Still Screens
Tools & Equipment Required
Safety Glasses
#2 Phillips Screwdriver, 6" length
Wire Ties
Parts & Sub-Assemblies
Receptacle Duplex
Jumper
Hardware
HW1
#8-16 Thread
Phillips #2 Pan Head
Thread Forming Screw for Plastic
Power Assembly Instructions
Parts and Hardware Overview
Receptacle USB
Corded (End) Infeed Sub-Assembly
HW2
#6-19 Thread
Phillips #2 Round Head
Thread Forming Screw for Plastic
General Information
All components should be installed with the "4-TRAC" logo facing
upright.
Power components needs to be installed after all screens in the layout
are fully assembled and adjusted, before installing Baseboards, End
Covers, and End Caps.
Receptacle Bracket
Receptacle Connector
H-Connector
Hanger
Hardwired (Side) Infeed Sub-Assembly
H5
#10-32 Thread x 7/16"
Phillips Pan Head
1
Advertisement
Table of Contents
Related Manuals for STYLEX Still
Summary of Contents for STYLEX Still
- Page 1 Still Screens Power Assembly Instructions Parts and Hardware Overview Tools & Equipment Required General Information Safety Glasses All components should be installed with the “4-TRAC” logo facing upright. #2 Phillips Screwdriver, 6” length Wire Ties Power components needs to be installed after all screens in the layout are fully assembled and adjusted, before installing Baseboards, End Covers, and End Caps.
- Page 2 Still Screens Power Assembly Instructions Receptacles / Jumpers / Splits Tools Required Parts Required General Information Safety glasses Receptacle All components should be installed with the “4-TRAC” logo facing upright. Wire Ties Jumpers Receptacle Bracket (Pre-Installed) Power components needs to be installed after all screens in the layout...
- Page 3 Still Screens Power Assembly Instructions Receptacles / Jumpers / Splits Image E Image F Image G...
- Page 4 Still Screens Power Assembly Instructions Corded Infeed Tools Required Parts Required Safety glasses Corded (End) Infeed Sub-Assembly Wire Ties 3-Pronged Jumper #2 Phillips Screwdriver, 6” length Conduit Clamp Baseboard End-Cover (or Endcap Screen) with Infeed Cutout #10-32 Thread x 7/16” Phillips Pan Head Corded (End) Infeed Assembly and Installation Connect the Corded Infeed to the indicated receptacle.
- Page 5 Still Screens Power Assembly Instructions Hardwired Infeed Tools Required Parts Required Safety glasses Hardwired (Side) Infeed Sub-Assembly Hardwire Body Receptacle #2 Phillips Screwdriver, 6” length Pivot Block x2 Conduit with Clip Baseboard Cover with Receptacle Cutout Hardwire Cover #8-16 Thread Phillips #2 Pan Head Thread Forming Screw for Plastic x4...
- Page 6 Still Screens Power Assembly Instructions Hardwired Infeed Continued Tools Required Parts Required Safety glasses Hardwired (Side) Infeed Sub-Assembly Hardwire Body Receptacle #2 Phillips Screwdriver, 6” length Pivot Block x2 Conduit with Clip Baseboard Cover with Receptacle Cutout Hardwire Cover #8-16 Thread Phillips #2 Pan Head Thread Forming Screw for Plastic x4...
