  • Page 1 CV-100 Series User Manual Convertible Display Module 8.4“ - 24” TFT-LCD Display Module Version: V1.86...

  • Page 2: Table Of Contents

    1.3.8 CV-117R/CV-117C/CV-117G ..................29 1.3.9 CV-119R/CV-119C/CV-119G ..................31 1.3.10 CV-W121R/CV-W121C/CV-W121G ................33 1.3.11 CV-W124R/CV-W124C/CV-W124G ................35 Chapter 2 System Setup ........................37 2.1 Connecting with PC Module or Monitor Module ..............38 2.2 Installing Panel Mount ......................40 CV-100 Series | User Manual...

  • Page 3: Preface

    2025/03/24 Copyright Notice © 2014 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 4: Declaration Of Conformity

    Product Warranty Statement Warranty Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and workmanship for 2 years (2 Years for PC Module, 1 Year for Display Module) from the date of purchase by the original purchaser. During the warranty period, we shall, at our option, either repair or replace any product that proves to be defective under normal operation.

  • Page 5: Technical Support And Assistance

    Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain a RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service. ◼...

  • Page 6: Conventions Used In This Manual

    Make sure the voltage of the power source is correct before connecting the equipment to the power outlet. Use a power cord that has been approved for using with the product and that it matches the voltage and current marked on the product’s electrical range label. The voltage and current CV-100 Series | User Manual...

  • Page 7: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. CV-108R / CV-108C Item Description Q’ty CV-108 Display Module Panel Mounting Kit CV-100 Series | User Manual...

  • Page 8: Item Description

    Item Description Q’ty CV-112H Display Module Panel Mounting Kit CV-115R / CV-115C / CV-115C-AG Item Description Q’ty CV-115 Display Module Panel Mounting Kit CV-W115R / CV-W115C Item Description Q’ty CV-W115 Display Module Panel Mounting Kit CV-100 Series | User Manual...
  • Page 9 CV-W121 Display Module Panel Mounting Kit CV-W124R / CV-W124C / CV-W124G Item Description Q’ty CV-W124 Display Module Panel Mounting Kit Note: Notify your sales representative if any of the above items are missing or damaged. CV-100 Series | User Manual...

  • Page 10: Ordering Information

    CV-119R 19” TFT SXGA 5:4 Display Module with Resistive 5-wire Touch 21.5" TFT Full HD 16:9 Display Module with Resistive 5-wire CV-W121R Touch 24" TFT Full HD 16:9 Display Module with Resistive 5-wire CV-W124R Touch CV-100 Series | User Manual...
  • Page 11 19” TFT SXGA 5:4 Display Module with Projected Capacitive CV-119C Touch 21.5" TFT Full HD 16:9 Display Module with Projected CV-W121C Capacitive Touch 24" TFT Full HD 16:9 Display Module with Projected Capacitive CV-W124C Touch CV-100 Series | User Manual...
  • Page 12 17” TFT SXGA 5:4 Display Module with Glass CV-119G 19” TFT SXGA 5:4 Display Module with Glass CV-W121G 21.5” TFT Full HD 16:9 Display Module with Glass CV-W124G 24” TFT Full HD 16:9 Display Module with Glass CV-100 Series | User Manual...

  • Page 13: Chapter 1 Product Introductions

    Chapter 1 Product Introductions CV-100 Series | User Manual...

  • Page 14: Overview

    1.1 Overview CV-100 Series is LCD display module with resistive 5-wire touch, projected capacitive touch, or glass only (available on selected models). CV-100 Series features flat surface and IP65 dust/waterproof front panel. In addition, designed with aluminum die-cast front frame, it is rugged and reliable for industrial environment.

  • Page 15: Hardware Specification

    • EN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/m • EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V CV-100 Series | User Manual...
  • Page 16 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-108R/CV-108C...

  • Page 17: Cv-110R/Cv-110C

    • EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m CV-100 Series | User Manual...
  • Page 18 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-110R/CV-110C...

  • Page 19: Cv-110Hr/Cv-110Hc

    • EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m CV-100 Series | User Manual...
  • Page 20 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-110HR/CV-110HC...

  • Page 21: Cv-112Hr/Cv-112Hc

    • EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m CV-100 Series | User Manual...
  • Page 22 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-112HR/CV-112HC...

  • Page 23: Cv-115R/Cv-115C/Cv-115C-Ag

    • EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m CV-100 Series | User Manual...
  • Page 24 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-115R/CV-115C/CV-115C-AG...

  • Page 25: Cv-W115R/Cv-W115C

    • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz CV-100 Series | User Manual...
  • Page 26 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-W115R/CV-W115C...

  • Page 27: Cv-W115Fhr/Cv-W115Fhc

    • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m • EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz CV-100 Series | User Manual...
  • Page 28 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-W115FHR/CV-W115FHC...

  • Page 29: Cv-117R/Cv-117C/Cv-117G

    • EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV • EN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/m • EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV CV-100 Series | User Manual...
  • Page 30 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-117R/CV-117C/CV-117G...

  • Page 31: Cv-119R/Cv-119C/Cv-119G

    • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz CV-100 Series | User Manual...
  • Page 32 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-119R/CV-119C/CV-119G...

  • Page 33: Cv-W121R/Cv-W121C/Cv-W121G

    • EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV • EN/IEC 61000-4-6 CS: 3V • EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz CV-100 Series | User Manual...
  • Page 34 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-W121R/CV-W121C/CV-W121G...

  • Page 35: Cv-W124R/Cv-W124C/Cv-W124G

    • EN/BS EN IEC 61000-3-2 Harmonic current emissions: Class A • EN/BS EN61000-3-3 Voltage fluctuations & flicker • FCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A • EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV CV-100 Series | User Manual...
  • Page 36 Safety UL, cUL, CB, IEC, EN 62368-1 * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. Dimension CV-W124R/CV-W124C/CV-W124G Unit: mm...

  • Page 37: Chapter 2 System Setup

    Chapter 2 System Setup CV-100 Series | User Manual...

  • Page 38: Connecting With Pc Module Or Monitor Module

    The photos show the male connector (on display module) and female connector (on PC module or monitor module) PC module Monitor module CV-100 Series | User Manual...
  • Page 39 1. Connect the modules. 2. Fasten the 6 screws to fix the PC module or monitor module on the display module. CV-100 Series | User Manual...

  • Page 40: Installing Panel Mount

    2.2 Installing Panel Mount 1. Accessories provided by Cincoze are as follows. CV-100 Series | User Manual...
  • Page 41 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. CV-100 Series | User Manual...
  • Page 42 CV-100 Series | User Manual...
  • Page 43 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. CV-100 Series | User Manual...
  • Page 44 © 2014 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.
