SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST-EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page... -
Page 2: Ageneral Information
SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *Professional Spiral Dough Mixer ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) SH.01 432x792x987 570x910x1180 SH.02 544x912x1065 680x1030x1230 SH.03 637x1040x1105 710x1200x1260 SH.04... -
Page 4: A3 Transportation
SPIRAL DOUGH MIXER TRANSPORTATION *This appliance can not be moved by hand from area to area.It must be moved on pallet with Kasap Tip Dik Buzdolapları forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. *Do not operate the appliance when the machine is empty. -
Page 6: Doperation
SPIRAL DOUGH MIXER OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : Time setting B : Start C : Stop D : Speed Setting *Operating; • Before operating,clean the bowl with a wet cloth and dry. • Please lift up bowl lid and put flour as much as capacity.Please add enough water into the bowl.If quantity of water is not enough, add water through lid space without lifting the lid. -
Page 7: Ecleaning & Maintenance
SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE CLEANING AND MAINTENANCE AFTER EVERY USE Clean outer surface of appliance ,mixer and bowl with hot water and then dry. Always turn off the appliance and disconnect from the power supply before cleaning. ... -
Page 8: Ftroubleshooting
SPIRAL DOUGH MIXER TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T Check the electrical connections and voltage. Check appliance’s bowl safety lid. OPERATE Check the urgent stop button. Check if there is enough water and flour in dough bowl. -
Page 9: Gspare Part List-Exploding Drawing
SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING SH.01... - Page 10 SPIRAL DOUGH MIXER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE:SH.01 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE BIG PULLEY YDK-ERS.SH-CN-0014 22 PJ 1168 STRAP M.KYS-TKY-005 MAGNET M.MIK-ERS-004 MICA BINDING SHEET YSC-ERS.SH-LZ-0001 BOILER COVER M.ENJ-ERS-FLK-019 STAMP YTL-ERS.SH-KS-0007 PRE-MIXER ARA-ERS.SH-0005 RING 472-85 B-SEG-SYH-021 BEARING ( 6009 ZZ ) M.RLM-NRM-035...
- Page 11 SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları BEARING ( 6009 ZZ ) M.RLM-NRM-035 UPPER SLEEVE YDK-ERS.SH-CN-0009 BEARING ( 6207 ZZ ) M.RLM-NRM-034 HINGE SHAFT YTL-ERS.SH-KS-0002 ELECTRIC MOTOR M.ELK-MTR-RSM-020 ENGINE PULLEY YTL-ERS.SH-KS-0038 STRAP (13*700) M.KYS-VKY-017 SMALL PULLEY YDK-ERS.SH-CN-0011 UPPER PULLEY YDK-ERS.SH-CN-0013 TOP COVER M.ENJ-ERS-PLS-SH-001...
- Page 12 SPIRAL DOUGH MIXER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları SH.02...
- Page 13 SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE:SH.02 PRODUCT NAME P.CODE TOP COVER M.ENJ-ERS-PLS-SH-002 STRAP (13*700) M.KYS-VKY-017 SMALL PULLEY YDK-ERS.SH-CN-0011 BIG PULLEY YDK-ERS.SH-CN-0014 22 PJ 1168 STRAP M.KYS-TKY-006 RING 471-35 B-SEG-SYH-019 BEARING ( 6207 ZZ ) M.RLM-NRM-034 UPPER SLEEVE YDK-ERS.SH-CN-0009...
- Page 14 SPIRAL DOUGH MIXER SWITCH M.ELK-SLT-PKO-015 TIME CLOCK M.ELK-MEK-MTM-004 Kasap Tip Dik Buzdolapları ELECTRICAL PANEL GROUP M.ELK-PNO-SH-003 EMERGENCY STOP BUTTON M.ELK-SLT-BTL-003 ELECTRICAL PANEL SHEET YSC-ERK.KD-LZ-0049 GZ1AN11 CONTACTOR ERS.M.ELK-KNT-KNT-029 ENGINE PROTECTION LINING SHEET M.ELK-SLT-MK-007 CONTACTOR LC1D09M7 ERS.M.ELK-KNT-KNT-027 STRAP (13*1175) M.KYS-VKY-013 LOWER PULLEY YDK-ERS.SH-CN-0012 BEARING ( UCFL 206 ) M.RLM-YTK-001...
