H-10048
DOWNTOWN COLLECTION –
48" ROUND TABLE
TOOLS NEEDED
Allen Wrench
Wrench
(Included)
(Included)
M6 x 65 mm Bolt x 8
Figure 1
M6 x 60 mm Bolt
PAGE 1 OF 6
1-800-295-5510
uline.com
Two Person Assembly
Recommended
PARTS
M6 x 60 mm Bolt x 2
ASSEMBLY
Center Leg
Support Leg
Hex Nut
Pour le français, consulter les pages 5-6.
Hex Nut x 2
NOTE: Assemble unit on a smooth, non-marring
surface to prevent scratching. Check that all
parts are included.
1. Position center leg between support legs. Slide
brackets on support legs over holes in center leg.
Attach using two M6 x 60 mm bolts and two hex
nuts. (See Figure 1)
NOTE: Do not fully tighten bolts until tabletop is
attached to frame.
Para Español, vea páginas 3-4.
Adjustable Glide x 4
0422 IH-10048

Advertisement

loading

Related Manuals for U-Line Downtown H-10048

Summary of Contents for U-Line Downtown H-10048

  • Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-10048 1-800-295-5510 uline.com DOWNTOWN COLLECTION – 48" ROUND TABLE TOOLS NEEDED Two Person Assembly Allen Wrench Wrench Recommended (Included) (Included) PARTS M6 x 65 mm Bolt x 8 M6 x 60 mm Bolt x 2 Hex Nut x 2 Adjustable Glide x 4...
  • Page 2 ASSEMBLY CONTINUED 2. Place tabletop on ground with underside facing Figure 2 up. Flip over assembled frame and align holes on M6 x 65 mm tabletop with holes on frame. Attach using eight Bolt M6 x 65 mm bolts. (See Figure 2) 3.

  • Page 3: Herramientas Necesarias

    H-10048 800-295-5510 uline.mx COLECCIÓN URBANA – MESA REDONDA DE 48" HERRAMIENTAS NECESARIAS Se Recomienda Armar Llave Allen Llave de Tuercas Entre Dos Personas (Incluida) (Incluida) PARTES 8 Pernos M6 x 65 mm 2 Pernos M6 x 60 mm 2 Tuercas 4 Tapas Niveladoras Hexagonales ENSAMBLE...
  • Page 4 CONTINUACIÓN DE ENSAMBLE 2. Coloque la cubierta de la mesa boca abajo con Diagrama 2 el lado inferior hacia arriba. Voltee el armazón ensamblado y alinee los orificios de la superficie de Perno M6 x 65 mm la mesa con los orificios del armazón. Fije utilizando ocho pernos M6 x 65 mm.

  • Page 5: Outils Requis

    H-10048 1-800-295-5510 uline.ca COLLECTION DOWNTOWN – TABLE – 48 PO, ROND OUTILS REQUIS Montage à deux Clé Allen Clé personnes recommandé (inclus) (inclus) PIÈCES Boulon M6 x 65 mm x 8 Boulon M6 x 60 mm x 2 Écrou hexagonal x 2 Patin réglable x 4 MONTAGE REMARQUE : Montez le meuble sur une...
  • Page 6 MONTAGE SUITE 2. Placez la surface de table au sol, face inférieure Figure 2 vers le haut. Tournez le cadre de table à l'envers et Boulon alignez les trous de la surface de table sur ceux du M6 x 65 mm cadre.
