TEMPLE & WEBSTER HTKIARBWS Assembly Instructions

Read these instructions and follow steps
carefully to ensure you assemble the
product correctly and avoid damages.
Check that all parts and hardware have
been provided before assembling the
products. Place all contents on a clean,
soft-flat surface to avoid scratching he
product.
CAUTION:
Only tighten bolts to 80% at first. Once all parts have
been assembled,fully tighten all hardware.
To prevent damage to threads, do not use a power
tool and do not over tighten bolts.
Use two people to lift and turn the product when
assembling.
Do not attempt with only one person and do not rail
onto legs.
Keep all hardware and small parts away from children.
Box of 1: Headboard(A), Footboard(B),
End rail
(O).
Box of 2: Siderail(C), Middle rail(D), Cross bar(E),Middle
cross bar(F),Support legs(G),U-bracket(H),Plywood slats(I),
post
Footboard (J),Headboard
Upper connect bar ,
(M) Hardware.
Please confirm you have all the parts listed before
commencing assembly.
ASSEMBLY INSTRUCTIONS
Plastc caps ,
(N)
post Canopy bar
(K), (L),
HTKIARBWS
ITEM DESCRIPTION
A
HEADBOARD
B
FOOTBOARD
C
SIDERAIL
D
MIDDLE RAIL
E
CROSS BAR
F
MIDDLE CROSS BAR
G
SUPPORT LEGS
H
U-BRACKET
I
PLYWOOD SLATS
J
FOOTBOARD POST
K
HEADBOARD POST
L
CANOPY BAR
M
UPPER CONNECT BAR
N
PLASTIC CAPS
O
END RAIL
HARDWARE LIST
ITEM DESCRIPTION
1
SCREW M6x13mm
2
SCREW M6x25mm
3
HEX NUTS M6
4
FLAT WASHER
5
SCREW M6x40mm
6
SPANNER
7
ALLEN KEY M4
8
ALLEN KEY M5
9
SCREW M8x55mm
10
SCREW M6x55mm
11
WASHER
PART LIST
QTY
1
1
2
1
2
1
3
2
12
2
2
2
3
24
1
QTY
12
8
12
31
9
1
1
1
10
12
24
