Cala
DISASSEMBLY & RECYCLING MANUAL
www.stylexdesign.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the CALA and is the answer not in the manual?

Questions and answers

Related Manuals for STYLEX CALA

Summary of Contents for STYLEX CALA

  • Page 1 Cala DISASSEMBLY & RECYCLING MANUAL www.stylexdesign.com...
  • Page 2 Cala DISASSEMBLY & RECYCLING MANUAL PART KEY / SOLID WOOD, WOOD VENEER, LAMINATE, CAESARSTONE PART MATERIAL A. Table Top Solid Wood, Laminate, Wood Veneer, CaesarStone B. Mounting Plate 1-2* Aluminium C. Column 1-2* Steel D. Base Cone 1-2* Aluminium E. Base Plate Steel F.
  • Page 3 Cala DISASSEMBLY & RECYCLING MANUAL PART KEY / METAL TOP PART MATERIAL A. Table Top Solid Wood, Laminate, Wood Veneer, CaesarStone B. Support Plate C. Mounting Plate 1-2* Aluminium D. Column 1-2* Steel E. Base Cone 1-2* Aluminium F. Base Plate Steel G.
  • Page 4 Cala DISASSEMBLY & RECYCLING MANUAL HARDWARE KEY PART MATERIAL H1. 7/16” Steel Hex Head Screw 1-2* Steel H2. Phillips Pan Head Screw 4-8* Steel H3. Phillips Flat Head Screw 4-8* Steel H4. 7/16” Steel Hex Head Screw 1-2* Steel H5. Phillips Flat Head Screw...
  • Page 5 Cala DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: TOP AND MOUNTING PLATE 1. Resting the table on its top (A), locate the phillips panhead 2. With top removed, turn the base upright. Using the base screws (H2) within the mounting plate (B) and remove plate (E) for leverage, slightly loosen (but not remove) the with #3 phillips screwdriver.
  • Page 6 Cala DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: GLIDES AND BASE PLATE 3. To access the glides (F), turn the base over to rest the base 4. While the base is still resting on the mounting plate on the mounting plate (B). Remove the glides (F) using a #2 (B), remove the 4 phillips flat head screws (H3) from phillips screw driver to remove the 3/4”...
  • Page 7 Cala DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: COLUMN AND BASE CONE 5. With the base plate removed, using the 5/8” socket 6. Return to the mounting plate (B) and fully remove the wrench, remove the 7/16” steel hex head screw (H1) 7/16”...
