- Page 1 Brake Cylinder JSC4 Series (ø125 to ø180) INSTRUCTION MANUAL SM-482241-A/2 INSTRUCTION MANUAL SM-358642 • Read this Instruction Manual before using the product. • Read the safety notes carefully. • Keep this Instruction Manual in a safe and convenient place for future reference.
-
Page 2: Preface
• Since there are a wide variety of customer applications, it is impossible for CKD to be aware of all of them. Depending on the application or usage, the product may not be able to exercise its full performance or an accident may occur due to fluid, piping, or other conditions. -
Page 3: Safety Information
SM-482241-A/2 SAFETY INFORMATION SAFETY INFORMATION When designing and manufacturing any device incorporating the product, the manufacturer has an obligation to ensure that the device is safe. To that end, make sure that the safety of the machine mechanism of the device, the fluid control circuit, and the electric system that controls such mechanism is ensured. -
Page 4: Table Of Contents
SM-482241-A/2 CONTENTS CONTENTS PREFACE ........................... i SAFETY INFORMATION ....................ii CONTENTS ........................iii PRODUCT OVERVIEW ..................... 1 Model Number Indication ..................1 1.1.1 Product model number ................... 1 1.1.2 Brake unit model number ................3 1.1.3 Switch model number ..................3 Specifications ...................... -
Page 5: Product Overview
SM-482241-A/2 1. PRODUCT OVERVIEW 1. PRODUCT OVERVIEW 1.1 Model Number Indication 1.1.1 Product model number Example of model number indication <Without switch> <With switch> Note 1 (a) Model no. (b) Mounting style (c) Bore size (mm) (d) Port thread Double-acting, φ125 JSC4-N... - Page 6 SM-482241-A/2 1. PRODUCT OVERVIEW Note3: (g) Switch model no. (g) Switch model no. Lead wire outlet direction Contact Lead wire Straight type Angled type T0H□ T0V□ T5H□ T5V□ Reed 2-wire T8H□ T8V□ T1H□ T1V□ 2-wire T2H□ T2V□ T3H□ T3V□ 3-wire T3PH□...
-
Page 7: Brake Unit Model Number
SM-482241-A/2 1. PRODUCT OVERVIEW 1.1.2 Brake unit model number Bore size (See (c) on page 1) 1.1.3 Switch model number T type switch model number <Switch body + Mounting bracket set> <Switch body only> Switch model number Bore size Switch model number (See (g) on page 2) (See (c) on page 1) -
Page 8: Specifications
SM-482241-A/2 1. PRODUCT OVERVIEW 1.2 Specifications 1.2.1 Product specifications Model no. JSC4-N JSC4-H JSC4-T Descriptions JSC4-LN JSC4-LH Bore size ø125 ø140 ø160 ø180 ø125 ø140 ø160 ø180 ø125 ø140 ø160 ø180 Double acting/ Double acting/ Double-acting Actuation low hydraulic heat-resistant Note 1 Compressed air Hydraulic fluid... -
Page 9: Switch Specifications
SM-482241-A/2 1. PRODUCT OVERVIEW 1.2.2 Switch specifications Variation, model no. Reed 2-wire type Descriptions T0H/V T5H/V T8H/V For programmable controller, For programmable relay, IC circuit Applications For programmable controller, relay controller, relay (without indicator), serial connection Power supply voltage Load voltage 12/24 VDC 110 VAC 5/12/24 VDC... - Page 10 SM-482241-A/2 1. PRODUCT OVERVIEW Variation, model no. Proximity 3-wire type Descriptions T3H/V T3YH/V T3WH/V Applications For programmable controller, relay Power supply voltage 10 VDC to 28 VDC Load voltage 30 VDC or less Load current 100 mA or less 50 mA or less Current consumption 10 mA or less at 24 VDC Internal voltage drop...
