TEMPLE & WEBSTER HAALMLDTN Assembly Instructions Manual

Read these instructions and follow steps carefully to ensure you assemble
the product correctly and avoid damages. Check that all parts and
hardware have been provided before assembling the product. Place all
contents on a clean, soft-flat surface to avoid scratching the product.
CAUTION:
Only tighten bolts to 80% at first. Once all parts have been assembled, fully tighten all
hardware.
To prevent damage to threads, do not use a power tool and do not overtighten bolts.
Use two people to lift and turn the product when assembling.
Do not attempt with only one person and do not roll onto legs.
Keep all hardware and small parts away from children.
STEP 1: Attach the right leg (A1) to the seat (B), then insert the Bolt (2) and the nut (3), and
tighten with allen key (4) as below:
A1
2
3
2
4
4
ITEM DESCRIPTION
RIGHT LEG
A1
LEFT LEG
A2
SEAT
B
BACK 1
C
BACK 2
D
SEAT CUSHION
E
BACK PILLOW
F
B
2
ASSEMBLY INSTRUCTIONS
HAALMLDTN
PART LIST X 2
QTY
1PC
1PC
1PC
2PCS
1PC
1PC
1PC
STEP 2: Attach the back 1 (C) to the right legs (A1), then insert the screw (1) and tighten
with allen key (4) as bellow:
1
HARDWARE LIST X 2
ITEM DESCRIPTION
SCREW M6X60
1
BOLT M6X70
2
NUT M6X13
3
ALLEN KEY
4
C
C
1
QTY
4PCS
4PCS
4PCS
2PCS
