Akytec MU210-412 Short Manual

Digital output module
Short guide
1. Overview
MU210-412 is an extension module with 24 digital outputs
The module is equipped with two Ethernet ports for daisy chain
connection. If the module fails or the power is turned off, then data will be
transferred directly from port 1 to port 2 without disconnecting.
The full User Guide is available on the device page at www.akytec.de.
2. Environmental conditions
Table 1 Operating conditions
Permissible range
Condition
Ambient temperature
Transportation and -40...+55 °C
storage
Relative humidity up to 95 % (at +35 °C, non-condencing)
up to 2000 m ASL
Attitude
IP code
Vibration / shock
conforms to IEC 61131-2
resistance
EMC emission /
conforms to IEC 61131-2
immunity
3. Specification
Table 2 General specifications
Parameter
Electrical
Power supply 24 (10 ... 48) V DC
Power consumption 4 W at 24 V DC
Polarity protection
Appliance class
Interfaces
Data transfer Double Ethernet 10/100 Mbps
Modbus TCP, MQTT
Protocols
SNMP, NTP
USB 2.0 (MicroUSB)
Configuration
Ethernet 10/100 Mbps
interface
Digital outputs
Outputs number
Output type
transistor
Low frequency PWM
Control
High frequency PWM
Pulse generator
High-side switch
Output switching
(DO1-DO8)
mode
Output power supply
10...36 V
DC load current, max.
0.15 A
Allowed short-time
0.19 A
output current, max.
MU210-412_3-EN-125426-1.2
© All rights reserved. Subject to technical changes and misprints.
Parameter
Output pulse length,
max.
Output frequency (for
resistive load), max.
Load capacity, max.
Output protection
File size, max.
Number of log files, ,
max.
Logging interval, min.
Accuracy
Backup battery
Dimensions
Weight
IP20
4. Installation and connection
Before installation make sure there is enough free space for connecting
the module and placing the wires.
The module is mounted on a DIN rail or on a vertical surface using
screws.
Installation of external connections is carried out by a wire with a cross
section of not more than 0.75 mm
Value
For stranded wires, use end sleeves.
After installation, lay the wires in the cable channel of the module
housing and close the cover.
If necessary, remove the terminal blocks of the module, loosen the two
Yes
screws at the corners of the terminal blocks.
II
CAUTION
Connection and maintenance is performed only when the
module power and the power to all devices connected to it is
turned off.
Table 3 Ethernet parameters
Parameter
24
IP address
Subnet mask
On-Off
Gateway
DNS server 1 Primary DNS server
DNS server 2 Secondary DNS server
Push-pull switch
(DO9-DO24)
0.4 A
0.6 A
MU210-412
Digital output module
Value
5 μs
1 ms
60 kHz 1 Hz
20 μF at <10 Hz 20 μF
short circuit protection during power on
output overcurrent protection
Flash-memory (log file storage)
2 kB
1000
10 s
Real time clock
±3 s/day at +25 °С
±10 s/day at -40 °С
CR2032
Mechanical
42 × 124 × 83 mm
approx. 600 g
2 .
Description
Default value
IPv4 Internet Protocol address 192.168.1.99
IP address recognition area in
255.255.255.0
the subnet
IP address of the gateway
192.168.1.1
77.88.8.8
8.88.8.8
5. Terminal assignment and Service button
Fig. 1 Terminal assignment
Table 4 Terminal assignments
Marking
DI1...DI24 Input terminals
COM Common input power supply point
+U1 Supply voltage for outputs DO1–DO8
+U2 Supply voltage for outputs DO9–DO16
+U3 Supply voltage for outputs DO17–DO24
The service button can be used for the following functions:
• IP address assignment
• Factory settings restoration
6. Connection diagrams
Ac-
cess
R
R
R
RW
RW
Fig. 2 Device connectors
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany
Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de
Description
