Summary of Contents for D-Link DSL-2640R
-
Page 2: Fcc Notices
FCC Notices This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Table Of Contents
Table of Contents ..................1 ACKAGE ONTENTS STATUS....................... 53 ..................1 YSTEM EQUIREMENTS ......................2 ..................... 54 EATURES YSTEM LEDs......................4 ....................... 55 TATISTICS INSTALLATION ....................5 TROUBLESHOOTING..................56 .................... 5 NETWORKING BASICS..................58 EFORE EGIN ..................5 NSTALLATION OTES IP A ................. -
Page 4: Package Contents
• One straight-through Ethernet cable • One Quick Installation Guide Note: Using a power supply with a different voltage rating than the one included with the DSL-2640R will cause damage and void the warranty for this product. System Requirements • ADSL Internet service •... -
Page 5: Features
This eliminates the need to reconfigure every host whenever changes in network topology occur. • Network Address Translation (NAT) – For small office environments, the DSL-2640R allows multiple users on the LAN to access the Internet concurrently through a single Internet account. This provides Internet access to everyone in the office for the price of a single user. -
Page 6: Hardware Overview
Use the Ethernet ports to connect Push in to power-on the Router. Use the adapter shipped with the the Router to a computer or an Push again to power-off the Router to connect to power Router Ethernet LAN source D-Link DSL-2640R User Manual... -
Page 7: Leds
This light will blink when there is activity Router power is off, this remains dark. A solid red light indicates currently passing through the Ethernet port. there is no DHCP response, no PPPoE response, PPPoE authentication has failed, and/or there is no IP. D-Link DSL-2640R User Manual... -
Page 8: Installation
Operating Systems The DSL-2640R uses an HTML-based web interface for setup and management. The web configuration manager may be accessed using any operating system capable of running web browser software, including Windows 98 SE, Windows ME, Windows 2000, Windows XP, and Windows Vista. - Page 9 802.1g or 802.1b wireless network card installed to use the Wireless ADSL Router. In addition the workstations must be configured to operate on the same channel and SSID as the Wireless ADSL Router. If wireless security is used, the wireless workstations must be properly configured for the security settings used. D-Link DSL-2640R User Manual...
-
Page 10: Information You Will Need From Your Adsl Service Provider
ADSL, ADSL2, and ADSL2+ modulation. Security Protocol This is the method your ADSL service provider will use to verify your Username and Password when you log on to their network. Your Router supports the PAP and CHAP protocols. D-Link DSL-2640R User Manual... - Page 11 IP address used for DHCP service on the LAN when DHCP is enabled. LAN Subnet Mask for the DSL-2640R This is the subnet mask used by the DSL-2640R, and will be used throughout your LAN. The default subnet mask is 255.255.255.0. This can be changed later.
-
Page 12: Device Installation
Ethernet NIC If your computer has an Ethernet NIC, you can connect the DSL-2640R to this Ethernet port using an Ethernet cable. You can also use the Ethernet ports on the DSL-2640R to connect to other computer or Ethernet devices. -
Page 13: Power On Router
Remember that this will wipe out any settings stored in flash memory including user account information and LAN IP settings. The device settings will be restored to the factory default IP address 192.168.1.1 and the subnet mask is 255.255.255.0, the default management Username is “admin” and the default Password is “admin.” D-Link DSL-2640R User Manual... -
Page 14: Network Connections
Router’s wireless access point must have the same SSID and channel. If wireless security is used, the wireless clients must be configured with the correct security information to use the Router. More information on configuring the wireless settings is found later in this manual. D-Link DSL-2640R User Manual... -
Page 15: Setup
Section 3 – Configuration Setup This section will show you how to set up and configure your new D-Link Router using the Web-based configuration utility. Web-based Configuration Utility Connect to the Router To configure the WAN connection used by the Router it is first necessary to communicate with the Router through its management interface, which is HTML-based and can be accessed using a web browser. -
Page 16: Configure The Router
Quick Start, Interface Setup, Advanced Setup, Access Management, Maintenance, and Status. The Quick Start Wizard allows you to configure the basic settings for the WAN (Internet) and Ethernet LAN (including DHCP) settings. D-Link DSL-2640R User Manual... -
Page 17: Quick Start
The first pop-up window of the Quick Start Wizard lists the basic steps in the process. These steps are as follows: 1. Set your new password 2. Choose your time zone 3. Set your Internet connection 4. Re-start your ADSL router Click Next to continue. D-Link DSL-2640R User Manual... - Page 18 Choose the time zone you are in from the pull-down menu and click Next. This sets the system time used for the Router. If you wish to return to the previous window during the setup process, click the Back button. D-Link DSL-2640R User Manual...
