CHARCOAL BARBECUE
˜ Introduction
We congratulate you on the purchase of your new
product . You have chosen a high quality product .
Familiarise yourself with the product before using it
for the first time . In addition, please carefully refer
to the assembly instructions and the safety advice
below . Only use the product as instructed and only
for the indicated field of application . Keep these
instructions in a safe place . If you pass the product
on to anyone else, please ensure that you also pass
on all the documentation with it .
˜ Intended use
This product is only suitable for cooking foods
suitable for grilling, and is for outdoor use only .
This product is not suitable for commercial use or
for any other use .
˜ Parts description
Lid handle
1 ]
[
Handle bezel
2 ]
[
Lid
3 ]
[
Thermometer
[
4 ]
Upper hinge
[
5 ]
Warming rack
[
6 ]
Cooking grate
[
7 ]
Lower hinge
8 ]
[
Back panel
9 ]
[
Right panel
10 ]
[
Charcoal tray
[
11 ]
Left panel
[
12 ]
Bottle opener
13 ]
[
Lock plate
[
14 ]
Charcoal door handle bezel
[
15 ]
Charcoal door handle
16 ]
[
Charcoal tray crank
[
17 ]
Front panel
18 ]
[
Side shelf front support
[
19 ]
Air vent
[
20 ]
Side shelf
[
21 ]
Side shelf back support
22 ]
[
Side handle bezel
23 ]
[
Side handle
24 ]
[
Left leg
[
25 ]
Ash tray handle
26 ]
[
Ash tray
27 ]
[
Back support
[
28 ]
Bottom rack
[
29 ]
Right leg
[
30 ]
Wheel
31 ]
[
Wheel axle
32 ]
[
Front wheel base cap
33 ]
[
Wheel cover
[
34 ]
Charcoal tray crank connector
[
35 ]
˜ Technical data
Dimensions:
approx .
100 cm × 103 cm × 71 cm
(w × h × d)
Max . capacity
(Fire bowl):
1 .35 kg
Fuel:
charcoal
Note: Only charcoal shall be used .
˜ Scope of delivery
1 Comfortable charcoal grill
1 Assembly material kit
1 Short manual

Safety notices

KEEP ALL SAFETY NOTICES AND
INSTRUCTIONS FOR FUTURE
REFERENCE!
The charcoal grill can only

be operated with charcoal
or charcoal briquettes
in accordance with DIN
EN 1860-2 .
GB/IE/NI/MT/CY
13
