Section 1 - General Information
ON/OFF
Press this button to turn the
unit on or off.
Power Receptor
Receptor for the supplied
power adapter.
D-Link DSL-30B ADSL+ Ethernet/USB Modem User Manual
Rear Panel View
LAN Port
Connect Ethernet devices such as
computers, switches, and hubs.
USB Port
Connect a computer using a USB
cable.
DSL Line
Connect to an active telephone
line (RJ-11).
Reset
Pressing the Reset button restores
the modem to its original factory
default settings.
6
