STYLEX Still Screens Assembly Instructions

Still Screens

Assembly Instructions

Parts and Hardware Overview

Tools & Equipment Required

Safety Glasses

3/8" Wrench

3/8" Socket and Ratchet

#2 Phillips Screwdriver, 6" length

1/4" Flat-head Screwdriver

Table or Stands

*2 person assembly requirement

Parts

Base Plate

Hardware

#10-32 Thread x 1/2"

Phillips Flat Head

Base Riser

Leveling Screw

1/4"-20 Thread x 1"

3/8" Hex Head

Base Connector

#10-32 Thread x 5/8"

#10-32 Thread x 7/16"

Phillips Pan Head

Screen Connector

Baseboard End-Cover

Leveling Glide

3/8" Hex Head

Table of Contents

Do you have a question about the Still Screens and is the answer not in the manual?

Page 1 Still Screens Assembly Instructions Parts and Hardware Overview Tools & Equipment Required Safety Glasses 3/8” Wrench 3/8” Socket and Ratchet #2 Phillips Screwdriver, 6” length 1/4” Flat-head Screwdriver Table or Stands *2 person assembly requirement Parts Base Plate Base Riser...
Page 2 Still Screens Assembly Instructions Baseplate Attachment Tools Required Parts Required Safety glasses Base Plate 3/8” Wrench Base Riser 3/8” Socket and Ratchet Base Connector #2 Phillips Screwdriver, 6” length #10-32 Thread x 1/2” Phillips Flat Head Leveling Screw 3/8” Hex Head 1/4”-20 Thread x 1”...
Page 3 Still Screens Assembly Instructions Screen to Screen Assembly Tools Required Parts Required Image A Image B Start assembly at end of run. If corner screens are in the layout, start assembly with a Safety glasses Screen Connector (Pre-Installed) corner screen.
Page 4 Still Screens Assembly Instructions Baseboard Covers Tools Required Parts Required Safety glasses Screen Connector (Pre-Installed) #2 Phillips Screwdriver, 6” length #10-32 Thread x 7/16” Phillips Pan Head Leveling, End-Covers, and Basebaords Once assembled, check that all baseplates and glides are making firm contact with the floor.
