Anla
DISASSEMBLY & RECYCLING MANUAL
www.stylexdesign.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Anla and is the answer not in the manual?

Questions and answers

Related Manuals for STYLEX Anla

Summary of Contents for STYLEX Anla

  • Page 1 Anla DISASSEMBLY & RECYCLING MANUAL www.stylexdesign.com...
  • Page 2 Anla DISASSEMBLY & RECYCLING MANUAL PART KEY: ARM SEAT PART MATERIAL A. Arm Back GF PP, PU Foam, Dacron, Uph B. Seat GF PP, PU Foam, Steel See Pg. 9 for Disassembly: Seat.
  • Page 3 Anla DISASSEMBLY & RECYCLING MANUAL PART KEY: ARMLESS SEAT PART MATERIAL A. Armless Back GF PP, PU Foam, Dacron, Uph B. Seat GF PP, PU Foam, Steel See Pg. 9 for Disassembly: Seat.
  • Page 4 Anla DISASSEMBLY & RECYCLING MANUAL PART KEY: 4 LEG ALUMINUM BASE PART MATERIAL A. Arm Seat GF PP, PU Foam, Dacron, Uph, Steel B. Aluminum Hub Aluminum C. Aluminum Leg Aluminum D. Aluminum Base Glide Nylon See Pg. 10 for Disassembly: 4 Leg Aluminum Base.
  • Page 5 Anla DISASSEMBLY & RECYCLING MANUAL PART KEY: 4 LEG STEEL BASE PART MATERIAL A. Arm Seat GF PP, PU Foam, Dacron, Uph, Steel B. 4 Leg Steel Base Steel C. Steel Base Glide Nylon See Pg. 11 for Disassembly: 4 Leg Steel Base. Same instructions apply to Lounge Chair.
  • Page 6 Anla DISASSEMBLY & RECYCLING MANUAL PART KEY: SLED BASE PART MATERIAL A. Arm Seat GF PP, PU Foam, Dacron, Uph, Steel B. Sled Base Steel C. Sled Base Glide Nylon See Pg. 12 for Disassembly: Sled Base. Same instructions apply to Counter Stool and Bar...
  • Page 7 Anla DISASSEMBLY & RECYCLING MANUAL PART KEY: 5 BLADE SWIVEL BASE PART MATERIAL A. Arm Seat GF PP, PU Foam, Dacron, Uph, Steel B. Support Plate Aluminum C. Lever Aluminum D. Cylinder Receiver Aluminum E. Cylinder Steel F. 5 Blade Base Aluminum G.
  • Page 8 Anla DISASSEMBLY & RECYCLING MANUAL HARDWARE KEY PART MATERIAL H1. Button Head Screw Steel H2. Locker Washer* 10 or Steel H3. Socket Head Cap Screw Steel H4. Socket Heas Cap Screw Steel H5. Button Head Screw* 4 or 8 Steel H6.
  • Page 9 Anla DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: SEAT A. Using a Phillips screwdriver or driver, remove the screws (6 total) attaching the back to the seat. Arm seat (Left) and Armless seat (Right).
  • Page 10 Anla DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: 4 LEG ALUMINUM BASE Flip the chair over to locate the base. Using a Phillips C. Set the base aside. Using a Phillips screwdriver or driver, screwdriver or driver, remove the screws (4 total) remove the screws (4 total) attaching the legs to the attaching the base to the bottom of the seat.
  • Page 11 Anla DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: 4 LEG STEEL BASE Flip the chair over to locate the base. C. Remove the glides (4 total) located at the bottom of each leg. Set the seat aside. Using a Phillips screwdriver or driver, remove the screws (6 total) attaching the back to the seat.
  • Page 12 Anla DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: SLED BASE Using a Phillips screwdriver or driver, remove the screws C. Remove the glides (4 total) located at the bottom the (4 total) attaching the base to the bottom of the seat. sled.
  • Page 13 Anla DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: 5 BLADE SWIVEL BASE Flip the chair over to locate the base. Using a Phillips C. Using a mallet, firmly hit the support plate until the screwdriver or driver, remove the screws (4 total) cylinder separates from the the support plate.
  • Page 14 Anla DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: 5 BLADE SWIVEL BASE D. Using a Phillips screwdriver or driver, remove the E. Using a mallet, firmly hit the cylinder from beneath until F. Remove casters (5 total) from the bottom of each blade screws (4 total) from the support plate until the level the cylinder separates from the 5 blade base.