- Page 19 3. Select the specific Connection Type from the drop-down menu. The available PPP connection and encapsulation types are PPPoE LLC, PPPoE VC-Mux, PPPoA LLC, and PPPoA VC-Mux. 4. Click Next to go to the next window and complete the Quick Start Wizard. D-Link DSL-2640R User Manual...
- Page 20 The available Static IP Address connection and encapsulation types are 1483 Bridged IP LLC, 1483 Bridged IP VC-Mux, 1483 Routed IP LLC (IPoA), and 1483 Routed IP VC-Mux. 4. Click Next to go to the next window and complete the Quick Start Wizard. D-Link DSL-2640R User Manual...
- Page 21 Next button to save the new configuration settings. If you need to change settings from a previous window, click the Back button. Click the Close button to complete the Quick Start setup procedure. D-Link DSL-2640R User Manual...
-
Page 22: Interface Setup
To change the settings for any profile in the list, use the Virtual Circuit drop-down menu to display individual profiles or click the PVCs Summary button to display the following summary of all the profiles for the Internet interface. D-Link DSL-2640R User Manual... -
Page 23: Pppoe/Pppoa
ADSL service. The available options are PPPoE LLC, PPPoE VC-Mux, PPPoA LLC, and PPPoA VC-Mux. If you have not been provided specific information for this section, leave the default setting. D-Link DSL-2640R User Manual... - Page 24 14. The Multicast feature is Disabled by default. Toggle between IGMP v1 software installed on it. and IGMP v2. 15. When you are satisfied that all the Internet settings are configured correctly, click on the SAVE button. D-Link DSL-2640R User Manual...
-
Page 25: Dynamic Ip Address
Direction to Both, IN Only, OUT Only, or None. 9. The Multicast feature is Disabled by default. Toggle between IGMP v1 and IGMP v2. 10. When you are satisfied that all the Internet settings are configured correctly, click on the SAVE button. D-Link DSL-2640R User Manual... -
Page 26: Static Ip Address
Both, IN Only, OUT Only, or None. 10. The Multicast feature is Disabled by default. Toggle between IGMP v1 and IGMP v2. 11. When you are satisfied that all the Internet settings are configured correctly, click on the SAVE button. D-Link DSL-2640R User Manual... -
Page 27: Bridge Mode
The available options are 1483 Bridged IP LLC and 1483 Bridged IP VC-Mux. If you have not been provided specific information for this section, leave the default setting. 5. When you are satisfied that all the Internet settings are configured correctly, click on the SAVE button. D-Link DSL-2640R User Manual... -
Page 28: Lan Setup
The three options for DHCP service are as follows: Use the Router as a DHCP server for your LAN. Disable DHCP service and manually configure IP settings for workstations. Use DHCP service provided by your ISP. D-Link DSL-2640R User Manual... -
Page 29: Use The Router For Dhcp
To use DHCP service from your ISP or another DHCP server, select the Relay option and type the DHCP Server IP for Relay Agent address in the space provided. Click SAVE to begin DHCP relay from the ISP. D-Link DSL-2640R User Manual... -
Page 30: Wireless Setup
Activated option for Wireless LAN and continue to configure basic settings. Click the SAVE button to begin wireless LAN function with the settings as configured. It is not necessary to reboot the Router. D-Link DSL-2640R User Manual...
