ASSEMBLY INSTRUCTIONS - 260 - EC - 4FVSC - ( 4' FULL VISION SHOWCASE )
CAMLOCK (X22)
WOOD DOWEL (X16)
ALU. TOP TRACK (X1)
ALU. TOP CHANNEL (X1)
10" SHELF BRACKET (X3)
C. SIDE PANEL - LEFT (X1)
D. SIDE PANEL - RIGHT (X1)
GRAND + BENEDICTS | 800-547-7005 | www.grand-benedicts.com
PAN CROSS HEAD SELF
FLAT HEAD DRILLING SELF
TAPPING SCREW #8X0.75 (X6)
TAPPING SCREW #8X1.5 (X8)
ALU. BOTTOM CHANNEL (X1)
8" SHELF BRACKET (X3)
E. TOP GLASS (X1)
FLAT HEAD SCREW
HEX NUT M4 (X3)
M4X14 (X3)
STANDARD (X3)
B. TOE KICK (X2)
A. BOTTOM PANEL (X1)
F. 8" GLASS SHELF (X1)
G. 10" GLASS SHELF (X1)
PVC STICKER (X5)
H. FRONT GLASS (X1)
PAGE: 1 OF 6
I. DOOR PANEL (X2)
