- Page 1 Operating instructions DALI-2 actuator Colour 4-gang Art. no. 300041SDA2R ALBRECHT JUNG GMBH & CO. KG Volmestraße 1 58579 Schalksmühle GERMANY Product image non-binding Telefon: +49 2355 806-0 Telefax: +49 2355 806-204 kundencenter@jung.de 05.12.2024 82408903 j0082408903 www.jung.de...
-
Page 2: Table Of Contents
DALI-2 actuator Colour 4-gang Table of contents Safety instructions ...................... 3 Device components ...................... 3 System information ...................... 4 Intended use ........................ 4 Product characteristics ..................... 4 Operation .......................... 5 Information for electrically skilled persons ................ 7 Mounting and electrical connection................ 7 Commissioning ...................... -
Page 3: Safety Instructions
DALI-2 actuator Colour 4-gang Safety instructions Electrical devices may be mounted and connected only by electrically skilled persons. Serious injuries, fire or property damage are possible. Please read and follow the manual fully. Danger of electric shock. Always disconnect before carrying out work on the device or load. -
Page 4: System Information
The device can be updated. Firmware can be easily updated with the Jung ETS Ser- vice App (additional software). -
Page 5: Operation
DALI-2 actuator Colour 4-gang – Control of up to 128 DALI devices in 4 DALI systems – Broadcast control of each of the four DALI systems – Setting the colour temperature or light colour (RGB, RGBW) for luminaires with DALI Device Type 8 in accordance with IEC 62386-209 –... - Page 6 DALI-2 actuator Colour 4-gang Switching on/off the permanent manual mode Operation using the button field is programmed and not disabled. ￭ Press the ǃ (1) button for at least 5 seconds. LED ǃ (2) lights up, LED (12) of the first DALI system flashes. Permanent manual operation is switched on.
-
Page 7: Information For Electrically Skilled Persons
DALI-2 actuator Colour 4-gang DALI systems blocked via manual operation can be operated in manual mode. Information for electrically skilled persons Mounting and electrical connection DANGER! Electric shock when live parts are touched. Electric shocks can be fatal. Always disconnect before carrying out work on the device or load. To do so, switch off all corresponding circuit breakers, secure them against being switched on again and check that there is no voltage. -
Page 8: Commissioning
DALI-2 actuator Colour 4-gang Figure 2: Connection example Commissioning The device can be put into operation, after mounting of the device and connection of the bus line, the mains supply and the DALI cables. The following procedure is gen- erally recommended... Commissioning the device ￭... - Page 9 DALI-2 actuator Colour 4-gang No ETS programming is possible if no mains voltage supply is connected. After each mains voltage return, the DALI actuator sends the DALI parameters (power ON level, system failure level ...) to all connected DALI devices. This means that when DALI operating devices are replaced, the DALI parameters within a DALI system are always configured the same.
- Page 10 5 s. Restoring the device to factory settings The device can be reset to factory settings with the Jung ETS Service App. This function uses the firmware contained in the device that was active at the time of de- livery (delivered state).
-
Page 11: Technical Data
DALI-2 actuator Colour 4-gang Technical data KNX medium TP 256 KNX commissioning mode S mode Rated voltage KNX DC 21 ... 32 V SELV Current consumption KNX 3 ... 4 mA Connection type for bus Device connection terminal Supply Rated voltage AC 110 ... -
Page 12: Accessories
DALI-2 actuator Colour 4-gang Storage temperature -5 ... +45 °C Transport temperature -25 ... +70 °C Clampable cable cross-sections (see figure 4) Figure 4: Clampable cable cross-sections Installation width 72 mm / 4 HP Terminals Connection mode Screw terminal Stripping length 8 mm Suitable tool Phillips screwdriver (recommended) -
Page 13: Warranty
DALI-2 actuator Colour 4-gang Exchange defective device. Warranty The warranty is provided by the specialist trade in accordance with statutory require- ments. ALBRECHT JUNG GMBH & CO. KG Volmestraße 1 58579 Schalksmühle GERMANY Telefon: +49 2355 806-0 Telefax: +49 2355 806-204 kundencenter@jung.de...
