SBTL7000 Series
User Manual
SBTL7000 Series
Applicable Models: SBTL7000/7011/7022/7033
Date: April 2023
Doc Version: 2.0
English
Thank you for choosing our product. Please read the instructions carefully
before operation. Follow these instructions to ensure that the product is
functioning properly. The images shown in this manual are for illustrative
purposes only.
P a g e
| 1
For further details, please visit our Company's website
www.zkteco.com.
Copyright©2020 ZKTECO CO., LTD. All rights reserved.
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBTL7011 and is the answer not in the manual?

Questions and answers

Related Manuals for ZKTeco SBTL7011

Summary of Contents for ZKTeco SBTL7011

  • Page 1 Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only. For further details, please visit our Company’s website www.zkteco.com. P a g e Copyright©2020 ZKTECO CO., LTD. All rights reserved.
  • Page 2 Copyright © 2023 ZKTECO CO., LTD. All rights reserved. Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company" or "ZKTeco").
  • Page 3 SBTL7000 Series User Manual relating to the use of the information contained in or referenced by this manual, even if ZKTeco has been advised of the possibility of such damages. This manual and the information contained therein may include technical, other inaccuracies or typographical errors.
  • Page 4 User Manual About the Company ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader Door Locks.
  • Page 5 The general information which helps in performing the operations faster The information which is significant Care taken to avoid danger or mistakes The statement or event that warns of something or that serves as a cautionary example. P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 6: Table Of Contents

    .......................... 24 RROR ODE FOR URNSTILE ........................25 IRING IAGRAM AND UNCTION MAINTENANCE ..........................27 ..........................27 HASSIS AINTENANCE ..........................27 OVEMENT AINTENANCE ........................27 OWER UPPLY AINTENANCE TROUBLESHOOTING.......................... 28 P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 7: Overview

    User Manual Overview The ZKTeco SBTL7000 swing barrier turnstile is an elegant cost-effective entrance control system designed for high-traffic volume. SBTL7000 barriers are normally held in a locked position, thus denying access to the secured side. Upon SBTL7000’s reader (RFID) positively recognizing a user’s valid access card, its barriers swing automatically, thus allowing users passage to the secured side.

  • Page 8: Mechanical System

    If the pedestrian enters the passage but forgets to verify identification, or if the card held by the pedestrian is invalid, the system will prompt an audible alarm to stop and retreat the P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 9: System Composition

    Relative Humidity (Non-condensing) Temperature -20°C to 70°C Throughput Rate Maximum 30 persons/minute Infrared Sensors 6~10 Pairs Working Environment Indoor/Outdoor with customization Dimension(mm) L = 1081, W = 1200, H =1028 P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 10: Installation

    The reference figure is shown below: Figure 2-1 SBTL7000 Series Dual-lane P a g e Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 11: Cables Installation And Fixing

    100mm. In addition, the conduit outlet is bent back to prevent the ingress of water into the conduit. SBTL7000 series installation holes and cabling positions is shown in Figure 2-2: Figure 2-2 P a g e | 10 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 12 It is recommended that a warning line be marked on the ground after installing the device, so as to prompt the pedestrian to stand behind the warning line when swiping the card.as shown in Figure 2-3: Figure 2-3 P a g e | 11 Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 13: Menu Introduction

    (01E003) Test mode (the digital LED displays "---" in the test mode).  (01E004) Version number.  Opening Mode Setting (02EXXX) (02E001) Two-way controlled, both need verification (Default)  P a g e | 12 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 14 (02E002) In need verification, out free  (02E003) In free, out need verification  (02E004) Two-way free  (02E005) In need verification, out prohibited  (02E006) In prohibited, out need verification  P a g e | 13 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 15 Set the gate opening speed to open the gate. The larger the number is set, the faster the speed. The Gate Opening Speed value can be set between 5 to 30 and the default value is 23. P a g e | 14 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 16 Set the gate closing speed to close the gate. The larger the number is set, the faster the speed. The Gate Closing Speed value can be set between 5 to 30 and the default value is 20. P a g e | 15 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 17 It can be set the valid time period after successful verification, after arriving at the set time, the gate willclose automatically, the larger the number set, the longer the valid time. The valid value is 2 to 60 seconds, and the default value is 5s. P a g e | 16 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 18 When setting the zero position, you can manually push the swing arm for fine-tuning. If the barrier exceeds a certain angle, it will be invalid. (At this time, the digital LED displays 13E000). P a g e | 17 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 19 Volume Setting is used for adjusting the volume of the device. The larger the number is set, the louder the volume. The valid value for Volume Setting can be set between 1 to 100 and the default value is 40. P a g e | 18 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 20 Set the duration of stay in the channel after successful verification. The valid value for Stay Duration Time can be set between 5 to 30 seconds and the default value is 10s. P a g e | 19 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 21 When the gate is unlocked in an unauthorized way, the clutch gets locked automatically. The Clutch Alarm Setting can be set as: (23E000) Delayed unlock (Default)  (23E001) Authentication to unlock.  P a g e | 20 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 22 When the Anti-pinch Area Setting needs to be set to (25E001) only, the False Direction Entry (26E000) is effective. (26E000) Close  (26E001) Only alarm (Default)  (26E002) No detection  P a g e | 21 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 23 When the Anti-pinch Area Setting needs to be set to (25E001) only, the Gate Closing Position (28E001) is effective. (28E000) Last pair (Default)  (28E001) Penultimate pair  P a g e | 22 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 24 You can adjust the synchronization of the Slave through this menu, the larger the value, the faster the response of the Slave to open the gate, the setting range lies between 30-200, and the default value is 100. P a g e | 23 Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 25: Error Code For Turnstile

    ER0002 Power-on Self-test failure, Hall Limit Detection Error ER0004 Run Timeout ER0008 Clutch Locked ER016 The code disk detection failed. ER032 Electric Motor Shaft Lock Protection failure P a g e | 24 Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 26: Wiring Diagram And Function

    SBTL7000 Series User Manual Wiring Diagram and Function Check circuit according to the following wiring diagram: P a g e | 25 Copyright©2023 ZKTECO CO., LTD. All rights reserved.
  • Page 27 LED light: It is connected to the light belt on the top of the device. IR Sensor: It is connected to the swing arm/barrier to achieve anti-crush function. P a g e | 26 Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 28: Maintenance

    For ensuring operational safety, first switch off the power supply when the barrier is not in use. P a g e | 27 Copyright©2023 ZKTECO CO., LTD. All rights reserved.

  • Page 29: Troubleshooting

    SBTL7000 Series User Manual Troubleshooting Failure Description Cause and Solution Cause: It may be due to if connection of the roof lamp is No response from direction not correct. indicator or indication is not Solution: Check whether the connection of the roof correct.
  • Page 30 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
