Installation Guide
Saturn-S1000 Series
Applicable Model(s): Saturn-S1000, Saturn-S1200
Version: 1.0
Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the
actual product and the written information in this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Saturn-S1000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKTeco Saturn-S1000 Series

  • Page 1 Installation Guide Saturn-S1000 Series Applicable Model(s): Saturn-S1000, Saturn-S1200 Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
  • Page 2: Revision History

    Revision History Description Revision Date Author Reviewer Julia Huang Original Document V1.0 12/11/2024...
  • Page 3 1 Overview Saturn-S1000 Saturn-S1200 Visual Indicator Top Lid Reserve Mounting Hole (for Face Device) Verification Area Entry/Exit Visual Indicator Infrared Sensor Core Component Barrier Material Side Lid Expansion Screw Cover Plate...
  • Page 4 2 Dimensions Saturn-S1000 Unit: mm Front View Side View 1200 1200 Top View Bottom View Mounting Holes 24x14mm...
  • Page 5 Saturn-S1200 Unit: mm Front View Side View 1000 1200 Top View Bottom View 1000 1000 Mounting Holes 24x14mm...
  • Page 6: System Composition

    3 System Composition The Saturn-S1000 and Saturn-S1200 can be combined to form a single, dual or multi-lane system, allowing the user to select the appropriate swing barrier size according to actual needs. Single-lane Standard Lane Wide Lane / ADA Lane Dual-lane Standard Lane Wide Lane / ADA Lane...
  • Page 7 4 Wiring Single-lane wiring Sub device 5-core connecting wire(M-S) AC110/220V input FACP (Fire alarm) Access controller cable Main device Dual-lane wiring Sub device Sub device Main device Main device Remarks: The multi-lane wiring method is similar.
  • Page 8: Installation Requirements

    5 Installation Requirements 1. It is recommended that the turnstile must be installed on a horizontal solid platform with a height of 50mm to 100mm. 2. It is recommended that the turnstile should not be used in the corrosive environment. 3.
  • Page 9 7 Installation Cabinet Step 1 Remove the Top Lid and Expansion Screw Cover Plate 1. Remove the four screws hidden under the top lid, then remove the top lid. 2. Remove the four screws of the expansion screw cover plate under the bottom beam, and then remove the cover plate.
  • Page 10: Step 2 Determine The Mounting Location

    Step 2 Determine the Mounting Location 1. Please refer to the user's manual and complete the power-on self test operation before installation. 2. Then place the cabinet according to the mounting distances shown in the diagram below. Take care to measure the distance between the bottom inside walls of the cabinets on the entrance side and exit side of the channel and make sure that the measurements are consistent.
  • Page 11 Step 4 Drill Holes and Place Bolts 1. Using a concrete drill bit, drill the mounting holes 60mm in depth at the center of each marked location. 2. Then insert the bolts vertically into the mounting holes as shown at right. 3.
  • Page 12 Step 6 Fixed Cabinet 1. After laying the PVC pipe, place the cabinet alignment bolts back into the mounting position. 2. Then insert the four washers and nuts into the bolts one by one. 3. Tighten the nuts to hold the cabinet in place. Don't tighten it completely until after you're sure it won't move anymore.
  • Page 13 Step 7 Close the Top Lid and Expansion Screw Cover Plate Close the top lid and expansion screw cover plate, and secure with screws. Step 8 Marking the Warning Line 1. It is recommended that warning lines be marked on the ground and used to alert users. 2.
  • Page 14: Wiring Diagram

    8 Wiring Diagram...
  • Page 15 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2024 ZKTECO CO., LTD. All Rights Reserved.
