TrailFX 201191 Installation Instructions

Aluminum trailer tongue box

Download this manual

Part No.

201191, 201341

REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT.

READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.

DO NOT OVER TORQUE. STANDARD OPERATING LOAD FOR TIGHTEN

BODY MOUNT NUTS & BOLTS VARIES FROM 45 TO 65 FOOT POUND.

Aluminium Trailer Tongue Box

part

Trailer tongue box

Key

part

3/8" u-bolt

Nut

Washer

Tool Box

Aluminum Trailer Tongue Box

PARTS INCLUDED

Description

Cutting Not

30-60 min

Required

qty.

Drilling

Required

Need help?

Do you have a question about the 201191 and is the answer not in the manual?

Page 1 Tool Box Aluminum Trailer Tongue Box Part No. 201191, 201341 Cutting Not Drilling 30-60 min Required Required REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. DO NOT OVER TORQUE. STANDARD OPERATING LOAD FOR TIGHTEN BODY MOUNT NUTS &...
Page 2 NOTE: Due to the variation in trailer styles, mounting hardware is not included but installation is required. Recommended hardware includes a minimum of two square 3/8" u-bolts with nuts and washers. TOOLS REQUIRED part Description qty. Drill Drill bit Tape measure Socket wrench Safety glasses 1.
Page 3 DRILLING MOUNTING HOLES IN THE BOX WARNING: The trailer box is designed to install on the tongue of a trailer. Before drilling into the box, ensure that your approximate drill location will not puncture, cut or obstruct any brake or fluid lines, electrical wires, fuel tanks, etc. Drill holes in the front of the box and in the rear of the box spaced properly for the U-bolts (not included).
Page 4 PRODUCT CARE  Periodically check the product to ensure all fasteners are tight and components are intact.  Regular waxing is recommended to protect the finish of the product.  Use ONLY Non-Abrasive automotive wax. Use of any soap, polish or wax that contains an abrasive is detrimental and can scratch the finish leading to corrosion.

201341
