REALTRUCK BAKFLIP INTERNATIONAL Installation Sheet

TOOLS REQUIRED
•
Scissors or utility knife
•
Isopropyl alcohol
•
1/2" Wrench or socket
•
Phillips screwdriver
•
5/8" Drill bit & drill
PARTS INCLUDED
IN THE BOX
1x Passenger side rail
A
1x Passenger side add-on rail
B
1x Driver side rail
C
1x Driver side add-on rail
D
1x Hard fold cover
E
1x Bulkhead seal
(on select make/models)
F
2x Cover retainer clamps
G
6x Clamps for side rails
H
2x Buckle ends
I
4x Screws
J
4x Nutserts
K
2x Gaskets
L
6x Clamps for add-on rails
M
12x Rubber filler strips
N
2x Drain tubes
O
P 3x D-shaped cab bumper
3x Oversized cab bumpers
Q
1
If a bulkhead seal (F) was
received a bulkhead seal (F) with the cover (E), clean the top of the bulkhead
with soap and water to remove dirt and debris. Clean the area with isopropyl
alcohol to remove wax or grease and to evaporate any remaining water. Allow
the surface to dry. Peel the backing and adhere the seal from one bulkhead edge
to the other. Remove any excess with scissors or a utility knife. Apply pressure
evenly to the entire seal to ensure proper adhesion. If the truck has a drop-in
bedliner, no seal will be needed.
RealTruck BAK Industries • 1100 N. Glenstone Ave. Suite 140, Springfield, MO 65802 • 818-365-9000 ©RealTruck Group, Inc., 2024
NOTE: It is important that all areas
where the bed cover mounts are clean
and free of debris prior to installing.
E
C
D
(3 sets of 3 different sizes included)
(on select make/moels)
(on select make/models)
NOT included in your kit, skip to step 2. If you
BAKFLIP INTERNATIONAL
INSTALLATION SHEET
Any damaged or missing parts?
Parts will be shipped to you directly.
Call 818-365-9000 Mon - Fri 8:30 am - 6:00 pm EST
or email support@bakindustries.com
A
O
I
J
L
K G
F
H
M
J K
B
P
Q
N
G H
L M N
Cab
Part# 318S0161 Rev. 2-5-25
I
