Vektek Guardian 2.0 User Manual page 42

Specifications
Maintenance
The entire Guardian system is designed to be nearly maintenance free. There are two CR2
batteries in each FTU. Follow the instructions below to replace the batteries. Vektek does
recommend that the face of the Master Control Unit be cleaned periodically with a mild cleaner (i.e.
non-ammonia glass cleaner) to remove foreign matter from the screen. The Fixture Transmitter
and Pallet ID Reader should be inspected occasionally to check for damage to the enclosures.
PL3309 REV. A
IAW ECN-5581
PAGE 42 of 44
© Copyright 2025 by Vektek, LLC
@ Copyright 1986-2025 by Vektek LLC****
Guardian Specification Chart
Power
Frequency
Connection
Cable
MCU P/N
Fixture
Transmitter
33-0120-01
Capacity
Inputs
Outputs
Batteries
Fixture
Transmitter P/N
33-0120-30 Frequency
Unique MCU
Pairing Capacity
Input
Figure 71: Guardian Specifications
Negative
Case Ground
Power &
Inputs/Outputs
Number
Type
Rating
Number
Type
Rating (Total
for all outputs)
********** ****See Vektek.com>Products>Maintenance
+10-36 VDC
900 MHz
M12-12PIN
32.8ft
64 For Discrete
I/O
200 For Pallet ID
Reader
1
Sourcing/Sinking
10-36 VDC
2
Sourcing/Sinking
2 amps
QTY:2 CR2
LITHIUM
BATTERIES
900MHz
5
3 Pin M8
