INSTALLATION AND OPERATION INSTRUCTIONS FOR TRD-26 TRD-30 TRD-33 TRD-38 TRD-44 TRD-48 SAFETY INFORMATION WARNING For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this appliance.
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. Table of Contents IMPORTANT INSTRUCTIONS ..........................
IMPORTANT INSTRUCTIONS 1. Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fire or injury. 2. Keep combustible materials such as furniture, pillows, bedding, clothing, curtains and paper at least 3 ft from the front, sides and rear of the heater.
PLUG INSTALLATION Your power cord will come separate from the unit, please locate it when unpacking your fireplace. The plug contained inside the box is predetermined at the factory and according to orders placed by authorized dealers. Available are UK, European, Swiss & Australian plugs. Should you require any of these options please contact your dealer for purchase.
UNPACKING AND TESTING APPLIANCE NG AND TESTING APPLIANCE Carefully remove the appliance from the box. Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging Prior to installing the appliance, test to make sure the appliance operates properly by plugging Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a 240 Volt grounded outlet.
TRD - 26 Description ELECTRIC FIREPLACE Voltage 120V AC 60Hz 220-240V AC 50-60Hz Watts 1500W Max NO HEATER MOTOR HEATER Appliance Width 27 3/8" or 69.4 cm Appliance Height 16 3/4" or 42.5 cm Appliance Depth 12" or 30.6 cm Gross Weight 50.7 lbs or 22 kgs Plug Location...
TRD - 30 Description ELECTRIC FIREPLACE Voltage 220-240V AC 50-60Hz Watts 1500W Max NO HEATER MOTOR HEATER Appliance Width 31 1/2" or 79.9 cm Appliance Height 19 1/8" or 48.5 cm Appliance Depth 12" or 30.6 cm Gross Weight 50.7 lbs or 22 kgs Plug Location Left side Cord Length...
TRD - 33 Description ELECTRIC FIREPLACE Voltage 220-240V AC 50-60Hz Watts 1500W Max NO HEATER MOTOR HEATER Appliance Width 33 7/8" or 86 cm Appliance Height 21 5/8" or 55 cm Appliance Depth 12" or 30.6 cm Gross Weight 50.7 lbs or 22 kgs Plug Location Left side Cord Length...
TRD - 38 Description ELECTRIC FIREPLACE Voltage 220-240V AC 50-60Hz Watts 1500W Max NO HEATER MOTOR HEATER Appliance Width 39 1/4" or 99.6 cm Appliance Height 27 1/4" or 69.1 cm Appliance Depth 13" or 33.1 cm Gross Weight 50.7 lbs or 22 kgs Plug Location Left side Cord Length...
TRD - 44 Description ELECTRIC FIREPLACE Voltage 220-240V AC 50-60Hz Watts 1500W Max NO HEATER MOTOR HEATER Appliance Width 45 1/4" or 115 cm Appliance Height 31 5/8" or 80.3 cm Appliance Depth 14 3/8" or 36.58 cm Gross Weight 50.7 lbs or 22 kgs Plug Location Left side...
TRD - 48 Description ELECTRIC FIREPLACE Voltage 220-240V AC 50-60Hz Watts 1500W Max NO HEATER MOTOR HEATER Appliance Width 49 1/4" or 115.2 cm Appliance Height 41 5/8" or 105.7 cm Appliance Depth 14 3/8" or 36.6 cm Gross Weight 50.7 lbs or 22 kgs Plug Location Left side...
Page 13
2. When the trim is removed, take off the front glass panel. When the trim is removed, take off the front glass panel. 3. Unscrew the screws located on each screws located on each side and take off the inner side steel panels. side and take off the inner side steel panels.
Page 14
4. Put the trim back onto the appliance and fasten with screws.(NOTE: This step is to make Put the trim back onto the appliance and fasten with screws.(NOTE: This step is to make Put the trim back onto the appliance and fasten with screws.(NOTE: This step is to make sure that the fireplace fits the wall opening well and there is no gap between the trim and the sure that the fireplace fits the wall opening well and there is no gap between the trim and the sure that the fireplace fits the wall opening well and there is no gap between the trim and the...
Page 15
6. Remove the trim following STEP 1. Screw back the inner side steel panels. Remove the trim following STEP 1. Screw back the inner side steel panels. Remove the trim following STEP 1. Screw back the inner side steel panels. 7.
MEDIA OPTIONS Your fireplace ships with a 10 piece Birch Log Set, two (2) bags of Smoke Glass, one (1) bag of Black Vermiculite and one (1) bag of White Vermiculite. SMOKE GLASS VERMICULITE 11-PIECE BIRCH LOG SET MEDIA INSTALLATION Unscrew 4 screws and take off the trim.
OPERATION The fireplace can be operated either by the switches located on the left bottom of the fireplace unit or by supplied remote control. Plug the fireplace into a 15 Amp wall socket. MANUAL OPERATION 1、 Press key . Press for the first time,heater work at 1500W, indicator lights red.
REMOTE CONTROL OPERATION Press the remote control’s key“ ”, its screen turns on, the flame ignites and the flame icon appears on 、 the LCD screen of the remote control. Week, time (24h system), and temperature setting are displayed normally. Press it again, the screen of the remote control will turn off; Key“...
Page 19
7、 Press the heating key“ .” Press for the first time ,the heating elements work at 1500W, the LCD screen displays , the indicator on the machine lights red. Press a second time , the heating elements work at 750W, the LCD screen displays , the indicator on the machine lights blue.
Page 20
for Tuesday. Press for the 7th time and it displays . Press for the 8th time and it exits and recovers to the current week day; 11、Press“ .” Press for the first time and the timing function turns on, the LCD screen displays the machine’s indicator lights green.
CARE AND MAINTENANCE 1. Switch off and unplug from the power supply before cleaning. 2. Using a soft, moist cloth, with or without a mild soap solution, carefully clean the exterior surface of the products. CAUTION: Allow the product to completely cool before handling or cleaning it. 3.
REPLACEMENT PARTS This list contains replacement parts PART NUMBER DESCRIPTION TRD-26 TRD-30 TRD-33 10702245 10702247 10702249 BOTTOM GLASS 10701375 10701376 10701377 FRONT CLEAR GLASS 3215501 3216501 3217501 TRIM SIDE STEEL PANEL 10702244 10702246 10702248 BACK GLASS 301506 REMOTE RECEIVER 601095F...
Page 23
This list contains replacement parts PART NUMBER DESCRIPTION TRD-38 TRD-44 TRD-48 10702251 10701379 10702255 BOTTOM GLASS 10701378 10701379 10701380 FRONT CLEAR GLASS 3218501 3219501 3220501 TRIM SIDE STEEL PANEL 10702250 10702252 10702254 BACK GLASS 301506 REMOTE RECEIVER 601095F CIRCUIT BOARD 602131B BLOWER AND HEATER ASSEMBLY...
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out. Inspect the LED’s and replace them if necessary. Back black cloth is falling off Change a flicker and back black cloth. and rolled up in the flicker. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and...
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:...
