USER MANUAL
1-Zone Water Timer
Model No. ITV105-DLS
Save the user manual for future reference. If you have any
questions, please contact us to get support.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITV105-DLS and is the answer not in the manual?

Questions and answers

Related Manuals for RainPoint ITV105-DLS

Summary of Contents for RainPoint ITV105-DLS

  • Page 1 USER MANUAL 1-Zone Water Timer Model No. ITV105-DLS Save the user manual for future reference. If you have any questions, please contact us to get support.

  • Page 2: Please Read Before Use

    Warm Tips Please read before use： Don’t use the water timer when the temperature is below 37°F (3°C), and please store the timer indoors to avoid potential freezing damage. The filter traps dirt particles, preventing them from entering the timer and causing clogging. Please clean the filter regularly and replace it if worn.

  • Page 3: Table Of Contents

    Contents Contents in the box Introduction 2.1 Product Overview 2.2 Specification Timer Programming 3.1 Product Installation 3.2 Programming Your Timer 3.3 Additional Functions 3.4 Cleaning Your Timer Troubleshooting Precautions Warranty Policy Customer Support...

  • Page 4: Contents In The Box

    1. Contents in the box ITV105-DLS 1-Zone Water Timer User Manual Quick Guide Eflon Sealing Tape Sealing Ring Warranty Card -01-...

  • Page 5: Introduction

    2. Introduction 2.1 Product Overview FILTER HOSE TAP CONNECTION BIG LCD DIAL SCREEN OK/MANUAL DELAY/+ BUTTON BUTTON OUTLET - BUTTON DIAL: Rotate the dial to customize your watering schedule. OK/MANUAL BUTTON: Use "OK" to confirm the time. When the dialis turned to "ON", press and hold "MANUAL"...

  • Page 6: Specification

    DIAL POSITION FUNCTION Set the current time (US SET CLOCK defaults to 12 hour clock). Select what time you would START TIME like to start watering. Determine how long to HOW LONG water (water duration). Choose how often you will HOW OFTEN water (water frequency).

  • Page 7: Timer Programming

    3. Timer Programming 3.1 Product Installation 3.1.1 Installing The Batteries Remove the battery compartment cover on the back of the timer. Insert 2 new AAA (1.5V) alkaline batteries (not included). Put the battery compartment cover back on the timer and press firmly to make sure it is completely sealed.

  • Page 8: Installing The Timer

    3.1.2 Installing The Timer Turn off the garden faucet. Wrap Teflon Tape around the faucet threads. Screw the timer to the garden faucet and make the display as vertical as possible to the ground to prevent rainwater from accumulating and leaking into the interior.
  • Page 9 Tips: If the connection between the timer and the faucet or hose is not tight or leaking, wrap more Teflon Tape(thread seal tape) to make them tight. Note: Please do not use tools, only install the timer by hand. When expecting freezing temperatures, timers should be removed from the hose faucet and stored indoors to avoid potential freeze damage.

  • Page 10: Activation Steps

    If yes, the timer valve is normal, please use it with confidence! If not, please repeat the above steps several times or contact RAINPOINT support team immediately. Note: When testing, please keep away from the water timer outlet to avoid being splashed and wet.

  • Page 11: Programming Your Timer

    3.2 Programming Your Timer STEP 1: SET CLOCK Turn the dial to SET CLOCK. Use "+'' or "-" button to select 24-hour or 12-hour format and press "OK" button to confirm. Use the "OK" button to confirm and switch between hours or minutes.

  • Page 12: Step 2: Start Time

    STEP 2: START TIME Turn the dial to "START TIME". Press the "+" and "-" buttons to set the time you want to start watering. Use the "OK" button to switch Hours or Minutes. Turn the dial clockwise to save the changes in this STEP and go to the next STEP.

  • Page 13: Step 3: How Long

    STEP 3: HOW LONG Turn the dial to "HOW LONG". Press the "+" and "-" buttons to select watering duration. Use the "OK" button to switch Hours or Minutes. Turn the dial clockwise to save the changes in this STEP and go to the next STEP.
  • Page 14 STEP 4: HOW OFTER Turn the dial to "HOW OFTEN". Press "+" and "-" buttons to set your watering frequency. Turn the dial clockwise to save the changes in this STEP and go to the next STEP. Examples of watering frequency of every 1 day, every 2 days and every 3 days: SUNDAY MONDAY...

  • Page 15: Step 5: Automatic Watering

    Step 5: Automatic Watering Turn the dial to "ON". The LCD screen will display the current time and the next time to start watering. Current Time Next Watering Start Time CONGRATULATIONS！ Your timer has now been programmed successfully. It will start watering automatically based on the programmed start time, duration and frequency.

  • Page 16: Additional Functions

    3.3 Additional Functions RAIN DELAY Setting rain delay Performing rain delay 24/48/72H Rain delay allows you to postpone watering for a set period of time, and it will not interrupt your original schedule. To access the rain delay, follow the steps below. With the dial on "ON", press "DELAY"...
  • Page 17 MANUAL / HAND WATERING Setting manual watering Performing manual 1min~8hrs watering This function allows you to manually water without interrupting your set watering schedule. To access this feature, please follow the steps below. Turn the dial to "ON". Press and hold the "MANUAL" button for 3-5s to enter the Manual Watering Mode.

  • Page 18: Off Mode

    Note: Please remember to press the "OK" button after setting the manual watering time to start manual watering. Otherwise, the manual watering setting will be automatically exited after the screen flashes for about 3-5s. OFF MODE lf you wish to stop the watering plan for an extended period, turn the dial to "OFF".

  • Page 19: Cleaning Your Timer

    3.4 Cleaning Your Timer After a period of use, impurities or dirt in the water may accumulate in the timer. Therefore, the timer should be cleaned regularly to ensure its proper operation. Please follow these steps to clean the timer. Turn off the garden faucet and remove the timer.

  • Page 20: Troubleshooting

    4. Troubleshooting Problem Possible Cause Possible Solution The water No filter or not Add a filter and inlet be placed make sure it's placed leakage horizontally. horizontally in the The faucet is inlet. not the Make sure the standard 3/4" . faucet is a standard 3/4"...
  • Page 21 Problem Possible Cause Possible Solution Short Mixed use of Use new alkaline battery life old and new batteries. batteries. Rechargeable Use the carbon batteries and carbon batteries or batteries have a rechargeable short life, use the batteries. alkaline batteries. Low water Filter blockage.

  • Page 22: Precautions

    5. Precautions For outdoor use only. Placing the timer in the sheltered outdoors will prolong its lifetime. To avoid damage, please tighten it without using tools. The filter should be placed horizontally in the water inlet to prevent leakage. When low power, please replace the batteries to avoid the interruption of normal operation, when replacing the batteries, please make sure that the battery tray is dry.

  • Page 23: Warranty Policy

    ID at support@rainpointonline.com and we’ll respond within 24 hours. 7. Customer Support Still have trouble with setup , please search for " RainPoint " on Youtube for installation videos! If the user manual doesn’t have what you're looking for or you need other help, please contact us before returning the product to the store and let us know the LOT NO.

  • Page 24: Need Help

    Need Help ? Scan the QR code for more help. or Email： support@rainpointonline.com...
