PART #357998
INSPECT CONTENTS IMMEDIATELY AND FILE CLAIM WITH DELIVERING CARRIER FOR ANY DAMAGE
YOU ARE RESPONSIBLE FOR DAMAGE TO YOUR UNIT IF RETURNED IMPROPERLY PACKED.
#1
#2

Step 1 - Attach bearings to drawer frame.

drawer frame
Eagle Foodservice Equipment, Eagle MHC, SpecFAB, and Retail Display are divisions of Eagle Group. ©2008 by the Eagle Group
Drawers with NSF Slides
ASSEMBLY INSTRUCTIONS
SAVE YOUR BOX AND ALL PACKING MATERIALS.
#3
nut
• 100 Industrial Boulevard, Clayton, Delaware 19938-9905 U.S.A. • www.eaglegrp.com
• Phone: 302/653-3000 • (Foodservice) 800/441-8440 • (MHC/Retail) 800/637-5100
• Fax: 302/653-2065
CAUTION

Parts List

#4
#6
#5
#7

Step 2 - Drop drawer pan into drawer frame.

drawer pan
drawer frame
bolt
bearing
#
qty
description
#1
1
drawer pan
#2
1
drawer frame
#3
1
drawer enclosure
#4
1
pair of slides
#5
8
bolts
#6
8
nuts
#7
8
bearings
(continued on back page)
EG9967
Revised 04/08
.
