Model No. NTL14122.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
REGISTER YOUR
PRODUCT
To register your product and
activate your warranty today, go
to my.nordictrack.com.
MEMBER CARE
For service at any time, go to
my.iFIT.com.
Or call 1-833-680-IFIT
(1-833-680-4348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading

Summary of Contents for iFIT NordicTrack COMMERCIAL 1750

  • Page 1 To register your product and activate your warranty today, go to my.nordictrack.com. MEMBER CARE For service at any time, go to my.iFIT.com. Or call 1-833-680-IFIT (1-833-680-4348) Mon.–Fri. 6 a.m.–6 p.m. MT Sat. 8 a.m.–12 p.m. MT Please do not contact the store. CAUTION...
  • Page 2: Table Of Contents

    Note: The decals may not be shown at actual size. 305284 NORDICTRACK and IFIT are registered trademarks of iFIT Inc. The Bluetooth word mark and logos are regis- ® tered trademarks of Bluetooth SIG, Inc. and are used under license. Google Maps is a trademark of Google LLC.
  • Page 3: Important Precautions

    To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. iFIT assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 19. Read, understand, and test the emergency 26. When folding or moving the treadmill, make stop procedure before using the treadmill sure that the storage latch is holding the (see HOW TO TURN ON THE POWER on frame securely in the storage position. Do page 19).
  • Page 5 STANDARD SERVICE PLANS...
  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new NORDICTRACK reading this manual, please see the front cover of this ® COMMERCIAL 1750 treadmill. The COMMERCIAL manual. To help us assist you, note the product model 1750 treadmill provides an impressive selection of fea- number and serial number before contacting us.
  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
  • Page 8: Assembly

    ASSEMBLY 1. To use the assembly steps in this manual, first see the helpful tips below. • Assembly requires two persons. • To identify small parts, see page 7. • Place all parts in a cleared area and remove the •...
  • Page 9 2. Make sure that the power cord is unplugged. Identify the Right Upright (114), and lay it near the Base (118) as shown. Next, connect the Belly Pan Wire (96) to the Upright Wire (120) in the Right Upright (114). The connectors should slide together eas- ily and snap into place with an audible click.
  • Page 10 4. Do not pinch the Wires (119, 120) during this step. With the help of a second person, hold the handrail assembly (D) on the Left and Right Uprights (113, 114). Attach the handrail assembly with four 3/8" x 2 3/4" Screws (2) and four 3/8"...
  • Page 11 6. Identify the Right Inner Grip (102), and attach it to the right side of the handrail assembly (D) with four #8 x 3/4" Screws (4); start all four Screws, and then tighten them. Do not overtighten the Screws. Attach the Left Inner Grip (101) to the left side of the handrail assembly (D) in the same way.
  • Page 12 8. Have a second person hold the console assembly (I) near the handrail assembly (D). Connect the wires (J) from the console assembly (I) to the wires (K) from the handrail assembly (D). The connectors should slide together easily and snap into place with an audible click.
  • Page 13 10. Rotate the console assembly (I) back to its original position. Firmly tighten the two M6 x 25mm Screws (8) that you attached in step 8. Next, identify the Right Pivot Cover (137). Attach the Right Pivot Cover to the Console Pivot Bracket (138) with an M4 x 20mm Screw (6);...
  • Page 14 12. Note: If the treadmill is assembled on a smooth surface, it may roll forward during this step. Raise the Frame (74) to the position shown. IMPORTANT: Do not raise the Frame past the vertical position. Have a second person hold the Frame until step 14 is completed.
  • Page 15 14. Remove the 5/16" Nut (49) and the 5/16" x 2 1/4" Bolt (27) from the bracket on the Latch Crossbar (76). 49 R Next, align the upper end of the Storage Latch (75) with the bracket on the Latch Crossbar (76), and insert the 5/16"...
  • Page 16 16. See HOW TO CONNECT THE POWER CORD on page 17, and plug in the power cord. Then, see HOW TO USE THE MANUAL MODE on page 21, and adjust the incline of the treadmill to 10%. Next, identify the Right Base Cover (121). Position the large cutout (S) in the Right Base Cover around the Right Upright (114), and slide the Right Base Cover downward onto the Base...
  • Page 17: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD capable of carrying 15 or more amps. To avoid overloading the circuit, do not plug other electrical Use a Surge Suppressor devices, except for low-power devices such as cell phone chargers, into the surge suppressor or into Your treadmill, like other electronic equipment, can be an outlet on the same circuit.
  • Page 18 UPDATE The console features wireless technology that enables display instant exercise feedback. the console to connect to iFIT and provides you with a rotating selection of featured iFIT workouts. Each You can also measure your heart rate when you use workout automatically changes the speed and incline of a compatible heart rate monitor.
  • Page 19 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
  • Page 20 The first time you use Provide your email address, and follow the prompts the treadmill, observe the alignment of the walking on the screen to sign up for or log into your iFIT account. belt, and center the walking belt if necessary (see page 31).
  • Page 21 HOW TO USE THE MANUAL MODE 4. Change the incline of the treadmill as desired. 1. Insert the key into the console. To change the incline of the treadmill, press the Incline increase and decrease buttons or one of the See HOW TO TURN ON THE POWER on page 19.
  • Page 22 (heart symbol). You must be logged into your iFIT account to save a featured workout (see step 3 on page 24). To draw your own map for a workout, see HOW TO CREATE A DRAW-YOUR-OWN-MAP WORKOUT on page 23.
  • Page 23 To select a draw your own map workout, touch ule (see HOW TO USE AN IFIT WORKOUT on Create on the screen. page 24) or adding the workout to your favorites list.
  • Page 24 See step 4 on page 23 for more button (three horizontal lines symbol) on the screen information. and then touch Log in to log in to your iFIT account. Follow the prompts on the screen to enter your 6. Follow your progress.
  • Page 25 HOW TO CHANGE CONSOLE SETTINGS screen. IMPORTANT: Some of the settings and features 6. Create a list of favorite iFIT workouts if desired. described may not be enabled. Occasionally, a firmware update may cause your console to function To mark an iFIT workout as a favorite, simply view slightly differently.
  • Page 26 2. Navigate the settings menus and change The screen will show the progress of the update. settings as desired. When the update is complete, the treadmill will turn off and then turn back on. If it does not, use Slide or flick the screen to scroll upward or down- the power switch (see HOW TO TURN ON THE ward if necessary.
  • Page 27 Note: If you have questions after following and an 802.11b/g/n router with SSID broadcast enabled (hidden networks are not supported). these instructions, go to support.iFIT.com for assistance. When a list of networks appears, touch the desired 5. Exit the wireless network menu.
  • Page 28: Fcc Information

