- Page 1 2FT WALL :: 257-W-2 ASSEMBLY INSTRUCTIONS 503.232.1988 | grand-benedicts.com PAGE 1 of...
-
Page 2: Part List
2FT WALL :: 257-W-2 PART LIST: 1X. CENTER RAIL A 1X. RIGHT UPRIGHT 1X. BOTTOM RAIL 1X. LEFT UPRIGHT 1X. CENTER RAIL B W/LEVELER W/LEVELER 1X. OPEN END WRENCH 24X. HEX BOLT 1/4"-20 X 0.625" 1X. TOP RAIL B 1X. TOP RAIL A FOR HEX BOLT 1/4-20 UNC 503.232.1988 | grand-benedicts.com PAGE 2 of... -
Page 3: Start Here
Orienting Uprights for Astoria Wall System START HERE Figure 1 1. Identify the bottom of the Left and Right uprights by OFFSET locating screw hole for UPRIGHT LIP attaching leveler. This indicates the bottom of these uprights. See Figure 1. 2. - Page 4 2FT WALL :: 257-W-2 STEP 1: COMPLETED FRAME LEFT UPRIGHT TOP RAILS A&B RIGHT UPRIGHT CENTER RAILS A&B PLEASE NOTE, BACK PANEL CHANNEL IS FACING UP BOTTOM RAIL HEX BOLT 1/4"-20 X 0.625" 503.232.1988 | grand-benedicts.com PAGE...
- Page 5 2FT WALL :: 257-W-2 STEP 2: MOUNT WALL CLEATS STEP 3: HANG WALL FRAMES INSTALL CONNECTOR BRACKET AFTER INSERTING BACK PANELS WALL CLEAT 2 FT WALL FRAME BRACKET CONNECTS MULTIPLE FRAMES HANG FRAMES AND APPLY FORCE TO LOCK THEM IN CUT THE CLEATS PLACE.
- Page 6 2FT WALL :: 257-W-2 STEP 3: W/ OPTIONAL CROSS BRACES CROSS BRACES CROSS-BRACES NEED TO BE MOUNTED TO THE INSIDE OF CHAMFERED CORNER COMPLETED WALL MOUNT CROSS BRACES WITH HEX BOLT 1/4"-20 X 0.75" 503.232.1988 | grand-benedicts.com PAGE...
- Page 7 2FT WALL :: 257-W-2 STEP 3: W/ OPTIONAL BACK PANELS Please note, due to a design limitation, cross-braces cannot be used in combination with back panels. This issue will be resolved in the next version. TO INSTALL, SLIDE UP AND THEN DOWN INTO FRAME CORNERS OPTIONAL BACK PANELS COMPLETED WALL...
