- Page 1 USER MANUAL 3-Zone Water Timer Model No. ITV305 Save the user manual for future reference If you have any questions, please contact us to get support.
-
Page 2: Please Read Before Use
Warm Tips Please read before use： Don’t use the water timer when the temperature is below 37.4°F (3°C), and please store the timer indoors to avoid potential freezing damage. The filter traps dirt particles, preventing them from entering the timer and causing clogging. Please clean the filter regularly and replace it if worn. -
Page 3: Table Of Contents
Contents Contents in the box Introduction 2.1 Product Overview 2.2 Button Function Introduction 2.3 Specification Timer Programming 3.1 Install The Timer Bracket 3.2 Programming Your Timer 3.3 Additional Functions 3.4 Working In Different Programs 3.5 Cleaning Your Timer Troubleshooting Precautions Warranty Policy Customer Support... -
Page 4: Contents In The Box
1. Contents in the box ITV305 3-Zone Water Timer Sealing tap Spare rubber washer User Manual Warranty Card Quick Guide -01-... -
Page 5: Introduction
2. Introduction 2.1 Product Overview FILTER WATER INLET SETTING DIAL SCREEN DELAY / + BUTTON MANUAL - BUTTON BUTTON WATER ZONE OUTLETS BUTTON 2.2 Button Function Introduction DIAL FUNCTIONS DIAL Turn the dial to set the watering plans and save the settings Run the timer as scheduled Turn off the timer SET CLOCK... -
Page 6: Specification
Button Functions OK/MANUAL Confirm settings or water manually BUTTON +/DEALY Adjust settings,choose rain delay time or select zone BUTTON Adjust settings,choose rain delay - BUTTON time or deselect zone ZONE Switch watering zone when setup BUTTON 2.3 Specifiction Inlet Thread: NH(US) for 3/4" faucet, BSP(EU) for 3/4"... -
Page 7: Timer Programming
3. Timer Programming 3.1 Product Installation 3.1.1 Installing The Batteries Remove the battery compart- ment at the bottom of the timer. Insert 4 new AA (1.5V) alkaline batteries (not included). Put the battery compartment back to the timer and press firmly to make sure it is completely sealed. -
Page 8: Installing The Timer
3.1.2 Installing The Timer Turn off the garden faucet. Wrap Teflon Tape around the faucet threads. Screw the timer to the garden faucet and make the display as vertical as possible to the ground to prevent rainwater from accumulating and leaking into the interior. - Page 9 Tips: lf the connection between the timer and the faucet or hose is not tight or leaking, wrap more Sealing tap (thread seal tape) to make them tight. Note: Please do not use tools, only install the timer by hand. When expecting freezing temperatures, timers should be removed from the hose faucet and stored indoors to avoid potential freeze damage.
- Page 10 3.1.3 Activate The Timer Before Use Please active the valves when getting the timer for the first time, or it's been a long time since your last time to use it. Keep the faucet off and turn the dial to "ON". Press and hold the "OK/ MANUAL"...
-
Page 11: Programming Your Timer
3.2 Programming The Timer This three-zone timer allows you to water three different areas using a single faucet, with each zone customizable for indepen dent start times, irrigation durations, and frequencies. Note: Single Zone Operation: The device can only run one zone's program at a time;... - Page 12 STEP 1: SET CLOCK Turn the dial to "SET CLOCK". Use the "+" or "-" buttons to select either the 24H or 12H format, then press the "OK" button to confirm and enter the time setting. The hour number flashes. Use the "+" or "-" buttons to adjust the number to your local time.
- Page 13 STEP 2: START TIME Turn the dial to "START TIME". The hour flashes, use the "+" and "-" buttons to set your start time. Use the "OK" button to switch between hours or minutes. Rotate the dial clockwise to save the changes and proceed to the next step.
- Page 14 STEP 3: HOW LONG Turn the dial to "HOW LONG". The hour flashes. Use the "+" and "-" buttons to select the watering duration, ranging from 1 minute to 4 hours. Use the "OK" button to confirm and switch between hours or minutes.
- Page 15 STEP 4: HOW OFTEN Turn the dial to "HOW OFTEN". Use the "+" and "-" buttons to set your watering frequency. You can choose every 1 to 12 hours or every 1 to 7 days. Rotate the dial clockwise to save the changes and proceed to the next step.
