Purelink PS-610 User Manual V1.2
PS-610
5×1 HDMI / USB-C 4K60 Seamless Presentation Switcher
with Dante
USER MANUAL
PureLink™
220-10 State Route 208
Fair Lawn, NJ 07410 USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at support@purelinkav.com.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-610 and is the answer not in the manual?

Questions and answers

Related Manuals for PureLink PS-610

Summary of Contents for PureLink PS-610

  • Page 1 Purelink PS-610 User Manual V1.2 PS-610 5×1 HDMI / USB-C 4K60 Seamless Presentation Switcher with Dante USER MANUAL PureLink™ 220-10 State Route 208 Fair Lawn, NJ 07410 USA Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com For order support, please contact your local dealer.

  • Page 2: Table Of Contents

    Purelink PS-610 User Manual V1.2 Contents Introduction Features What’s in the box Specifications Controls and Functions Transmitter Panel Receiver Panel IR Cable Pin Assignment IR Remote Web GUI User Guide Dante Web GUI User Guide RS-232 Control Command Connection Diagram...

  • Page 3: Introduction

    Purelink PS-610 User Manual V1.2 Introduction The PS-610 is a 6×1 HDMI/USB-C 4K/60Hz Seamless Presentation Switch, featuring versatile input options including USB-C, HDMI,, and Dante™ 2ch audio. Additionally, it offers balanced analog audio embedding and de-embedding capabilities. Any of the five sources connected to the main switch can be output in a Multiview configuration four at a time.

  • Page 4: Specifications

    Purelink PS-610 User Manual V1.2 Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 DP Version DP 1.2 Video Bandwidth 18Gbps TX USB DEVICES to TX HOST/USB-C: 480Mbps RX USB USB Bandwidth DEVICES to TX HOST/USB-C: 350Mbps RX USB DEVICES...
  • Page 5 Purelink PS-610 User Manual V1.2 Audio S/N Ratio 93dB @ 2Vrms, 1kHz A-weighted Audio THD+N <0.1% @ 0dBV, 1kHz Dante Audio Audio Formats LPCM 2.0 Sample Rate 44.1, 48, 88.2 and 96KHz at 24 bits Audio Delay 2ms, 3ms, 4ms, 5ms, 10ms...

  • Page 6: Controls And Functions

    Purelink PS-610 User Manual V1.2 Power Supply Input: AC100 - 240V 50/60Hz Output: DC 24V/8A (US/EU standard, CE/FCC/UL certified) Power Consumption 150W (Max) Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F...

  • Page 7: Rear Panel

    Purelink PS-610 User Manual V1.2 Rear Panel Name Function Description Connect to a router or Switch for USB-C Internet access or Web GUI control. LAN port Press and hold this button for 5 seconds to restore to factory default settings.

  • Page 8: Usb Devices

    Purelink PS-610 User Manual V1.2 Two USB extension ports, connected to mouse, keyboard, USB camera or other USB DEVICES USB devices. ports Receiver Panel Front Panel Name Function Description Power LED When the receiver is powered on, the red power LED will be on.

  • Page 9: Ir Cable Pin Assignment

    Purelink PS-610 User Manual V1.2 RS-232 serial port, used for RS-232 signal pass-through or controlling this receiver via RS-232 RS-232 commands. port Power port, connected to the DC 24V power adapter. DC 24V port Note: The receiver also can be powered by POE (through the HDBaseT IN port).

  • Page 10: Web Gui User Guide

    Purelink PS-610 User Manual V1.2 belongs to the audio input channels of Main In (HDMI/USB-C In). Mute: Press this button to mute / unmute the audio of Master Out. VOL-, VOL+: Press these buttons to increase / decrease the audio output volume of Master Out.
  • Page 11 Purelink PS-610 User Manual V1.2 The default usernames and passwords are as below: Username User Admin Password user admin Select the username “User” and input the password “user”, then click the “Login” button to enter the User page. User Page You can do the following operations on the User page: ①...
  • Page 12 Purelink PS-610 User Manual V1.2 The Information page provides basic information about the model’s name, software version, IP information and the current machine temperature. Besides, you can do the following operations on each page of the admin interface. ① Display and set the audio volume of Master Out. Click the volume icons to increase/ decrease the audio volume of Master Out, or click the mute icon to mute/unmute the audio of Master Out.
  • Page 13 Purelink PS-610 User Manual V1.2 You can set up to 5 preset scenes on the Preset page. ① Preset Name: You can name the preset scene. ② Preset Save: Click the Save button to save the scene. ③ Preset Clear: Click the Clear button to clear the saved scene.
  • Page 14 Purelink PS-610 User Manual V1.2 ② Click the drop-down list to select USB-C 1\USB-C 2\HDMI 3\HDMI 4\HDMI 5\HDMI OUT\ HDBT OUT for EDID download. ③ Click the Download button to download EDID and generate a .bin file. ④ Display the downloaded EDID .bin file.

