Steelcase Migration Desk Assembly Instructions
Steelcase Migration Desk Assembly Instructions

Steelcase Migration Desk Assembly Instructions

Metal tray with sarto privacy/modesty screens 60”+w

Advertisement

Quick Links

®
888.STEELCASE (888.783.3522)
www.steelcase.com
© 2024 Steelcase Inc.
Grand Rapids, MI 49501 U.S.A.
Ordered
DSBULKSTRP
Separately
Migration Desk Collection - Metal Tray with
Sarto Privacy/Modesty Screens 60"+W
This product contains magnet(s) located
as indicated by this symbol.
#2
Page 1 of 4
Doc # 168247 Rev A

Advertisement

loading
Need help?

Need help?

Do you have a question about the Migration Desk and is the answer not in the manual?

Questions and answers

Summary of Contents for Steelcase Migration Desk

  • Page 1 ® Migration Desk Collection - Metal Tray with Sarto Privacy/Modesty Screens 60”+W Ordered DSBULKSTRP Separately This product contains magnet(s) located as indicated by this symbol. 888.STEELCASE (888.783.3522) www.steelcase.com Page 1 of 4 © 2024 Steelcase Inc. Doc # 168247 Rev A...
  • Page 2 ® NOTICE Screen Tray Screws Do not mix screen and tray screws. Screws (Tray screws are 7/8” ( long; 22.25mm) screens have 1” long screws.) (25.4mm) 1" .875" (25.4mm) Tray Size: Hole Spacing (A) mm & Inches (22.25mm) Small (762mm / 30”) 709.5mm 28”...
  • Page 3 ® Install 2 front screws (1 at each end) partially into the worksurface, leaving enough space for the tray to slide over the head. Space screws L-R per the chart for the “slotted” holes. Flex/slide tray tabs over the screw head on either end to hang the tray.
  • Page 4 ® 25mm 25mm (1”) (1”) Rear Rear Cord Drop Cord Drop 4. Install the screen in the desired position: (4a) Place the magnet on the center bracket mounting location. (4b) Align the screen L-R where desired, ensuring it does not interfere with any other items on the worksurface.
