H-10267
LEATHER BUCKET
CHAIR
TOOL NEEDED
Allen Wrench
(included)
Back Cushion x 1
5-Star Base x 1
Figure 1
Gas Lift
PAGE 1 OF 9
1-800-295-5510
uline.com
PARTS
Seat Plate x 1
Seat Cushion x 1
Armrest x 2
ASSEMBLY
Mechanism x 1
Hex Bolt x 4
5/16 x 3/4"
Caster x 5
1. Turn five-star base upside down and insert casters
into legs. Turn base upright. Insert gas lift into center
of base. (See Figure 1)
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
Gas Lift x 1
Hardware Kit
Hex Bolt x 8
Bolt x 3
1/4 x 15/16"
5/16 x 3/4"
0124 IH-10267
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for U-Line H-10267
Summary of Contents for U-Line H-10267
- Page 1 Para Español, vea páginas 4-6. Pour le français, consulter les pages 7-9. H-10267 1-800-295-5510 uline.com LEATHER BUCKET CHAIR TOOL NEEDED Allen Wrench (included) PARTS Back Cushion x 1 Seat Plate x 1 Seat Cushion x 1 Mechanism x 1 Gas Lift x 1...
- Page 2 ASSEMBLY CONTINUED 2. Remove seat cushion from the seat plate. Align Figure 2 holes in the armrest brackets with holes on the seat 1/4 x 15/16" plate. Connect armrests to seat plate using eight Hex Bolt 1/4 x 15/16" hex bolts. (See Figure 2) NOTE: Use Allen wrench to tightly secure all bolts.
-
Page 3: Chair Adjustments
ASSEMBLY CONTINUED 5. Slowly lower seat onto gas lift. Press down on seat Figure 5 plate to secure. (See Figure 5) 6. Place seat cushion onto seat plate and press down. Figure 6 (See Figure 6) CHAIR ADJUSTMENTS 1. Seat Height – To raise seat height, push lever down with little to no weight on the seat. -
Page 4: Herramienta Necesaria
H-10267 800-295-5510 uline.mx SILLA DE PIEL TIPO BUTACA HERRAMIENTA NECESARIA Llave Allen (incluida) PARTES 1 Respaldo 1 Placa para Asiento 1 Asiento 1 Mecanismo 1 Pistón de Gas Kit de Tornillería 4 Pernos 8 Pernos 3 Pernos 5/16 x 3/4"... - Page 5 CONTINUACIÓN DEL ENSAMBLE 2. Retire el asiento de la placa para asiento. Alinee Diagrama 2 los orificios de los soportes para descansabrazos Perno de con los de la placa para asiento. Conecte los 1/4 x 15/16" descansabrazos a la placa para asiento utilizando ocho pernos de 1/4 x 15/16".
- Page 6 CONTINUACIÓN DEL ENSAMBLE 5. Baje lentamente el asiento sobre el pistón de gas. Diagrama 5 Presione la placa para asiento para asegurarla. (Vea Diagrama 5) 6. Coloque el asiento sobre la placa para asiento y Diagrama 6 presione. (Vea Diagrama 6) AJUSTES DE LA SILLA 1.
-
Page 7: Montage
H-10267 1-800-295-5510 uline.ca FAUTEUIL BAQUET EN CUIR OUTIL REQUIS Clé Allen (inclus) PIÈCES Dossier x 1 Plaque de siège x 1 Siège x 1 Mécanisme x 1 Vérin pneumatique x 1 Matériel de fixation Boulon x 4 Boulon x 8... - Page 8 MONTAGE SUITE 2. Retirez le siège de la plaque de siège. Alignez les Figure 2 trous des supports d'accoudoir sur les trous de la Boulon de plaque de siège. Fixez les accoudoirs à la plaque 1/4 x 15/16 po de siège avec huit boulons de 1/4 x 15/16 po. (Voir Figure 2) REMARQUE : Utilisez la clé...
- Page 9 MONTAGE SUITE 5. Positionnez attentivement l'ensemble du siège sur le Figure 5 vérin pneumatique. Appuyez sur la plaque de siège pour la fixer. (Voir Figure 5) 6. Placez le siège sur la plaque de siège et appuyez Figure 6 dessus. (Voir Figure 6) RÉGLAGES DU FAUTEUIL 1.