  • Page 15: Output Setting

    Purelink PS-610 User Manual V1.2 Output Setting ① Resolution: Click the drop-down list to select the output resolution. The output resolution list is as following. Output Resolution No Output Resolution Auto 1920x1080p60 3840x2160p60 10 1920x1080p50 3840x2160p50 11 1360x768p60 4096x2160p60 12 1280x800p60...
  • Page 16 Purelink PS-610 User Manual V1.2 ③ Line Out: Click the drop-down list to select the signal source for Line Out. ④ Dante Out: Click the drop-down list to select the signal source for Dante Out. After setting up, click “Save” to take effect.

  • Page 17: Network Page

    Purelink PS-610 User Manual V1.2 RS-232 Settings ① Local RS-232: You can set the Baud Rate, Data Bit, Parity and Stop Bit for the RS-232 port of the transmitter. ② Remote RS-232: You can set the Baud Rate, Data Bit, Parity and Stop Bit for the RS-232 port of the receiver.
  • Page 18 Purelink PS-610 User Manual V1.2 System Page Display Control ① CEC Command: You can power on/off the CEC command. ② Display Auto Power: You can turn on/off the Display Auto Power. When it is set to ON, you can control the display device power on/off or switch the port based on the power status (power on/standby) or the signal input status of the transmitter by sending serial port or CEC Power On/Off command.

  • Page 19: Dante Web Gui User Guide

    Purelink PS-610 User Manual V1.2 Dante Web GUI User Guide There is a built-in Dante Web GUI for the presentation switch. The operation method is shown as below: Step 1: Connect the presentation switch and PC to the same Ethernet Switch with two Network cables.
  • Page 20 Purelink PS-610 User Manual V1.2 Step 4: Click the Device Info tab to check the IP address of the Dante device. Step 5: Input the IP address of Dante device into your browser on the PC to enter the login interface of the Dante Web GUI.

  • Page 21: Information Page

    Purelink PS-610 User Manual V1.2 Information Page **PHOTO SAYS DEP-MOD-100 The Information page provides basic information about the model name, software version and IP information. Network Page **PHOTO SAYS DEP-MOD-100 On the Network page, you can set the IP Mode (DHCP/Static), IP Address, Subnet Mask, Gateway, Telnet Port, TCP Port and Domain Name.

  • Page 22: Rs-232 Control Command

    Purelink PS-610 User Manual V1.2 You can do the following operations on the System page: ① Account Passwords: You can modify the login password for Admin. After inputting the old password, new password and confirm password, click “Save” to take effect.
  • Page 23 Purelink PS-610 User Manual V1.2 Please refer to the note at the end of the list. r status Get device current status r status MCU 1.1.0 Web 1.1.0 Scaler 20230228-10 r fw version r fw version Get Firmware version FPGA 1.1.0 RX 1.18.02 Power on System Initializing...