    THE OPTIONAL HEART RATE MONITOR rate during your workouts. The optional heart rate monitor will enable you to continuously monitor your Whether your heart rate while you exercise, helping you to reach your personal fitness goals. To purchase a heart rate goal is to monitor, please see the front cover of this manual.
  • Page 29: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.
  • Page 30: Maintenance And Troubleshooting

    Make sure that the wireless settings on the console are correct (see page 27). b. Make sure that the settings for your wireless net- work are correct. c. If you still have questions, go to support.iFIT.com.
  • Page 31 SYMPTOM: The walking belt slows when walked on c. Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never a. Use only a surge suppressor that meets all of the apply silicone spray or other substances to the walking belt or the walking platform unless specifications described on page 17.
  • Page 32 b. If the walking belt slips when walked on, first SYMPTOM: The displays of the console do not remove the key and UNPLUG THE POWER function properly CORD. Using the hex key, turn both idler roller screws clockwise, 1/4 of a turn. When the walking a.
  • Page 33: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
  • Page 34: Part List

    PART LIST Model No. NTL14122.0 R0122B Key No. Qty. Description Key No. Qty. Description 3/8" x 1 1/4" Screw Clip 3/8" x 2 3/4" Screw M25 Nut Incline Stop Bracket M10 Nut #8 x 3/4" Screw 1/2" Plastic Bushing Ground Screw Fan Screw M4 x 20mm Screw Rear Foot...
  • Page 35 Key No. Qty. Description Key No. Qty. Description Left Inner Grip Console Wire Tie Right Inner Grip Console Base Cover Right Outer Grip Upper Console Cover Right Upright Inner Cover Lower Console Cover Right Inner Console Base Cover Console Back Plate Left Handrail Saddle Bracket Right Handrail...
  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. NTL14122.0 R0122B...
  • Page 37 EXPLODED DRAWING B Model No. NTL14122.0 R0122B...
  • Page 38 EXPLODED DRAWING C Model No. NTL14122.0 R0122B...
  • Page 39 EXPLODED DRAWING D Model No. NTL14122.0 R0122B...
  • Page 40: Ordering Replacement Parts

    (4) if the product is abused or improperly or abnormally used, (5) if the product is modified to alter function- ality or capability without the written permission of iFIT, or (6) if the product is used for commercial or rental purposes.
