  • Page 2: Table Of Contents

    CV-100 Series | User’s Manual Convertible Display Module Contents Prefaces Revision …………………………………………………..……………….….…….. 03 Copyright Notice …………………………………………………………………… 03 Acknowledgement ……………………………………………………..... 03 Disclaimer ………………………………………………………….……………….. 03 Declaration of Conformity ……………………………………….………………… 03 Product Warranty Statement ……………………………………….…………….. 04 Technical Support and Assistance ………………………………….……………. 04 Conventions Used in this Manual …………………………………….………….. 04 Safety Precaution …..…………………………………….…………….…………..

  • Page 3: Revision

    2014/10/20 Copyright Notice © 2014 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd.

  • Page 4: Product Warranty Statement

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain a RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service.

  • Page 5: Technical Support And Assistance

    | User’s Manual Convertible Display Module Prefaces Technical Support and Assistance 1. Visit the Cincoze website at www.cincoze.com/support.php where you can find the latest information about the product. 2. Contact your distributor or our technical support team or sales representative for technical support if you need additional assistance.

  • Page 6: Safety Precaution

    CV-100 Series | User’s Manual Convertible Display Module Prefaces Safety Precautions Before installing and using this device, please note the following precautions: 1. Read these safety instructions carefully. 2. Keep this User’s Manual for future reference. 3. Disconnected this equipment from any AC outlet before cleaning.

  • Page 7: Package Contents

    CV-100 Series | User’s Manual Convertible Display Module Prefaces Package Contents Before installation, please ensure all the items listed in the following table are included in the package. CV-108 Q’ty Item Description CV-108 Display Module Panel Mounting Kit CV-110 Q’ty...

  • Page 8: Ordering Information

    CV-100 Series | User’s Manual Convertible Display Module Prefaces Ordering Information Model No. Product Description 8.4” TFT SVGA 4:3 Display Module with Resistive 5-wire Touch CV-108R 10.4” TFT SVGA 4:3 Display Module with Resistive 5-wire Touch CV-110R 12.1” TFT SVGA 4:3 Display Module with Resistive 5-wire Touch CV-112R 15”...

  • Page 9: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 10: Overview

    CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions 1.1 Overview CV Series is LCD display module with resistive 5-wire or projected capacitive touch screen. CV Series features flat surface and IP65 dust/waterproof front panel. In addition, designed with aluminum die- cast front frame, it is rugged and reliable for industrial environment.

  • Page 11: Cv-108

    CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions 1.1.1 CV-108 Key Features • 8.4" SVGA TFT 4:3 LCD with Resistive 5-wire Touch • 30,000 hrs LED Backlight Life • Resolution up to 800 x 600 (SVGA) •...

  • Page 12: Cv-110

    CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions 1.1.2 CV-110 Key Features • 10.4" SVGA TFT 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch • 50,000 hrs LED Backlight Life • Resolution up to 800 x 600 (SVGA) •...

  • Page 13: Cv-112

    CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions 1.1.3 CV-112 Key Features • 12.1" SVGA TFT 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch • 50,000 hrs LED Backlight Life • Resolution up to 800 x 600 (SVGA) •...

  • Page 14: Cv-115

    CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions 1.1.4 CV-115 Key Features • 15" XGA TFT 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch • 50,000 hrs LED Backlight Life • Resolution up to 1024 x 768 (XGA) •...

  • Page 15: Cv-W115

    CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions 1.1.5 CV-W115 Key Features • 15.6" WXGA TFT 16:9 LCD with Resistive 5-wire / Projected Capacitive Touch • 50,000 hrs LED Backlight Life • Resolution up to 1366 x 768 (WXGA) •...

  • Page 16: Cv-117

    CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions 1.1.6 CV-117 Key Features • 17" SXGA TFT 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch • 50,000 hrs LED Backlight Life • Resolution up to 1280 x 1024 (SXGA) •...

  • Page 17: Cv-119

    CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions 1.1.7 CV-119 Key Features • 19" SXGA TFT 4:3 LCD with Resistive 5-wire / Projected Capacitive Touch • 50,000 hrs LED Backlight Life • Resolution up to 1280 x 1024 (SXGA) •...

  • Page 18: Mechanical Dimension

    CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions 1.2 Mechanical Dimensions Unit: mm CV-108...
  • Page 19 CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions Unit: mm CV-110...
  • Page 20 CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions Unit: mm CV-112...
  • Page 21 CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions Unit: mm CV-115...
  • Page 22 CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions Unit: mm CV-W115...
  • Page 23 CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions Unit: mm CV-117...
  • Page 24 CV-100 Series | User’s Manual Convertible Display Module Chapter 1: Product Introductions Unit: mm CV-119...

  • Page 25: Chapter 2 System Setup

    Chapter 2 System Setup...

  • Page 26: Connecting With Pc Module Or Monitor Module

    CV-100 Series | User’s Manual Convertible Display Module Chapter 2: System Setup 2.1 Connecting with PC Module or Monitor Module In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.
  • Page 27 CV-100 Series | User’s Manual Convertible Display Module Chapter 2: System Setup 2. Fasten the 6 screws to fix the PC module or monitor module on the display module.
  • Page 28 © 2014 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.
