TOOLS REQUIRED
•
Scissors or utility knife
•
Isopropyl alcohol
•
1/2" Wrench or socket
•
Phillips screwdriver
•
5/8" Drill bit & drill
PARTS INCLUDED IN THE BOX
1x Hard fold cover
A
1x Driver side rail
B
1x Passenger side rail
C
1x Bulkhead seal
D
2x Cover retainer clamps
E
6x Clamps
F
2x Buckle ends
G
4x Screws
H
6x Bolts
I
6x T-nut
J
2x Drain tubes
K
Clamp Parts Used With Utili-Track
Installation:
Use the six front of clamps (F) with
six T-nuts (L) and six bolts (K) as
shown to the right.
RealTruck UnderCover • 59 Absolute Dr., Rogersville, MO 65742 • 866-900-8800 ©RealTruck Group, Inc., 2024
NOTE: It is important that all areas
where the bed cover mounts are clean
and free of debris prior to installing.
A
B
Back of Clamp F
Bolt of Clamp F
F
J
J
2004-15 & 16+ NISSAN TITAN
With or Without Utili-Track System
FLEX
INSTALLATION SHEET
Any damaged or missing parts?
Parts will be shipped to you directly.
Call 866-900-8800 Mon - Fri 8:00 am - 5:00 pm CST
or email info@undercoverinfo.com
D
F
E
D
I
J
Clamp Assembly
F
Front of Clamp F
Washer of Clamp F
T-nut
ULTRA FLEX
ARMORFLEX
l
l
C
K
G
H
I
E
F
Clamp Parts Used Without
Utili-Track Installation:
Use the six clamps (F) provided.
Side Rail
F
Bolt
I
J
G
H
K
Part# FX-T4_Install Rev. 6-14-24
