PART #A223979
INSPECT CONTENTS IMMEDIATELY AND FILE CLAIM WITH DELIVERING CARRIER FOR ANY DAMAGE.
YOU ARE RESPONSIBLE FOR DAMAGE TO YOUR UNIT IF RETURNED IMPROPERLY PACKED.
Step 1 - Mount bottom undershelf.
Attach split sleeves onto #10 groove on 33˝ front posts
and on 74˝ rear posts.
• The wider part of the taper goes toward the bottom.
• Make sure rib on split sleeve is seated into groove on
the post.
Eagle Foodservice Equipment, Eagle MHC, SpecFAB
Carry-Out Worktable
ASSEMBLY INSTRUCTIONS
CAUTION
SAVE YOUR BOX AND ALL PACKING MATERIALS.
11
10
split
sleeves
corner
collar
post
split
sleeve
• 100 Industrial Boulevard, Clayton, Delaware 19938-8903 U.S.A. • www.eaglegrp.com
• Phone: 302/653-3000 • (Foodservice) 800/441-8440 • (MHC/Retail) 800/637-5100
• Fax: 302/653-2065
®
, and Retail Display are divisions of Eagle Group. ©2009 by the Eagle Group
74˝ rear posts
33˝ front posts
bottom
undershelf
split
sleeve
(continued on back page)
EG9862
Revised 07/09
