Akytec MU210-402 Short Manual

Digital output module
Short guide
1. Overview
MU210-402 is an extension module with 16 relay outputs.
The module operates as a slave in Ethernet network with Modbus TCP
protocol.
The device is intended for use in industrial automation for creation of
decentralized control systems.
2. Environmental conditions
Table 1 Operating conditions
Permissible range
Condition
Ambient temperature
Transportation and storage
Relative humidity up to 95 % (at +35 °C, non-condencing)
up to 2000 m ASL
Attitude
IP code
Vibration / shock resistance conforms to IEC 61131-2
EMC emission / immunity
conforms to IEC 61131-2
3. Specification
Table 2 General specifications
Parameter
Electrical
Power supply
Power consumption
Polarity protection
Appliance class
Interfaces
Double Ethernet 10/100 Mbps
Data transfer
Modbus TCP, MQTT, SNMP, NTP
Protocols
USB 2.0 (MicroUSB)
Configuration interface
Ethernet 10/100 Mbps
Digital outputs
Outputs number
Output type Relay, NO and changeover
Control
Switching AC 5 A, 250 VAC, resistive load
capacity
DC
Switching current, min.
Switching time
PWM frequency, max. 1 Hz with 0.05 duty cycle
PWM pulse length, min.
Optional functions
3 A, 30 VDC 35,000 switching cycles
Service life,
electrical 5 A, 250 VAC 50,000 switching cycles
Service life, mechanical 5,000,000 switching cycles
Flash-memory (log file storage)
File size, max.
MU210-402_3-EN-61424-2.1
© All rights reserved. Subject to technical changes and misprints.
Number of log files, ,max.
Logging interval, min.
Accuracy
Backup battery
Dimensions
Weight
4. Installation and connection
Before installation make sure there is enough free space for connecting
the module and placing the wires. The module is mounted on a DIN rail
or on a vertical surface using screws.
-40...+55 °C
Installation of external connections is carried out by a wire with a cross
section of not more than 0.75 mm
For stranded wires, use end sleeves.
IP20 After installation, put the wires into the cable channel of the module
housing and close the cover.
If necessary, in order to remove the terminal blocks of the module, loosen
the two screws at the corners of the terminal blocks.
CAUTION
Connection and maintenance is performed only when the
Value
module power and the power to all devices connected to it is
turned off.
24 (10 ... 48) V DC
Table 3 Network parameters
6 W at 24 V DC
Parameter
Yes
IP address
II
Subnet mask
Gateway
DNS server 1
DNS server 2
5. Electrical connection
16
On-Off or PWM
3 A, 30 VDC
10 mA at 5 VDC
15 ms
50 ms
Safe state
2 kB
MU210-402
Digital output module
Parameter Value
1000
10 s
Real time clock
±3 s/day at +25 °С
±10 s/day at -40 °С
CR2032
Mechanical
82 × 124 × 83 mm
approx. 260 g
2 .
Description
IPv4 Internet Protocol address
IP address recognition area in the
subnet
IP address of the gateway
Primary DNS server
Secondary DNS server
Fig. 1 Device connectors
Fig. 2 Front view (open cover)
Table 4 Terminal assignments
Marking
Default value
192.168.1.99
DO1A...DO16A
Relay, NO
255.255.255.0 DO1B...DO16B
DO1A...DO16A
192.168.1.1
Relay,
DO1B...DO16B
77.88.8.8
changeover
DO1C...DO16C
8.88.8.8
Service button performs following functions:
• Factory settings restore
• IP-address assignment
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany
Description
Connection to NO contact
Common output
Connection to a NO contact
Connection to a NC contact
Fig. 3 NO relay wiring
