- Page 1 INSTRUCTION MANUAL 12V Licensed Lamborghini Revuelto Ride On SKY9095 + SKY9096 + SKY9097 + SKY9098 + SKY9099 + SKY9100 SKY9101 + SKY9102 Ver. 1...
- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
- Page 3 Charge for 12 hrs before initial use. After initial charge, follow the normal recommended charging time. bestchoiceproducts.com...
-
Page 4: Battery Warnings
SAFETY Please retain these instructions for future reference. This vehicle must be assembled by an adult who has read and understood the instructions in this manual. Keep the packaging and bags away from children and dispose of all packaging before use. Always use common sense and safe practices when operating this vehicle. -
Page 5: Specifications
To reduce the risk of injury, adult supervision is required. Never use on roadways, near motor vehicles, on or near steep inclines or steps, swimming pools or other bodies of water; always wear shoes, and never allow more than one rider. •... -
Page 6: Tools Required
TOOLS REQUIRED AA - 2 AA BATTERIES (FOR STEERING WHEEL) AAA - 66 LBS 2 PERSON UP TO 45 MIN. PHILLIPS PLASTIC WRENCH 2 AAA BATTERIES CAPACITY ASSEMBLY ASSEMBLY SCREWDRIVER (2, PROVIDED) (FOR REMOTE) HARDWARE SELF TAPPING SCREW 4 PCS PARTS RIDE ON BODY WHEEL... -
Page 7: Product Assembly
PARTS SIDE MIRRORS (L/R) 12V CHARGER REMOTE CONTROL 1 SET 1 PC 1 PC PRODUCT ASSEMBLY Place the part A ride on body topside down on a flat covered surface to prevent scratches, then cut the zip tie holding down the rear suspension frame. - Page 8 PRODUCT ASSEMBLY Locate and remove the pre-attached hardware on the front axle, then set the hardware aside. NOTE: Do not remove the final washer set on the axle. DO NOT DO NOT REMOVE REMOVE Attach two part B wheels to the front axle and use the previously removed nuts and washers to secure.
- Page 9 PRODUCT ASSEMBLY Locate and remove the zip ties securing the rear motos, then use two part 1 screws to secure the rear bracket. Remove the pre-attached hardware from the rear axle, then set the hardware aside. DISPOSABLE DISPOSABLE...
- Page 10 PRODUCT ASSEMBLY Carefully mount the right and left motors onto the rear axle, taking care not to dislodge the terminal wires and mounting the body of the motors into the recesses on the part A ride on body. Attach two part B wheels to the rear axle and use the previously removed nuts and washers to secure.
- Page 11 PRODUCT ASSEMBLY With a second person, carefully flip the ride on assembly upright. Locate the power terminal under the seat and connect the power terminals as shown. Place the part D steering wheel over the steering yoke, press until secured. NOTE: To remove the steering wheel, squeeze the two pressure latches on the yoke and lift.
- Page 12 PRODUCT ASSEMBLY Attach the part E seat to the part A ride on body, press until you hear an audible click, then secure the two pre-attached screws on the seat. Attach to the part F backrest to the part Attach the part G side mirrors to the part E seat, then secure with two part 1 screws.
-
Page 13: Remote Control
REMOTE CONTROL INDICATOR LIGHTS TURN LEFT FORWARD TURN RIGHT REVERSE PARK/STOP SPEED SELECT • Remote control operation will OVERIDE manual operation; the pedal will not work when operating the remote control. • After a period of non-operation, the remote will go into power-saving mode. Linking the remote control: 1. - Page 14 MP3 PLAYER DIAGRAM MODE Voltage Display Screen: The value on the display determines whether the battery needs to be charged. Previous Channel/Volume Down: Short press to play the previous channel, long press to lower the volume. Play/Pause: Short press this button to pause or play music. NOTE: in FM mode, long press this button to search radio stations.
-
Page 15: Charging Instructions
CHARGING INSTRUCTIONS Locate the charging connector under the seat. Disconnect the power supply from the control terminal. Connect the part H charger to the power supply, then plug the other end into a wall outlet. Charge the battery 12 hours before initial use (Do not charge for a period exceeding 20 hours). When fully charged, unplug part H charger from the wall outlet, then remove the charger from the charging port. -
Page 16: Charging Notice
CHARGING NOTICE • On average, you will need to charge the battery between 8 and 12 hours. Do not charge the battery for more than 20 hours. Failure to charge the battery as directed could cause permanent damage to the battery and void the warranty. -
Page 17: Fastening The Seatbelt
FASTENING THE SEAT BELT NOTE: Ensure that seat belts fit comfortably and snugly over the child's shoulder and across their chest. Fasten seat belt: Unfasten seat belt: Adjust seat belt: LENGHTEN SHORTEN... -
Page 18: Troubleshooting
TROUBLESHOOTING PROBLEM REASON SOLUTION Low battery Fully charge the battery Stop use for several minutes and restart Electrical protection Vehicle does not move Completely press in switches Switch not in the correct position Battery connectors disconnected Plug in battery connectors Battery connectors disconnected Plug in battery connectors Battery does not recharge... -
Page 19: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This product may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 20: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
