REALTRUCK BAK MX4 TS Installation Sheet

Honda ridgeline 2017+
Hide thumbs Also See for BAK MX4 TS:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

TOOLS REQUIRED
•
Scissors or utility knife
•
Isopropyl alcohol
•
1/2" Wrench or socket
•
Phillips screwdriver
•
5/8" Drill bit & drill
•
T-50 Torx drive
•
3/16" Hex wrench
•
1/8" Allen wrench
PARTS INCLUDED
IN THE BOX
1x Passenger side rail
A
1x Driver side rail
B
1x Hard fold cover
C
1x Bulkhead seal
D
2x Cover retainer clamps
E
6x Clamps
F
2x Buckle ends
G
4x Screws
H
4x Nutserts
I
2x Gaskets
J
2x Drain tubes
K
3x D-shaped cab bumpers
L
1x Driver side mounting rail
M
1x Passenger side mounting rail
N
4x Rail brackets
O
2x Cab brackets
P
4x Tap plates
Q
8x Socket head screws
R
1x Driver side rear bracket
S
1x Passenger side rear bracket
T
1x Driver side rail end corner
U
1x Passenger side rail end corner
V
RealTruck BAK Industries • 1100 N. Glenstone Ave. Suite 140, Springfield, MO 65802 • 818-365-9000 ©RealTruck Group, Inc., 2025
NOTE: It is important that all areas
where the bed cover mounts are clean
and free of debris prior to installing.
C
B
M
N
E
O
P
2017+ HONDA RIDGELINE
MX4 TS
INSTALLATION SHEET
Any damaged or missing parts?
Parts will be shipped to you directly.
Call 818-365-9000 Mon - Fri 8:30 am - 6:00 pm EST
or email support@bakindustries.com
J
H
G
I
E
F
F
G
Q
R
S
A
K
L
D
H
I
T
U
Part# 318S0182 Rev. 1-24-25
J
V