- Page 15 SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING SH.03...
- Page 16 SPIRAL DOUGH MIXER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE:SH.03 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE TOP COVER M.ENJ-ERS-PLS-SH-003 SMALL PULLEY YDK-ERS.SH-CN-0011 STRAP (13*750) M.KYS-VKY-021 BIG PULLEY YDK-ERS.SH-CN-0014 BOILER COVER M.ENJ-ERS-FLK-021 PRE-MIXER ARA-ERS.SH-0008 Dough BOILER (60*31) M.MTS-ERS-HY-009 RING 472-72 B-SEG-SYH-020 BEARING ( 6009 ZZ ) M.RLM-NRM-035 LOWER SLEEVE SHAFT...
- Page 17 SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING SH.04...
- Page 18 SPIRAL DOUGH MIXER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE:SH.04 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE TOP COVER M.ENJ-ERS-PLS-SH-001 SMALL PULLEY YDK-ERS.SH-CN-0011 BIG PULLEY YDK-ERS.SH-CN-0014 BEARING ( 6207 ZZ ) M.RLM-NRM-034 RING 471-35 B-SEG-SYH-019 22 PJ 1168 STRAP M.KYS-TKY-005 UPPER SLEEVE SHAFT YTL-ERS.SH-KS-0033 UPPER SLEEVE YDK-ERS.SH-CN-0009...
- Page 19 SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING SH.05...
- Page 20 SPIRAL DOUGH MIXER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE:SH.05 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE TOP COVER M.ENJ-ERS-PLS-SH-001 SMALL PULLEY YDK-ERS.SH-CN-0011 BIG PULLEY YDK-ERS.SH-CN-0014 RING 471-35 B-SEG-SYH-019 BEARING ( 6207 ZZ ) M.RLM-NRM-034 UPPER SLEEVE YDK-ERS.SH-CN-0009 BEARING ( 6009 ZZ ) M.RLM-NRM-035 FELT 48*90*10 M.CNT-KCE-030...
- Page 21 SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING SH.06...
- Page 22 SPIRAL DOUGH MIXER SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE:SH.06 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE TOP COVER M.ENJ-ERS-PLS-SH-002 SMALL PULLEY YDK-ERS.SH-CN-0011 BIG PULLEY YDK-ERS.SH-CN-0014 22 PJ 1168 STRAP M.KYS-TKY-006 RING 471-35 B-SEG-SYH-019 BEARING ( 6207 ZZ ) M.RLM-NRM-034 UPPER SLEEVE YDK-ERS.SH-CN-0009 BOILER COVER M.ENJ-ERS-FLK-020...
-
Page 23: Product Code
SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA PRODUCT CODE POWER (KW) VOLTAGE SH.04 SH.05 SH.06 Motor Safety Basket Magnetic Start Timer 0-30 Terminal Motor Contactor Relay Sensor Lamp min. -
Page 24: Helectric Circuit Schema
SPIRAL DOUGH MIXER ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları Q1-ENGINE PROTECTION SWITCH B1-STOP BUTTON B2-START BUTTON T-TIME CLOCK S1-MAGNETIC SENSOR 1 P-2 CYCLE SWITCH C1-CONTACTOR 1 C2-CONTACTOR 2 C3-CONTACTOR 3 C4-CONTACTOR 4 M-ENGINE... - Page 25 SPIRAL DOUGH MIXER Kasap Tip Dik Buzdolapları PRODUCT CODE POWER (KW) VOLTAGE SH.01 1 / 1,7 750/1500 SH.02 1.5 / 2.5 750/1500 SH.03 1.5 / 2.5 750/1500...
