocking. Select Lock and press OK to display the Lock interface. Press ▲/▼ to select a value. Press ESC to exit current interface and save your settings. For this parameter, its unit of quantity is 1 second and value range is 3–15, that is, 3–15 seconds.

  • Page 37: Language Settings

    2009-11-16 OK(Lock Up) To disable the NO function, power on the system and press OK in the Normal Open interface. Then the system closes the lock and automatically powers off. Press OK to display the Card Only interface, and press ▲/▼ to Card Only: select Yes or No.

  • Page 38: Fp Card Password

     Note: Language selection is a non-standard function. If you need this function, please consult our commercial representatives or pre-sales technical support engineers. 3.3 FP Card Password After you set a password for your FP card, the fingerprint lock will write this password into a Mifare card during the enrollment or creation of your FP card.

  • Page 39: Browse System Information

    ↓ Adv Option Clr Admin Pri Reset Opts. Del All Logs Clear All Data The options under “Adv Option” include: Reset Opts., Del All Logs, Clear All Data, and Clr Admin Pri. Select any one of these options and press OK to display the related setting interface.

  • Page 40: Browse Logs

    ↓ Sys Info Admin Cnt Browse Logs Pwd Usr Enroll User Reg RFID Enroll FP Free Space Info Dev Info Press ▲/▼ to select Free Space Info and then press OK to browse the following information: Free Space Info FP Cnt 29915 Reg RFID ...

  • Page 41: Usb Pen Drive Management

    Select “Browse Logs” from the main menu to display the following information: Browse Logs UserID 0001 Press ▲/▼ to select a registered number that you want to browse logs and then press OK to confirm the log date and time: The first digit denotes the 2--1 total number of records...
  • Page 42 PenDrive Mng DwnLoad AttLog 3) Press OK in the prompt dialog box to display the DwnLoad User following interface: UpLoad User Upgrade Firmware 1. Download Attendance Logs 1) Press ▲/▼ to select “Dwn AttLog” and then press OK. When download completes, the following Copy Data Suc! interface is displayed: 2) Press ESC to return to the initial interface and then remove the USB pen drive.
  • Page 43  Tip: If a user exits with the same ID in the fingerprint lock, the new upload will overwrite the existing user data; otherwise, the new user data will be directly added. 4. Upgrade Firmware You can select “Upd Firmware” to upgrade the firmware of a fingerprint lock through the upgrade files in the USB pen drive.

  • Page 44: Conventions On Other Functions

    4. Conventions on Other Functions 4.1 Routine Operation Indications User operation success indication: The buzzer sounds once and the green LED indicator is solid on for 3 seconds. User operation failure indication: The buzzer sounds short tone twice and the red LED indicator is solid on for 3 seconds.

  • Page 45: Automatic Program Exit And System Power-Off

    4.4 Automatic Program Exit and System Power-off  The fingerprint lock powers off automatically upon successful matching and unlocking.  The fingerprint lock powers off automatically when you set Yes for the “Normal Open” option upon unlocking.  The fingerprint lock powers off automatically when the number of invalid operations exceeds the threshold.

  • Page 46: Unlock With An Emergency Mechanical Key

    If you power off a fingerprint lock without closing the lock during the use of external power, the lock cylinder will not automatically return to its original position. That is, the fingerprint lock remains in NO state. To solve this problem, you can replace the battery and then open the lock once to have the lock cylinder in position.
  • Page 47 ① ②...

  • Page 48: Appendix

    Appendix Technical Specifications  Sensor: Optics sensor without coating  Capacity: 500 fingerprint images; 100 passwords; 500 users.  Matching mode: Fingerprint matching, password matching, MF card & ID card matching.  Record capacity: 30000  Resolution: 500 DPI  Identification speed: ≤...
  • Page 49 This document is subject to change without prior notice. Printed in China...
