STYLEX Bounce Disassembly And Recycling Document

Model: Bounce
*Refer to P.2 for model variations
Tools Required
safety glasses
hammer
phillips screwdriver
utility knife
Breakdown Steps
1. The arm rests of the chair are plastic
inserts. To remove them, tap them with
a hammer going in the direction away
from the frame. Do this until they pop
loose.
2. Position the chair upside down. Use a
Phillips head screw driver to unscrew
the seat from the frame. There should be
four screws in total.
3. Lift the seat off of the frame to reveal
the seat pan. Use a Phillips head to
unscrew the screws attaching the seat
pan to the frame. There should be four
in total.
4. Remove the upholstery from the seat by
simply unzipping it and stripping it from
the frame. First do the outside lining
then do the same with the tensioned
mesh suspension. Feel free to use a
utility knife to make the work easier.
www.stylexseating.com
Disassembly and Recycling Document
Disassembly Time:10min / No Special Training Required
A
B
C
D
- Tensioned web suspension
- Material: Elastic mesh
- Seat
- Material:
Foam, plastic, upholstery
Foam
-Seat frame
-Material: Steel
- Phillips round-head ( ) x8
bolts and screws
-Material: Steel
-Seat pan
-Material: HDPE plastic
-Arms rests
-Material: Nylon plastic
-Frame structure
-Material: Steel
800.257.5742
P.1
Disassembly Bounce
