TREK
DOMANE DISC
®
SUPPLEMENT TO OWNER'S MANUAL
This supplement gives instructions on
the use and maintenance of the wheel
attachment and braking system on the
Trek Domane Disc bicycle. Please also
read the Trek Bicycle Owner's Manual;
it provides important use and safety
information.
This supplement is written for the owner. If
you need more information, consult your
dealer.
TABLE OF CONTENTS
Condition 1 bicycle ....................................2
Carbon fiber fork .........................................2
Disc brakes ...................................................2
WHEEL ATTACHMENT TYPES
Over-center cam ........................................3
DT RWS ..........................................................3
Optional attachment types .......................3
To install a front wheel ................................4
To install a rear wheel .................................4
® Trek is a registered trademark of the Trek Bicycle
© Copyright Trek Bicycles 2014
This supplement is available in electronic
format at www.trekbikes.com
Denne information er også tilgængelig i
elektronisk format på www.trekbikes.com
Diese Ergänzung gibt es in elektronischer
Fassung zum Download auf www.
trekbikes.com
Este anexo está disponible en formato
electrónico en www.trekbikes.com
Tämä liite on löydettävissä elektronisena
versiona myös osoitteessa www.trekbikes.
com
Ce supplément est disponible au format
électronique sur www.trekbikes.com
Questo materiale integrativo è
disponibile in formato elettronico al sito
www.trekbikes.com
こちらの補足は、 www.trekbikes.comにて電
子版でご確認いただけます
이 추가자료는 www.trekbikes.com 에서
확인할 수 있습니다
Dit document is digitaal beschikbaar op
www.trekbikes.com
Dette tillegget er tilgjengelig elektronisk
på www.trekbikes.com
Ten aneks jest dostępny w formie
elektronicznej na www.trekbikes.com
Esse complemento está disponível em
formato eletrônico em www.trekbikes.
com
Denna info finns tillgänglig i elektroniskt
format via www.trekbikes.com
补充内容的电子版在www.trekbikes.com
网站可以提供下载
Corporation
J
1
Advertisement
Table of Contents
Related Manuals for Trek DOMANE DISC
Summary of Contents for Trek DOMANE DISC
-
Page 1: Table Of Contents
WHEEL INSTALLATION Denna info finns tillgänglig i elektroniskt To install a front wheel ........4 format via www.trekbikes.com To install a rear wheel .........4 补充内容的电子版在www.trekbikes.com 网站可以提供下载 ® Trek is a registered trademark of the Trek Bicycle Corporation © Copyright Trek Bicycles 2014... -
Page 2: Special Features
SPECIAL FEATURES The Domane Disc is a road bike with a unique combination of features: Condition 1, carbon fiber fork, disc brakes, and thru-axles. Before riding this bike, you should familiarize yourself with these features by reading this supplement and the Trek Bicycle Owner’s Manual. -
Page 3: Over-Center Cam
CAUTION: A disc brake and disc get very hot during use and could burn skin. Also, the disc edges can be sharp and could cut skin. Do not touch the disc or disc brake when hot or when the disc turns. FIGURE 3 Closing an over-center cam thru-axle after adjusting... -
Page 4: Dt Rws
DT RWS This type of thru-axle has a handle, not a lever; it is not a quick-release. The axle works like a screw, and the handle works like a wrench to tighten the screw. To secure a wheel: Instead of flipping the lever to close, you simply rotate the handle until fully tight (Figure 4), a minimum of 15 Nm. -
Page 5: Wheel Installation
WHEEL INSTALLATION Be careful not to rub or scrape the fork or frame with the disc. The disc can damage the paint or even remove frame material. TO INSTALL A FRONT WHEEL 1. Remove the thru-axle from the hub (Figure 6). FIGURE 6 Inserting the thru-axle through the fork and hub... -
Page 6: To Install A Rear Wheel
TO INSTALL A REAR WHEEL 1. Remove the thru-axle from the hub (Figure 6). 2. While guiding the disc past the brake pads inside the disc caliper (Figure 7), slide the wheel into the frame from below. 3. With the wheel fully in the frame, pass the axle through the left side of the frame (same side as the disc) and then the hub.