-
Page 11: Installation
SM-482241-A/2 2. INSTALLATION 2. INSTALLATION 2.1 Environment • Use the product within the following ambient temperature ranges: −10°C to 60°C (no freezing) JSC4-N (standard type) JSC4-H (low hydraulic type) 5°C to 50°C JSC4-T (heat-resistant type) 5°C to 120°C • When using the product in a dusty environment, use a cylinder equipped with bellows. •... -
Page 12: Mounting
• When the cylinder is secured and the rod end guide is used, connect the rod end guide with a free joint (spherical bearing) manufactured by CKD to align the centers of the cylinder piston rod and the load. If the centers are not aligned, bushings and packings of the cylinder may become worn. -
Page 13: Mounting The Switch
SM-482241-A/2 2. INSTALLATION 2.3.1 Mounting the switch Mounting position <Mounting the switch at the end of the stroke> For the switch to function at maximum sensitivity, mount the switch so that its end face is in contact with either the rod cover or the head cover. In addition, mount the switch in the direction as shown in the figure below so that the lead wire is inside. -
Page 14: Changing The Position Of The Switch
SM-482241-A/2 2. INSTALLATION Minimum stroke with switch The table below shows the minimum stroke necessary for the switch to operate properly. (Unit: mm) Item Stroke for when mounted on the same surface Stroke for when mounted with the center trunnion Outline Port Port... -
Page 15: Securing The Switch
SM-482241-A/2 2. INSTALLATION 2.3.3 Securing the switch Mount the switch to the switch holder and secure them to the mounting base with M4 x 10 pan Philips screwdriver Tightening torque head screw. 1.5 N·m to 1.9 N·m Lightly insert two hexagon socket head screws Pan head screw M4 Finely adjustable into the holes in the mounting base and insert the... -
Page 16: Piping
SM-482241-A/2 2. INSTALLATION 2.4 Piping 2.4.1 Basic circuit Observe the following basic matters and set up a circuit by referring to the figures shown below to operate the product properly. • While the cylinder is stopped, make sure that both ends are pressurized (to prevent the piston rod from popping out when the cylinder starts moving). -
Page 17: Piping
SM-482241-A/2 2. INSTALLATION 2.4.2 Piping • Use pipes that are made of corrosion-resistant materials after the filter such as zinc-plated pipes, nylon tubes, and rubber tubes. • Use pipes with an effective cross-sectional area that allows the cylinder to achieve the predetermined piston speed. -
Page 18: Wiring
SM-482241-A/2 2. INSTALLATION 2.5 Wiring 2.5.1 Electric control circuit Since the control device and the circuit to be used affect the stopping accuracy, observe the following instructions: • Use a device with excellent accuracy that has a control circuit with short response time. •... -
Page 19: Reed Switch
SM-482241-A/2 2. INSTALLATION 2.5.2 Reed switch Connection of lead wires Do not connect the lead wire of the switch to the power directly. Make sure that the lead wire and the load are connected in serial. For T0 and T8 switches, observe the following instructions as well: •... -
Page 20: Serial Connection
SM-482241-A/2 2. INSTALLATION Contact capacity Do not use a load that exceeds the maximum contact capacity of the switch. If the current falls below the rated current value, the indicator may not light up. Relay Use one of the following or equivalent relays: •... - Page 21 SM-482241-A/2 2. INSTALLATION Protection of the output circuit For the following cases, refer to the figures below and install a protection circuit: • When an inductive load (relay or solenoid valve) is connected and used: See Ex. 1 Use a surge absorption element since a surge voltage is generated when the switch is turned off. •...
- Page 22 SM-482241-A/2 2. INSTALLATION Connection to the programmable controller The connection method depends on the type of the programmable controller. Connect as shown below. Programmable controller Programmable controller Blue Brown Blue Brown Switch Switch Input Input termi- termi- nals nals Blue Brown Blue...
- Page 23 SM-482241-A/2 2. INSTALLATION Parallel connection Since the leakage current of a 2-wire type switch increases according to the number of connected units, check the input specifications of the programmable controller, which is a connected load, to determine the number of switches to connect. For the 2-wire type switch, the indicator may become dim or not light up. Although the leakage current of a 3-wire type switch increases according to the number of connected units, the leakage current is very small (10 μA or less) and can generally be ignored.
