- Page 1 USER MANUAL 2-Zone Water Timer Model NO. ITV205 Save the user manual for future reference. If you have any questions, please contact us to get support.
- Page 2 Warm Tips Please read before use： Don't use the water timer when the temperature is below 37.4°F (3℃), and please store the timer indoors to avoid potential freezing damage. The filter traps dirt particles, preventing them from entering the timer and causing clogging. Please clean the filter regularly and replace it if worn.
- Page 3 Contents Contents in the box Introduction 2.1 Product Overview 2.2 Specification Timer Programming 3.1 Product Installation 3.2 Programming Your Timer 3.3 Additional Functions 3.4 Cleaning Your Timer Trouble Shooting Precautions Warranty Policy Customer Support...
- Page 4 1. Contents in the box ITV205 2-Zone Water Timer User Manual Quick Guide Eflon Sealing Tape Warranty Card -01-...
- Page 5 2. Introduction 2.1 Product Overview FILTER HOSE TAP CONNECTION DIAL BIG LCD SCREEN DELAY/+ OK/MANUAL BUTTON BUTTON - BUTTON ZONE SWITCH BUTTON ZONE 1 ZONE 2 DIAL: The dial to customize your watering schedule; Save changes (settings). ZONE SWITCH BUTTON: Switch between ZONE 1 and ZONE 2.
- Page 6 DIAL POSITION FUNCTION Switch 12H/24H and set the SET CLOCK current time Set the first irrigation start START TIME time for each zone Determine how long to HOW LONG water fo reach zone Choose how often you will HOW OFTEN water for each zone Timer waters according to your customized schedule...
- Page 7 3. Timer Programming 3.1 Product Installation 3.1.1 Installing The Batteries Remove the battery compartment cover on the back of the timer. Insert 2 new AA (1.5V) alkaline batteries (not included). Put the battery compartment cover back on the timer and press firmly to make sure it is completely sealed.
- Page 8 3.1.2 Installing The Timer Turn off the garden faucet. Wrap Teflon Tape around the faucet threads. Screw the timer to the garden faucet and make the display is as vertical as possible to the ground to prevent rainwater from accumulating and leaking into the interior.
- Page 9 Tips: lf the connection between the timer and the faucet or hose is not tight or leaking, wrap more Teflon Tape (thread seal tape) to make them tight. Note: Please do not use tools, only install the timer by hand. When expecting freezing temperatures, timers should be removed from the hose faucet and stored indoors to avoid potential freeze damage.
- Page 10 If not, please repeat the step 2-5 several times or contact RAINPOINT support team immediately. Note: When testing, please keep away from the water timer outlet to avoid being splashed and wet.
- Page 11 3.2 Programming Your Timer STEP 0: UNDERSTANDING ZONES This is a two-zone timer that allows you to water two different areas from the same faucet. Each zone can be programmed with independent start time, duration and frequency. Note: Dual zones operating simultaneously have lower water pressure than single zone because the water pressure is divided between the two zones.
- Page 12 STEP 1: SET CLOCK Turn the dial to "SET CLOCK". Use "+" or "-" button to select 24-hour or 12-hour format and press "OK" button to confirm. Use "+" or "-" button to set the current exact time. lf you choose the 12-hour format, please note the AM and Use the "OK"...
- Page 13 STEP 2: START TIME Turn dial to "START TIME". Use "+" and "-" buttons to set your start time. Use "OK" button to switch time ( Hours or Minutes). Turn the dial clockwise to save the changes in this STEP and go to the next STEP.
- Page 14 STEP 3: HOW LONG Turn dial to "HOW LONG". Use "+" and "-" buttons to select watering duration, from 1 minute to 3 hours 59 minutes. Use "OK" button to switch to (Hours or Minutes). Turn the dial clockwise to save the changes in this STEP and go to the next STEP.
- Page 15 STEP 4: HOW OFTEN Turn dial to "HOW OFTEN". Use "+" and "-" buttons, to set your watering frequency. You can choose to water every 1 to 12 hours, or every 1 to 7 days. (NOTE: 1 is every day2 is every other day, etc.) Turn the dial clockwise to save the changes in this STEP and go to the next STEP.
- Page 16 STEP 5: AUTOMATIC WATERING Turn dial to "ON". The LCD screen will display the current time and the next watering start time in Zone 1, and then display the current time and the next watering start time in Zone 2. NOTE: The automatic watering program will only run when the dial is in the ON position.
- Page 17 CONGRATULATIONS! Your timer has now been programmed successfully! lt will automatically start watering based on the programmed start time duration and frequency. Now you can keep the faucet open and trust the timer to water! Note: Turning the dial and not in the ON state. It will stop all watering plans and will not start automatically.
- Page 18 3.3 Additional Functions RAIN DELAY MODE Turn the dial to Press the "+" or "-" Press the "OK" "ON", press and hold button to adjust the button to start the "DELAY" button delay watering time rain delay Rain delay allows you to postpone watering on both zones for a set period of time without interrupting your set watering schedule.
- Page 19 MANUAL/HAND WATERING Turn the dial Press the "ZONE" Press the "+" Press the "OK" to "ON", press button to select or "-" button to button to start and hold the the zone to be adjust the manual manual "MANUAL" watered watering time watering button...
- Page 20 Note: Please remember to press the "OK" button after setting the manual watering time to start manual watering. Otherwise, the manual watering setting will be automati- cally exited after the screen flashes for about 3-5s. USE ONLY ONE OF THE ZONES lf you want to use only ZONE 1 and close ZONE 2, please set it up as follows.
- Page 21 OFF MODE If you wish to stop all watering plan for an extended period, turn the dial to "OFF". (Your settings are saved) The timer will not water automatically while in OFF mode. (The screen will display the word OFF in large letters) To start watering automatically again, turn the dial back to "ON"...
- Page 22 3.4 Cleaning Your Timer After a period of use, impurities or dirt in the water may accumulate in the timer. Therefore, the timer should be cleaned regularly to ensure its proper operation. Please follow these steps to clean the timer. Turn off the garden faucet and remove the timer.
- Page 23 4. Trouble Shooting Lssue Possible Cause Advice The water No filter or not Add filter and make inlet be placed sure it' s placed leakage horizontally. horizontally in the The faucet is inlet. not the Right Make sure the faucet standard 3/4".
- Page 24 Lssue Possible Cause Advice Short Mixed use of Use brand new battery life old and new alkaline batteries. batteries. Rechargeable Used the batteries and carbon carbon batteries have a batteries or short and unstable rechargeable battery life, please batteries. use the alkaline batteries instead of them.
- Page 25 Lssue Possible Cause Advice The timer The dial turn to Rotate the dial to ON does not OFF position. position. water The faucet is After finishing all not turned on. settings turn on the The battery is faucet. dead, it shuts Replace with new down alkaline batteries.
- Page 26 Never immerse the product in water. 6. Warranty Policy RainPoint provides a 1-year warranty against manufacturing defects in materials and workmanship from the date of purchase. During the warranty period, well replace free of charge the product found to be defective under reasonable use and service as determined solely by RainPoint.
- Page 27 7. Customer Support Still have trouble with setup, please search for "RainPoint" on YouTube for installation videos! If the user manual doesn't have what you re looking for or you need other help, please contact us before returning the product to the store and let us know the LOT NO. of your device.
- Page 28 Need Help ? Scan the QR code for more help. or Email： support@rainpointonline.com...
