5-7
REMOTE
CONTROL
JACK
(С1-М) INFORMATION
$3 SWITCHES (Switches 1 ~ 10)
The S3 SWITCHES shown above are located on the
LOGICUNIT.
SATELLITE COMMUNICATIONS
be connected to a maximum
of 4 transceivers.
e CT-17 connections
ra] AC outlet
[ur]
=
Personal computer
осоп
6000000
=
1С-475Н
—
Switches 1 ~ 7 (for setting an address with your transceiver):
14H (decimals 20)
Switch 8 (For setting a transceive flag):
The ON position sets a flag used for sending or receiving code data
of
transceive
operations
automatically
when
the
frequency
is
changed or code data are received.
This switch must be OFF when
the CT-16 SATELLITE INTERFACE UNIT is used.
Switches 9 and 10 (For setting CI-V baud rate):
NOTE:
The
standard
1СОМ
CI-V
baud rate is 1200bps.
е Baud rate (Switch 9:OFF, Switch 10:ОМ):
1200bps
-17-
