- Page 1 ASSEMBLY INSTRUCTIONS Hannon Office Chair...
- Page 2 Read first, enjoy forever Assembly tips ● Assemble your product on a level surface and lay something soft underneath to protect potential floor damage. ● Don’t over tighten screws. During assembly we recommend tightening to approximately 70% tightness. Only tighten hardware 100% when fully assembled. ●...
-
Page 3: Parts List
ASSEMBLY INSTRUCTIONS Parts list Hannon Office Chair SBHAOCCR NUMBER OF PEOPLE REQUIRED FOR ASSEMBLY: 8 x5 4 PCS 6 PCS 4 PCS 4 PCS 1 PCS Damaged or missing parts? Or just need help? Contact us on service@templeandwebster.com.au... - Page 4 Position Back Support right (3) and Back Support left (4) to the Seat (1), You will Loosely attach the Back Support to the Seat through holes shown using 6 x Screws (B) by Allen Key (E). need: 6 Screws 1 Allen Key Position Back (2) to the Back Support Right (3) and Back Support left (4), You will Fix theBack to both Back Support through holes shown...
- Page 5 Fasten all screws (B) with Allen Key (E). You will need: 1 Allen Key Position Seat Support (6) to the Seat (1), You will Fix the Seat Support to the Seat through holes shown need: us ing 4 x Screws (A) and 4 x Washers (D) by Allen Key (E). 4 Screws 4 Washers 1 Allen Key...
- Page 6 Fit 5 x Feet (8) on the Star Base (7) as shown. Remove the plastic cap from the top of the gaslift (5). Note: Please make sure you remove the plastic cap from the top of the gaslift before fitting to the Seat Plate. Assembly is complete.
- Page 7 Insert the Gas Lift (P5) into the centre hole of Star Base (P7). Cover the Cap (P9) to the Star Base (P7). Position Seat Body to Base Body as shown. Assembly is complete. Damaged or missing parts? Or just need help? Contact us on service@templeandwebster.com.au...