  • Page 24: Function Description

    Purelink PS-610 User Manual V1.2 Set input EDID (x=0~5) (y=1~16) x=0: all inputs x=1: USB-C 1 x=2: USB-C 2 x=3: HDMI 3 x=4: HDMI 4 x=5: HDMI 5 y=1: Auto (HDBT or HDMI or HDBT+HDMI) y=2: Copy HDMI OUT y=3: Copy HDBT y=4: 4K2K60_444, Stereo Audio 2.0...
  • Page 25 Purelink PS-610 User Manual V1.2 Set Output Resolution (x=1~15) x=1: Auto x=2: 3840x2160p60 x=3: 3840x2160p50 x=4: 4096x2160p60 x=5: 4096x2160p50 x=6: 3840x2160p30 x=7: 3840x2160p25 Out Resolution: Auto s output res x s output res 1 x=8: 1920x1200p60RB x=9: 1920x1080p60 x=10: 1920x1080p50...
  • Page 26 Purelink PS-610 User Manual V1.2 Set output (x=0~3) audio source from (y=1~3) x=0: all outputs Output HDMI/HDBT (HDMI/HDBT, Line, Dante) Audio: Main In x=1: HDMI/HDBT Out (HDMI/USB-C In) Output s output x audio y s output 0 audio 1 x=2: Line Out...
  • Page 27 Purelink PS-610 User Manual V1.2 Function Description Example Feedback Command Code Default Setting Set master output member (x/y/z=0~1) x=0: Exclude HDMI/HDBT Out s master member x=1: Include HDMI/HDBT Out s master member Master Member: 111 y=0: Exclude Line Out 1 1 1...
  • Page 28 Purelink PS-610 User Manual V1.2 Command Code Function Description Example Feedback Default Setting Get output (x=0~3) audio mute Output HDMI/HDBT on/off Audio Mute: On x=0: all outputs Output Line Audio r output x audio r output 0 audio (HDMI/HDBT, Line, Dante)
  • Page 29 Purelink PS-610 User Manual V1.2 Function Description Example Feedback Command Code Default Setting Set output (x=0~3) audio GEQ to preset (y=1~6) x=0: all outputs (HDMI/HDBT, Line, Dante) Output HDMI/HDBT x=1: HDMI/HDBT Out Audio EQ Preset 1 x=2: Line Out Output Line Audio...
  • Page 30 Purelink PS-610 User Manual V1.2 Set multiview display mode (x=1~5) x=1: Multiview: Single s multiview x s multiview 1 Single x=2: PIP x=3: PBP x=4: Triple x=5: Quad Multiview: Single r multiview Get multiview display mode r multiview Command Code...
  • Page 31 Purelink PS-610 User Manual V1.2 Set triple windows display aspect ratio (x=1~2) Triple Aspect: Full Screen 1 s triple aspect x s triple aspect 1 x=1: Full screen x=2: 16:9 Get triple windows display aspect Triple Aspect: Full Screen r triple aspect...
  • Page 32 Purelink PS-610 User Manual V1.2 Set RX Auto Switch on/off RX Auto Switch: On s rx auto switch x (x=0~1) x=0: Off s rx auto switch 1 x=1: On r rx auto switch Get RX Auto Switch on/off r rx auto switch...
  • Page 33 Purelink PS-610 User Manual V1.2 Set serial port (x=0~2) setting to y x=0: All RS-232 (Local and HDBT) x=1: Local RS-232 x=2: HDBT RS-232 Local RS-232: s serial 0 y= 115200-8n1 115200-8n1 s serial x setting y 115200-8n1 setting Baud rate: 115200/57600/56000/...
  • Page 34 Purelink PS-610 User Manual V1.2 IP Mode: DHCP IP: 192.168.62.106 Subnet Mask: 255.255.255.0 default static IP Gateway: 192.168.62.1 r ipconfig Get the Current IP Configuration r ipconfig TCP/IP port: 8000 192.168.0.100/ Telnet port: 23 255.255.0.0/ MAC: 192.168.0.1 6C:DF:FB:0C:B3:8E (Static: 169.254.100.200 255.255.0.0...
  • Page 35 Purelink PS-610 User Manual V1.2 Set network telnet port s telnet port x s telnet port 23 Telnet port: 23 (x=1~65535) Get network telnet port Telnet port: 23 r telnet port r telnet port Search for IP, Please wait ...! IP Mode: DHCP 192.168.62.106...
  • Page 36 Purelink PS-610 User Manual V1.2 DHCP Gateway SubnetMask 192.168.062.111 192.168.062.001 255.255.000.000 (Static: 192.168.000.100 192.168.000.001 255.255.000.000) ========================================================================================== The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

  • Page 37: Connection Diagram

    Purelink PS-610 User Manual V1.2 Connection Diagram...

  • Page 38: Warranty

    Product or the failure of Product to perform, including incidental or consequential damages. PureLink shall not be liable for any claim made by a third party or made by the purchaser for a third party. Except as expressly set forth in this warranty, PureLink makes no other warranties, expressed or implied, including any implied warranties of merchantability and fitness for a particular purpose.

  • Page 39: Customer Service

    To better enable PureLink to address a warranty claim, please have the Product’s serial and model numbers. If PureLink, in its sole discretion, determines that an on-site visit or other remedial action is necessary, PureLink may send a representative to Customer’s site.
