- Page 1 Luna DISASSEMBLY & RECYCLING MANUAL www.stylexdesign.com...
- Page 2 Luna DISASSEMBLY & RECYCLING MANUAL PART KEY: ELEVATED PART MATERIAL A. Seat Unit Plywood, PU Foam, Nylon, PET B. Mid Leg Aluminum C. End Leg Aluminum *Depends on unit type...
- Page 3 Luna DISASSEMBLY & RECYCLING MANUAL PART KEY: PLINTH PART MATERIAL A. Seat Unit Plywood, PU Foam, Nylon, PET B. Plinth MDF, Laminate C. Plinth Leg Brackets Aluminum D. Glides Steel, TPU E. Plinth Angle Brackets Steel F. Ganging Receiver Aluminum G.
- Page 4 Luna DISASSEMBLY & RECYCLING MANUAL PART KEY: PLANTER PART MATERIAL A. Liner 1 or 2 Polypropylene B. Planter Flakeboard, Laminate C. Glide Steel, Polypropylene...
- Page 5 Luna DISASSEMBLY & RECYCLING MANUAL PART KEY: ROUND TRAY PART MATERIAL A. Top Steel B. Weldment Steel C. Spacer Plastic...
- Page 6 Luna DISASSEMBLY & RECYCLING MANUAL PART KEY: WIRELESS CHARGING TRAY PART MATERIAL A. Wireless Charging Pad Plastic B. Top Solid Wood C. Backing Plate Steel D. Weldment Steel E. Spacer Plastic...
- Page 7 Luna DISASSEMBLY & RECYCLING MANUAL PART KEY: TABLET ARM PART MATERIAL A. Top Solid Wood B. Top Mounting Plate* Steel C. Swivel Arm* Aluminum D. Upright* Steel *Showing Undermount, Dual Swivel Arm for reference. See pg 14 and pg 15 for more details.
- Page 8 Luna DISASSEMBLY & RECYCLING MANUAL HARDWARE KEY PART MATERIAL H1. Leg Screw* 3 or 6 Steel H2. Wood Screw* Steel H3. Flat Head Screw Steel H4. Nut Steel H5. Flat Head Screw Steel H6. Wood Screw* Steel H7. Flat Head Screw...
- Page 9 Luna DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: SEAT & LEGS A. Flip the seating unit over to locate legs. B. Using a Phillips screwdriver or driver, remove the screws attaching the legs to the bottom of the unit.
- Page 10 Luna DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: SEAT & PLINTH A. Ungang the units from each other and place them on B. Using a Phillips screwdriver, remove all screws their back. Using a Phillips screwdriver or driver, remove connecting. Remove all screws connecting the plinth all screws connecting the ganging bracket to the to the leg brackets.
- Page 11 Luna DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: PLANTER A. Move the planters away from the seating unit. B. Take out the planter liners and recycle them. Dispose the planters and glides.
- Page 12 Luna DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: ROUND TRAY A. Using a 5/32 Allen wrench, remove the 4 screws B. Using a 7/16 Wrench or socket wrench, remove the 4 connecting the round tray to the side of the seat unit.
- Page 13 Luna DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: WIRELESS CHARGING TRAY A. Using a 5/32 Allen wrench, remove the 4 screws B. Flip the wireless charging tray upside down. Using a 5/32 connecting the round tray to the side of the seat unit.
- Page 14 Luna DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: TABLET ARM A. For mid seat mount units, use a 5/32 Allen wrench to B. For undermount units, use a Phillips screwdriver or driver remove the 4 screws connecting the tablet arm to the to remove the 6 screws connecting the tablet arm to the side of the seat unit.
- Page 15 Luna DISASSEMBLY & RECYCLING MANUAL DISASSEMBLY: TABLET ARM A. Using a Phillips screwdriver or driver, remove the B. For single swivel units, flip the remaining assembly C. For dual swivel units, begin by removing the mounting three screws underneath the top.
