1D Barcode Scanner
User Manual
SBT3000 Series
Date:
April 2024
Doc Version: 1.0
English
Thank you for choosing our product. Please read the instructions carefully
before operation. Follow these instructions to ensure that the product is
functioning properly. The images shown in this manual are for illustrative
purposes only.
P a g e
| 1
For further details, please visit our Company's website
www.zkteco.com.
Copyright©2020 ZKTECO CO., LTD. All rights reserved.
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBT3000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ZKTeco SBT3000 Series

Summary of Contents for ZKTeco SBT3000 Series

  • Page 1 Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only. For further details, please visit our Company’s website www.zkteco.com. P a g e Copyright©2020 ZKTECO CO., LTD. All rights reserved.
  • Page 2 Copyright © 2024 ZKTECO CO., LTD. All rights reserved. Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company" or "ZKTeco").
  • Page 3 ZKTeco shall in no way be responsible (i) in case the machine/unit/device malfunctions due to any non- compliance of the instructions contained in this manual (ii) in case of operation of the machine/unit/device beyond the rate limits (iii) in case of operation of the machine and device in conditions different from the prescribed conditions of the manual.
  • Page 4 User Manual About the Company ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/Floor access controllers, Doors, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader door locks.

  • Page 5: Table Of Contents

    SERIAL COMMUNICATION PROTOCOL ..................24 ..................................25 OOR OPENING INSTRUCTION ..........................25 UTOMATIC ETURN TO OMPLETION TATUS ....................................27 ASSAGE LARM NQUIRY ..................................27 UMBER OF ASSES NQUIRY ...................................28 ASSAGE TATUS NQUIRY APPENDIX ..............................29 P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 6: Overview

    Offers switching between normally open/normally closed functions to suite different places. Features memory function to allow passage for multiple individuals after continuous card swipin. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 7: Product Specifications

    Indoor, outdoor (canopy), temperature: -20°C to 70°C; humidity: RH ≤ Environment 90% non-condensation. Power Input AC220V to 240V, 50/60Hz. Input Interface Switching signal or DC12V level signal. Running Times Above 15 million. Product Dimensions P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 8: Installation

    SBT3000 Series User Manual Installation Bottom Mounting Holes: Bottom Cable Routing Holes: Wiring Schematic diagram location of the gate's main and auxiliary machine online cables. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 9: Interface Description

    SBT3000 Series User Manual Interface Description Installation Diagram Main Board Ports P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 10: Secondary Board Ports

    Swing / Flap Barrier Turnstile: alarm signal output; Solenoid/Alarm Tripod Turnstile: solenoid output (12V/24V optional). RS485: master-slave synchronous communication; Synchronization and Communication RS232: communication with the host computer. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 11: Device Settings

    (A- Menu) Click Confirm button Display "___" Set zero position and others. (Password Input Interface) Input password “168”, and Click Confirm button Display "___" (Password Input Interface) P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 12: Menu Display

    Step 2. Click Confirm button again to confirm, the door panel will enter the deactivation state, then swing the door panel to the set position. Step 3. After 5 seconds, the gate will be reset automatically. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 13: Quick Debug Wizard

    F65 to modify the door type Speed blocking parameter Auxiliary Encoder A-IdE, parameter identification of This operation is not required if Recognition the auxiliary encoder. no auxiliary encoder is installed. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 14: Parameter Table

    Zeroing Turn Blocking Increase appropriately when 09 08 1 to 100 Current finding zero abnormality. 09 09 Velocity Ring Ratio 1 to 999 Increase when the door is heavy. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
  • Page 15 0F 01 Infrared Logarithmic 0 to 2 6 pairs of red. 4 pairs of infrared. 0F 02 Continuous Swipe 0 to 1 0 means invalid. 1 means valid. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
  • Page 16 Gate Opening Delay Time 0F 0E 0 to 500 Unit: 10ms. After Card Swipe Delay Time to Close Gate 0F 0F 0 to 500 Unit: 10ms. After Passing P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
  • Page 17 Stay Voice Setting (Please 0F 1E 0 to 79 pass through quickly) Gate Breaking Voice 0F 28 (Break-in, please pass 0 to 79 after verification) P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
  • Page 18 Maximum Deviation Used for double closed-loop 06 07 Angle of Position 0 to 900 zeroing, set to 0 to invalidate this Following function. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
  • Page 19 Tempered glass 300. Acrylic 400. Door Panel Selection Tempered glass 400. 08 0E 0 to 7 (Height 1000) Acrylic 500. Tempered glass 500. Acrylic 600. Tempered glass 600. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 20: Voice Content Table

    Code Chinese Code English 欢迎光临 Welcome 非法闯入请验证后通过 Do not enter, authorized personnel only 反向进入请退出等候 Unauthorized access from opposite direction 尾随通行请注意 Don't follow 尽快通行请勿逗留 Please pass through quickly P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
  • Page 21 Please authorize outside the line "DING" "DI DI" 请出厅 请通行 Please go through 系统初始化 System startup 系统启动完成 System startup complete 验证失败 Verification failure 请小心通行 Please be careful P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 22: Status Display

    Power-On Hall Loss Check encoder cable or replace motor. Drive hardware failure or abnormal software EEPROM Error version. Check for stuck motor loads or abnormal Motor Blocking motors. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
  • Page 23 F61 The motor model is set incorrectly, change to the correct motor model; Failure To Find Zero F49 Deceleration ratio parameter setting error. running blocking current size mismatch, adjust larger smaller appropriately. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 24: Serial Communication Protocol

    0x03 for read function code command, 0x06 for write function code command. Function Code Address: Function code parameter F12-00, i.e. 0x0C 0x00. Data: Function code value 01, i.e. 0x00 0x01. CRC Checksum: CRC16 check value, CRC_L CRC_H. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 25: Door Opening Instruction

    It is used to judge the current passage status of the gate: When the display is 0, it means that all passes are completed; When FF FF is displayed, it means the passage timeout; P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
  • Page 26 If someone does not enter the passageway in time, the passage FF FF: Passage timeout. 09 04 00 FF FF CRC_L CRC_H time out and the gate closes. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 27: Passage Alarm Inquiry

    Entrance Headcount = Entrance Headcount High * 65536 + Entrance Headcount Low. • Exit Count = Exit Count High * 65536 + Exit Count Low. • Empty Headcount: Empty both entrance and exit headcount. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 28: Passage Status Inquiry

    5. Outward swipe card status. 6. Set zero state. 7. Inward free pass status. 8. Outward free passage status. 9. Power down and open status. 10. System normally open state. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.

  • Page 29: Appendix

    Glass Glass Material Door 1200 Opening and Closing (60%) (45%) (45%) (40%) (40%) (25%) (35%) (22%) Speed (F03) Acceleration Deceleration (F04) Speed Ring (F07) Position Ring (F08) P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
  • Page 30 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2024 ZKTECO CO., LTD. All Rights Reserved. P a g e Copyright © 2024 ZKTECO CO., LTD. All rights reserved.
