- Page 1 INSTRUCTION MANUAL 12V Ford Lightning Truck Ride On SKY9309 + SKY9310 + SKY9311 + SKY9312 + SKY9313 Ver. 1...
- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
- Page 3 Charge for 12 hrs before initial use. After initial charge, follow the normal recommended charging time. bestchoiceproducts.com...
-
Page 4: Battery Warnings
SAFETY Please retain these instructions for future reference. This vehicle must be assembled by an adult who has read and understood the instructions in this manual. Keep the packaging and bags away from children and dispose of all packaging before use. Always use common sense and safe practices when operating this vehicle. -
Page 5: Specifications
To reduce the risk of injury, adult supervision is required. Never use on roadways, near motor vehicles, on or near steep inclines or steps, swimming pools or other bodies of water; always wear shoes, and never allow more than one rider. •... -
Page 6: Tools Required
TOOLS REQUIRED AA - 2 AA BATTERIES (FOR REMOTE) AAA - PHILLIPS 66 LBS 2 PERSON UP TO 45 MIN. 2 AAA BATTERIES PLASTIC WRENCH SCREWDRIVER ASSEMBLY ASSEMBLY CAPACITY (FOR STEERING WHEEL) (PROVIDED) (2) (NOT PROVIDED) HARDWARE SELF TAPPING SCREWS 2 PCS PARTS REAR AXLE... - Page 7 PARTS SEAT BACKREST WINDSHIELD 1 PC 1 PC 1 PC TAIL FRAME SIDE MIRROR 12V CHARGER 2 PCS 1 PC 2 PCS REMOTE CONTROL 1 PC...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY Place the part A ride on body topside down on a flat covered surface to prevent scratches, then part G windshield, part B rear axle, part E front axle, cut the zip ties holding down the and the part F steering wheel. - Page 9 PRODUCT ASSEMBLY Locate and remove the pre-attached hardware on the front axle, then set the hardware aside. Carefully slide the part B rear axle through the right and left motors. Attach two part C wheels to the part B rear axle and use the previously removed nuts and washers to secure.
- Page 10 PRODUCT ASSEMBLY Locate the steering wheel yoke, and remove the nut attached to it, then set aside. Locate the part E front axle and remove the pre-attached nuts from the mounting stakes, set the hardware aside, then mount the part E front axle onto the square pipe of the part A ride-on body.
- Page 11 PRODUCT ASSEMBLY Secure the axle with the previously removed nuts and be sure to thread the steering wheel yoke through the opening and secure with the previously removed nut. Remove the pre-attached hardware from the part E front axle, then set the hardware aside. *Keep this one, not need to remove.
- Page 12 PRODUCT ASSEMBLY Attach two part C wheels to the part E front axle and use the previously removed nuts and washers to secure. Cover each wheel with one part D wheel cover. With a second person, carefully flip the ride on assembly upright. part F steering wheel Locate the then use a Philips screwdriver to open the battery access on...
- Page 13 PRODUCT ASSEMBLY Remove the bolt on the side of the part F steering wheel’s shaft, make sure to keep the fastening nut in place. Place the part F steering wheel over the steering yoke, then replace the bolt to secure. Don’t remove the nut! Attach the part G windshield to the part A ride on body, press down until secured.
- Page 14 PRODUCT ASSEMBLY Attach the part H seat to the part A ride on body, press until you hear an audible click, then secure the pre-attached screws with a Philips screwdriver. Attach to the part I backrest to the part H seat, then secure with two part 1 screws.
- Page 15 PRODUCT ASSEMBLY Insert two part J tail frames into the receivers at the rear of the part A ride on body, press down until secured. Attach the part K side mirrors to the part A ride on body.
-
Page 16: Remote Control
REMOTE CONTROL INDICATOR LIGHTS FORWARD TURN LEFT TURN RIGHT REVERSE SPEED STOP/ SELECT PARK Remote control operation will OVERIDE manual operation; the pedal will not work when operating • the remote control. • After a period of non-operation, the remote will go into power-saving mode. •... -
Page 17: Control Board Diagram
CONTROL BOARD DIAGRAM 11 12 13 TUNE START STOP High MODE Tune: FM radio search, press to find FM radio channels. FM: Press to enter FM Radio Mode. Mode: Press to toggle between start sound, the media player, Bluetooth, and the aux input. Forward: Press to make the car move forward when the foot pedal is pressed. -
Page 18: Charging Instructions
CHARGING INSTRUCTIONS 1. Locate the charging connector under the seat. 2. Disconnect the power supply from the control terminal. part L charger 3. Connect the to the power supply, then plug the other end into a wall outlet. 4. Charge the battery 12 hours before initial use (Do not charge for a period exceeding 20 hours). part L charger 5. -
Page 19: Charging Notice
CHARGING NOTICE • On average, you will need to charge the battery between 8 and 12 hours. Do not charge the battery for more than 20 hours. Failure to charge the battery as directed could cause permanent damage to the battery and void the warranty. -
Page 20: Fastening The Seatbelt
FASTENING THE SEAT BELT NOTE: Ensure that seat belts fit comfortably and snugly over the child's shoulder and across their chest. Fasten seat belt: Unfasten seat belt: Adjust seat belt: LENGHTEN SHORTEN CALIFORNIA PROPOSITION 65 WARNING: Battery posts, terminals, and related accessories can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm, and are toxic and corrosive. -
Page 21: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This product may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 22: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