-
Page 24: Usage
SM-482241-A/2 3. USAGE 3. USAGE CAUTION Do not enter or put your hand in the operating area of the actuator when it is operating. 3.1 Using the Cylinder Working pressure range Use the cylinder within the following pressure range: Model Brake pressure range Cylinder pressure range... -
Page 25: Using The Switch
SM-482241-A/2 3. USAGE 3.2 Using the Switch Magnetic environment Do not use the switch in a place where there is a strong magnetic field or large current (such as a large magnet or welding machine). If switch mounted cylinders are installed close to each other and in parallel or if magnetic substances are moving close to the cylinder, the magnetic forces may interfere with each other and affect the detection accuracy. -
Page 26: Maintenance And Inspection
SM-482241-A/2 4. MAINTENANCE AND INSPECTION 4. MAINTENANCE AND INSPECTION WARNING Do not touch electrical wiring connections (bare live parts) of actuators equipped with solenoid valves, actuators equipped with switches, and other such actuators. Do not touch live parts with bare hands. An electric shock may occur. -
Page 27: Periodic Inspection
The brake is an important part of the product and must not be disassembled. To inspect the inside of the brake, contact CKD for an off-site inspection. 4.1.2 Maintenance of the circuit • Discharge the drainage accumulated in the air filter periodically before it exceeds the specified line. -
Page 28: Removing And Mounting
SM-482241-A/2 4. MAINTENANCE AND INSPECTION 4.2 Removing and Mounting Follow the procedure below to perform maintenance and repairs when a problem such as an air leakage occurs. 4.2.1 How to remove the brake unit Dust proof cover Remove the four cover mounting screws (cross Cross recessed pan head screw recessed pan head screws) with a Philips Bolt for manual... -
Page 29: How To Mount The Brake Unit
SM-482241-A/2 4. MAINTENANCE AND INSPECTION 4.2.2 How to mount the brake unit Mount the brake unit by following the steps in "4.2.1 How to remove the brake unit" in reverse order. Observe the following instructions when mounting: • Do not apply grease to the piston rod. (Greasing will weaken the holding force of the brake.) •... - Page 30 SM-482241-A/2 4. MAINTENANCE AND INSPECTION Parts list Part name Material Quantity Remarks Wear ring Polyacetal resin Piston packing B Cushion rubber Urethane rubber Spring Steel Coating Cross recessed pan head screw with washer Steel Zinc chromate Bearing Bearing pin Alloy steel E-type stop ring Alloy steel Zinc chromate...
- Page 31 SM-482241-A/2 4. MAINTENANCE AND INSPECTION Consumable parts are as follows. Specify the kit number when ordering. Consumable parts list Bore size (mm) Kit no. Consumable part no. ø125 JSC4-N-125K ø140 JSC4-N-140K 13, 22, 23, 26, 27, 30, 31, 36, 49 ø160 JSC4-N-160K ø180...
-
Page 32: Troubleshooting
SM-482241-A/2 5. TROUBLESHOOTING 5. TROUBLESHOOTING 5.1 Problems, Causes, and Solutions 5.1.1 Cylinder If the cylinder does not operate properly, check the table below for a possible solution. Problem Cause Solution No pressure or insufficient pressure is applied to Secure sufficient pressure. brake. - Page 33 (external cushion mechanism) Install a guide. Lateral load is applied. Correct the way the cylinder is mounted. Change the mounting style. If you have any other questions or concerns, contact your nearest CKD sales office or distributor. 2018-11-12...
-
Page 34: Switch
Install a magnetic shield. External signal is faulty. Check the external circuit. * For how to replace or reposition the switch, refer to "2.3 Mounting". If you have any other questions or concerns, contact your nearest CKD sales office or distributor. 2018-11-12... -
Page 35: Warranty Provisions
If the product specified herein fails for reasons attributable to CKD within the warranty period specified below, CKD will promptly provide a replacement for the faulty product or a part thereof or repair the faulty product at one of CKD’s facilities free of charge.