- Page 16 STEP 5: AUTOMATIC WATERING Next Plan For Zone 1 Next Plan For Zone 2 Next Plan For Zone 3 Turn the dial to "ON". The LCD will display the current time and automatically switch to show program details for each of the three zones. CONGRATULATIONS! Your timer has now been programmed successfully.
-
Page 17: Additional Functions
3.3 Additional Functions Manual Watering Select ZONE 1 Select ZONE 1 and ZONE 3 Manual water Manual watering duration setting -14-... - Page 18 Turn the dial to "ON". Press and hold the "MANUAL" button for 3-5 seconds to enter manual watering mode. Press the "ZONE" button to switch zones, use the "+" button to select a zone, and the "-" button to deselect a zone. After making your selections, press the "OK"...
- Page 19 Note: Remember to press the "OK" button after setting the manual watering duration in order to start manual watering, otherwise, the manual watering settings will automatically exit after approximately 3-5 seconds of flashing on-screen. If you do not select a zone and press "OK" to enter the manual watering time setting, then press "OK"...
-
Page 20: Delay Mode
Delay Mode When dial at "ON", press and hold "+/DELAY" button for 3 sec to enter into rain delay mode interface. When default time "24H" is flashing, press "+" and "-" buttons to adjust time between 0H, 24H, 48H and 72H. Select 0H means cancel delay mode. - Page 21 Note: After selecting the rain delay duration, you need to press the "OK" button to activate the rain delay program. Otherwise, the rain delay settings will automatically exit after flashing on the screen for 3-5 seconds. Rain delay mode cannot be paused once started. To stop the rain delay program, press and hold the "DELAY"...
-
Page 22: Off Mode
Off Mode If you wish to stop all watering plans for an extended period, turn the dial to "OFF". The timer will not water automatically while in OFF mode, but timer still saves your setted programs. Once you turn the dial to "ON", the setted programs will work again. -
Page 23: Working In Different Programs
3.4 Working In Different Programs Automatic Watering for 3 Zones Your Timed Watering Plan Real Working Real Start Finish Valve Start Time How Long Time Watering Time Zone 1 7�00 20 minutes 7�00 7�20 Zone 2 7�00 20 minutes 7�20 7�40 Zone 3 6�00... - Page 24 Different Watering Frequency Start How timer works in Next Start time often different frequency time Next start time 8�00 AM 16�00 PM = start time + 8H Next start time 8�00 AM 20�00 PM = start time + 12H Next start time 8�00 AM 8�00 AM 1 Day...
- Page 25 Manual Watering for 3 Zones Your Manual Watering Plan Real Working Finish Real Start Valve Start Time How Long Watering Time Time 20 minutes Zone 1 9�00 9�00 9�20 Zone 2 9�00 20 minutes 9�20 9�40 Zone 3 9�00 20 minutes 9�40 10�00 If you set manual watering mode for 3 zones as above, how...
- Page 26 Timed Watering meets Manual Watering Start Valve Mode Really Run Time Long Run automatic Timed watering Zone 1 7�00 watering program minutes mode every day from 7�00~7�10 Run manual Manual watering watering program Zone 2 7�10 minutes mode only today from 7�10~7�40 Run automatic Timed watering...
-
Page 27: Cleaning Your Timer
3.5 Cleaning Your Timer After a period of use, impurities or dirt in the water may accumu- late in the timer. Therefore, the timer should be cleaned regularly to ensure its proper operation. Please follow these steps to clean the timer. Turn off the garden faucet and remove the timer. -
Page 28: Troubleshooting
4. Troubleshooting Problem Possible Factors Solution may help Condensation Air condenses inside The fog will disappear on the screen the screen due to the as the temperature difference in tempera- rises, or leave it stand ture between inside for a period of time. and outside. -
Page 29: Precautions
5. Precautions Intended for outdoor use only, put in the sheltered outdoor will prolong the product lifetime. Using tools to secure the timer can lead to over-tightening and damage to the timer. Please do not use tools to install the timer;... -
Page 30: Warranty Policy
To place a warranty request, please email your order lD to support@rainpointonline.com and we'll respond within 24 hours. 7. Customer Support Still have trouble with setup, please search for "RainPoint" on YouTube for installation videos ! lf the user manual doesn't have what you're looking for or you need some help, please prepare the LOT NO. -
