U-Reach PRO398 User Manual

Sata 3.0 1 to 3 ultra-high speed hdd duplicator and sanitizer
Hide thumbs

Advertisement

Quick Links

Download this manual
SATA 3.0
1 to 3 Ultra-High Speed
HDD Duplicator and Sanitizer
User Manual
v A.04

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO398 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U-Reach PRO398

Summary of Contents for U-Reach PRO398

  • Page 1 SATA 3.0 1 to 3 Ultra-High Speed HDD Duplicator and Sanitizer User Manual v A.04...

  • Page 2: Table Of Contents

    PRO398 v A.03 Index Product Disclaimer ..................2 Warranty ....................2 Piracy Statement ..................2 Before You Start ..................3 Notice Symbols ..................3 Product Overview ..................4 Function Table ................... 5 Functions ....................8 1. Copy ....................8 2. Compare ................... 9 3.

  • Page 3: Product Disclaimer

    U-Reach is not accountable for any incidental or consequential damages, which includes, but is not constrained to property harm, loss of time or data from use of a U-Reach product, or any other damages attributable to product malfunction or failure (including without...

  • Page 4: Before You Start

    Before You Start Important Notice Carefully read the entire manual before operating. ● Make sure the source device is correct and functioning. ● Equal capacity of source and target is recommended for guaranteed data consistency. ● Using the Copy+Compare function provides the most flawless duplication. ●...

  • Page 5: Product Overview

    Product Overview Hardware overview  Red: Fail Flashing Green: Operating Remain Green: Pass Yellow: Powered Port 4 Port 1 (Target 3) (Source) Port 2 Port 3 (Target 1) (Target 2) UP: Backward OK: Confirm/OK DOWN: Forward ESC: Cancel/Back  LCD configuration Target HDD Total Size (Source)

  • Page 6: Function Table

    Function Table Function Description To copy source HDD to multiple target HDDs. Refer to function [6.1 Copy 1. Copy Area] for 4 different copy modes selection. 2. Compare To compare data bit for bit between source and target HDDs. 3. Copy It makes copy first and then compare target HDD with source HDD to +Compare ensure data correctness.
  • Page 7 5.4 Read Speed To show the speed of reading. 5.5 Write Speed To show the speed of writing. 6.1.1 System and Files To copy source HDD's data area only. 6.1.2 ALL Partitions To copy source HDD's all partitions. 6.1 Copy Area 6.1.3 Whole HDD To copy the whole source HDD.
  • Page 8 6.5.5 Wait HDD Time Auto start time after plugging HDD from 0~30 seconds. Do Not Copy HPA 6.5.6 HPA Copy Setting Target HPA Mode Copy and Setting Clear HPA Setting 6.5.7 Clear HPA at Erase Keep HPA Setting 6.5.8 Transfer Rate Select the proper transfer rate from UDMA2~UDMA7.

  • Page 9: Functions

    Functions 1. Copy Step 1: Prepare source and target devices. Recommendation: Target device(s)’ capacity must be equal to or larger than Note the source device capacity. Step 2: Connect source and target devices. Step 3: Proceed to copy. Scroll to select "1. Copy", then press "OK" to start the duplication process. The number of working/connected targets will be displayed on LCD.

  • Page 10: Compare

    2. Compare Proceed to verify device(s). Scroll to select "2. Compare", then press "OK" to start the verification process. The number of working/connected targets will be displayed on the LCD. Press Note "OK" to start. 3. Copy+Compare Sequentially automates from Function 1, Copy to Function 2, Compare. Scroll to select "3.
  • Page 11 User is responsible for verification of targets’ quality. Testing a few completed Caution targets in a mass production environment for quality control is recommended. 4.1 Quick Erase This function will erase the index table from the connected device(s). Scroll to select "4.1. Quick Erase”, then press "OK" to start the erasing process. 4.2 Full Erase This function will erase all data per NIST 800-88 Standards on the connected device(s).

  • Page 12: Utility

    4.7 Enhanced Secure Erase This function erases devices that supports this feature. Scroll to select "4.7 Enhanced Secure Erase", then press "OK" to start the erasing process. 5. Utility This menu contains submenus related to device information, system information and updates. Scroll to "5.

  • Page 13: Setup

    Update will take about a minute to complete. [Update System] 1. Update BIOS Please do not disrupt during BIOS update, otherwise it would Caution cause irretrievable error on duplicator. The manufacturer will not held responsible for any damages. 5.3 System Info. This function will display basic information such as controller, model number, software version, etc.
  • Page 14 Example: There are two defined partitions in a 500GB device. The charts below illustrate what portion would be duplicated. Whole Device System and files All Partitions 30GB Data 30GB Data 30GB Data 100GB 100GB 100GB 70GB 70GB 60GB Data 60GB Data 60GB Data 250GB 250GB...
  • Page 15 copy. If the source device’s data is within the target device’s capacity, the copy will be processed. FAT16/32/64, NTFS, EXT2/EXT3/EXT4, and HFS/HFS+/HFSX are supported in this copy mode. Target Source Duplication Partition1 (150GB) Data 30 GB Partition2 (200GB) 500GB Data 90GB 150GB Unallocated Partition...
  • Page 16 6.1.3 Whole HDD Copies all source data bit by bit. Scroll to select "Whole Device”, then press "OK" to save the copy method. Copies the whole source device, irrespective of content, format, partition, or empty space. This mode does not analyze the data. Target Source Duplication...
  • Page 17 6.2 Copy GPT Backup Area Disabling this function allows the duplicator to copy from big capacity device to small capacity device(s). Note The partition size of the source HDD must be smaller than target capacity. Index Partition Disabling function “Copy GPT Backup Area” will force the duplicator to ignore this area.
  • Page 18 desired language. 6.5 Advanced Setup 6.5.1 Unknown Format This function only works with “6.1 Copy Area >> System and Files.” Scroll to select "6.5.1 Unknown Format”, then press "OK”. Unknown format includes all forms of modified and proprietary data and partitions.
  • Page 19 ❶ One Byte Random character written per byte. Scroll to select "6.5.3 Erase Pattern >> One Byte”, then press "OK” to save this setting. ❷ Big Random Data Random character written in a set of area. Scroll to select "6.5.3 Erase Pattern >> Big Random Data”, then press "OK" to save this setting.
  • Page 20 Scroll to select "Clear Target HPA”, then press "OK" to save this setting. ❷ Setting Target HPA Copies HPA setting from source device to target. Scroll to select "6.5.6 HPA Copy Modes >> Setting Target HPA”, then press "OK" to save this setting. ❸...
  • Page 21 6.5.10 Bytes Per Cmd Set the size of the data transfer between the duplicator and the HDD. The setting value is form 512Byte to 16Mbyte and the default is 512KB. 6.5.11 Delete Disk Signature After Copy Set at “Yes” means do not copy the disk signature part. This function is for Windows only.
