Trek DOMANE+ SLR 2023 Service Manual page 5

Drive unit
1
2
1 Front bolt (75 mm)
2 Rear bolt (62 mm)
3 Compensation screws, T55
Remove the drive unit
Before removing the drive unit from the frame, grab the
connectors and unplug the speed sensor and drive unit
cables.
NOTICE: Unplug the speed sensor by the connector – not
the cable itself – or you may damage the cables.
NOTICE: Do not carry the drive unit by the cables. This can
damage the internal wiring.
5289570
Compensation screws
NOTE: Only adjust the compensation screws if you are
replacing the drive unit.
Before mounting a replacement drive unit, adjust the
compensation screws (tighten or loosen) to match the
frame as shown below.
3
=
2023 Domane SLR+
20Nm
2
20Nm
1
3
4
