INSTALLATION AND OPERATION INSTRUCTIONS FOR
TRV-55-SIG
TS2210055-1
TRV-65-SIG
TS2210065-1
TRV-75-SIG
TS2210075-1
TRV-85-SIG
TS2210085-1
if the information in these instructions are not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss
of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
WARNING: This product can expose you to chemicals including
lead in the wiring, which is [are] known to the State of California
to cause birth defects of other reproductive harm. For more
information visit: www.p65warnings.ca.gov
ELECTRIC FIREPLACE
www.amantii.com
SAFETY INFORMATION
WARNING
01
REVISED - 202504
Advertisement
Table of Contents
Related Manuals for Amantii TRV-55-SIG
Summary of Contents for Amantii TRV-55-SIG
- Page 1 ELECTRIC FIREPLACE www.amantii.com INSTALLATION AND OPERATION INSTRUCTIONS FOR TRV-55-SIG TS2210055-1 TRV-65-SIG TS2210065-1 TRV-75-SIG TS2210075-1 TRV-85-SIG TS2210085-1 SAFETY INFORMATION WARNING if the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Please read and carefully follow all of the instruction found in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii Electric Fireplace. IMPORTANT INSTRUCTIONS CAUTIONS... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS 1. Read all instructions before installing or using this heater. 2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surface. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet from the front, sides and rear of the heater. -
Page 4: Cautions
CAUTIONS Always install the heater in accordance with this guide. If in doubt obtain expert advice. Always make sure the electrical socket is accessible and located adjacent to, but not above the heater. Always disconnect the heater from the electrical supply before moving it, or carrying out cleaning, maintenance. -
Page 5: Fcc Cautions
FCC CAUTIONS This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifcations not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. -
Page 6: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Test all aspects of its operation (manual switches, remote and heater) to make sure all components are operating correctly. As with most electronic devices, your new electric fireplace has been designed to operate at temperatures between 5 ℃(41℉）... -
Page 7: Product Specification
In the absence of local codes, use the current CSA C22.1 Canadian Electrical Code in Canada or the ANSI/NFPA 70 National Electrical Code in the United States. TS2210055-1 TS2210065-1 TS2210075-1 TS2210085-1 Product model TRV-55-SIG TRV-65-SIG TRV-75-SIG TRV-85-SIG Voltage 120V AC 60Hz 240V AC 60Hz... -
Page 8: Hardwire Installation
HARDWIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hardwire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. - Page 9 Connect to 240V 1. Remove the cover plate from the lower right corner on the back of the fireplace by removing the four screws as shown below. Pierce wire grommet with a knife. 2. Attach the wiring to the junction block. Please make sure the live wire goes into the “L”, the neutral wire into “N”...
-
Page 10: Installation
2. To view the flame from different angles, you need to remove panels from different sides. 55 1/4” 13 1/4” 29 5/8” TRV-55-SIG 140.2 cm 33.6 cm 75.2 cm (1). Remove both sides of the fending 65 1/4” 13 1/4”... - Page 11 (3). Remove the fending panel on the right 5. Make an opening for the fireplace side if you want to view the flame from according to requested measurement. front and right side. 3. Screw back the fending bar after the panel is removed.
- Page 12 7. After checking that the fireplace operates properly, cover the glass panels with protective plastic bag and install plywood or drywall. Three angles viewing Front and right side viewing Front and left side viewing 14 1/4” [367mm] 4” 8 3/4” [100mm] [222mm] 12 7/8”...
-
Page 13: Side By Side Installation
SIDE BY SIDE INSTALLATION 1. Unscrew 7 screws on the right side that 4. Unscrew 2 screws and remove the brackets fix the fending bar and panel, and then which are fending the right side glass. take off the fending bar and panel. 5. - Page 14 7. Place fireplace 1 and fireplace 2 on the same level, and place the right side of fireplace 1 close to the left side of fireplace 2. 8. Unscrew the 8 screws at the joint, then remove the 2 framing plates from the fireplace 1 and fix them as the picture shows.
-
Page 15: Media Installation
MEDIA INSTALLATION 4. Remove the left and right side glass and 1. Unscrew 2 screws（The quantity varies take off the brackets. depending on the size of the unit） and remove the bracket which are fending the front glass panel. 5. Remove the Tray Glass. 2. - Page 16 Main PCB N Heater L Heater N Power switch Fireplace grounded Power switch cassette wiring port 8. Insert the tray glass and black glass liners 7. Install the shade cover onto the cassette. back in place. Pour the media into the tray. Feel free to use any combination of the fire glass media that you find most appealing.
-
Page 17: Manual Operation
MANUAL OPERATION The fireplace operates either by the touch panel located on the left front top side of the fireplace or by supplied remote control. Ensure that the ON / OFF Power Switch on the fireplace is in the ON position. Power Switch Of Fan Power Switch Of Fireplace Touch the control panel once to “wakes up”... -
Page 18: Remote Control Operation
REMOTE CONTROL OPERATION For the remote to function make sure the fireplace is plugged in and the ON / OFF Power Switch on the fireplace is in the ON position and the remote has batteries. Important: When operating the remote make sure you point the remote to the center of the fireplace. - Page 19 Each time Speed Button is pressed, the speed of the flame will change. Three options are available: Medium- High- Low. The Moodlight Button turns the moodlight on and off. When in on position, the display screen of the remote control shows AD 1, when the number “1” flash, you can set the color of moodlight with keys.
- Page 20 7 day timer function NOTE: Ensure that the current time setting accurate, otherwise the effective time of the 7 day timer function will be different from what you set. Press the key once, 7 days from Monday to Sunday will display on the LCD screen of the remote control, press key within 5 seconds to enter 7 day timer function .
-
Page 21: Trouble Shooting
TROUBLE SHOOTING Fault code Fault Cause Solution The heater overheating Call after-sales service. NTC is defective. Call after-sales service. If the vents are dirty or clogged. Unplug the power, The heater not working. clean the dust and debris of the vent area. Wait for 5 minutes, plug in and turn on the heater. -
Page 22: Exploded View
EXPLODED VIEW... -
Page 23: Wiring Diagram
WIRING DIAGRAM peripheral unit L1’ EMBER BED LIGHT AC120V XTL:26MHz L2’ ANTENNA peripheral unit WIFI PCB POWER PCB KEY PCB BLUETOOTH PCB ANTENNA XTL:24MHz LOUDSPEAKER peripheral unit L1’ AC240V EMBER BED LIGHT XTL:26MHz L2’ AC120V ANTENNA peripheral unit WIFI PCB POWER PCB KEY PCB BLUETOOTH PCB... -
Page 24: Electric Fireplace Warranty
Should a product or part covered by this limited warranty be proven to be defective, in material or workmanship, and during the two (2) year limited warranty period, Amantii will replace such defective product or part without charge. If Amantii is unable to replace such product, or if replacement is not commercially practicable or cannot be timely done, in its sole discretion Amantii may, in lieu of replacement, choose to refund the purchase price for such product or part. - Page 25 The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty. GENERAL Amantii reserves the right to make changes at any time without notice, in design, material, speci cations, prices and the right to discontinue styles and products. GLASS...
