INSTALLATION AND OPERATION INSTRUCTIONS FOR
TRV-45 BESPOKE
TRV-55 BESPOKE
TRV-65 BESPOKE
TRV-75 BESPOKE
TRV-85 BESPOKE
if the information in these instructions are not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss
of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
WARNING: This product can expose you to chemicals including
lead in the wiring, which is [are] known to the State of California
to cause birth defects of other reproductive harm. For more
information visit: www.p65warnings.ca.gov
ELECTRIC FIREPLACE
www.amantii.com
BS2100045-1/EU4
BS2100055-1/EU4
BS2100065-1/EU4
BS2100075-1/EU4
BS2100085-1/EU4
SAFETY INFORMATION
WARNING
01
REVISED - 03/16/23
Advertisement
Table of Contents
Related Manuals for Amantii TRV-45 BESPOKE
Summary of Contents for Amantii TRV-45 BESPOKE
- Page 1 ELECTRIC FIREPLACE www.amantii.com INSTALLATION AND OPERATION INSTRUCTIONS FOR TRV-45 BESPOKE BS2100045-1/EU4 TRV-55 BESPOKE BS2100055-1/EU4 TRV-65 BESPOKE BS2100065-1/EU4 TRV-75 BESPOKE BS2100075-1/EU4 TRV-85 BESPOKE BS2100085-1/EU4 SAFETY INFORMATION WARNING if the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Please read and carefully follow all of the instruction found in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii Electric Fireplace. IMPORTANT INSTRUCTIONS CAUTIONS... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS Please read the following instructions carefully before using the appliance. Caution - Fire, electric shock, physical injury and material damage hazards: To use the appliance, always follow the instructions for assembly, use and maintenance as well as usage cautions: 1. -
Page 4: Cautions
CAUTIONS Always install the heater in accordance with this guide. If in doubt obtain expert advice. Always make sure the electrical socket is accessible and located adjacent to, but not above the heater. Always disconnect the heater from the electrical supply before moving it, or carrying out cleaning, maintenance. -
Page 5: Plug Installation
PLUG INSTALLATION Your power cord will come separate from the unit, please locate it when unpacking your fireplace. The plug contained inside the box is predetermined at the factory and according to orders placed by authorized dealers. Available are UK, European, Swiss & Australian plugs. Should you require any of these options please contact your dealer for purchase. -
Page 6: Product Specification
PRODUCT SPECIFICATION BS2100045-1/EU4 BS2100055-1/EU4 BS2100065-1/EU4 BS2100075-1/EU4 BS2100085-1/EU4 Product model TRV-45 BESPOKE TRV-55 BESPOKE TRV-65 BESPOKE TRV-75 BESPOKE TRV-85 BESPOKE Voltage 220-240V AC 50Hz 1700W-2000W Watts 46 1/8” x 29 3/8” x 15” 56 1/8” x 29 3/8” x 15” 66 1/8” x 29 3/8” x 15”... -
Page 7: Hardwire Installation
HARDWIRE INSTALLATION Turn off the appliance completely and let cool before servicing. Only a qualified service person should service and repair this electric appliance. If it is necessary to hardwire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. -
Page 8: Installation
2. To view the flame from different angles, you need to remove panels from different sides. 45 1/4” 13 1/4” 29 5/8” TRV-45 BESPOKE 114.8 cm 33.6 cm 75.2 cm (1). Remove both sides of the fending 55 1/4” 13 1/4”... - Page 9 (3). Remove the fending panel on the right 5. Make an opening for the fireplace side if you want to view the flame from according to requested measurement. front and right side. 3. Screw back the fending bar after the panel is removed.
- Page 10 7. After checking that the fireplace operates properly, cover the glass panels with protective plastic bag and install plywood or drywall. Three Sided Installation Right Side Open Installation Left Side Open Installation...
-
Page 11: Modular Installation
MODULAR INSTALLATION Unscrew all 7 screws on the right side that 4. Unscrew the 2 screws and remove the hold the fending bar and panel, and then brackets which are fending the right side glass. take off the fending bar and panel. 5. - Page 12 7. Align fireplace 1 and fireplace 2 and place the right side of fireplace 1 close to the left side of fireplace 2 8. Unscrew the 8 screws at the joint, then remove the 2 framing brackets from the fireplace 1 and fix them as shown in the image.
-
Page 13: Media Installation
MEDIA INSTALLATION 3. Installing the fire glass media. Pour the fire glass media into the tray as shown below. Feel free to use any combination of fire 1. Unscrew 3 screws（The quantity varies glass media that you find most appealing. depending on the size of the unit）... -
Page 14: Manual Operation
MANUAL OPERATION The fireplace operates either by the touch panel located on the left front top side of the fireplace or by supplied remote control. Ensure that the ON / OFF Power Switch on the fireplace is in the ON position. Touch the control panel once to “wakes up”... -
Page 15: Remote Control Operation
REMOTE CONTROL OPERATION For the remote to function make sure the fireplace is plugged in and the ON / OFF Power Switch on the fireplace is in the ON position and the remote has batteries. Important: When operating the remote make sure you point the remote to the center of the fireplace. - Page 16 Each time Speed Button is pressed, the speed of the flame will change. Three options are available: Medium- High- Low. The Moodlight Button turns the moodlight on and off. When in on position, the display screen of the remote control shows AD 1, when the number “1” flash, you can set the color of moodlight with keys.
- Page 17 7 day timer function NOTE: Ensure that the current time setting accurate, otherwise the effective time of the 7 day timer function will be different from what you set. Press the key once, 7 days from Monday to Sunday will display on the LCD screen of the remote control, press key within 5 seconds to enter 7 day timer function .
-
Page 18: Trouble Shooting
TROUBLE SHOOTING Fault code Fault Cause Solution The heater overheating Call after-sales service. NTC is defective. Call after-sales service. If the vents are dirty or clogged. Unplug the power, The heater not working. clean the dust and debris of the vent area. Wait for 5 minutes, plug in and turn on the heater. -
Page 19: Replacement Parts
REPLACEMENT PARTS PART NUMBER DESCRIPTION BS2100045-1/EU4 BS2100055-1/EU4 BS2100065-1/EU4 BS2100075-1/EU4 BS2100085-1/EU4 (TRV-45 BESPOKE) (TRV-55 BESPOKE) (TRV-65 BESPOKE) (TRV-75 BESPOKE) (TRV-85 BESPOKE) Trim not applicable Adjustable Screws 40000174 10002786P Front Glass Bracket 10003005P 10003018P 10003012P 10003012P Front Glass 60000261 60000265 60000268 60000271... -
Page 20: Exploded View
EXPLODED VIEW... -
Page 21: Wiring Diagram
WIRING DIAGRAM... -
Page 22: Electric Fireplace Warranty
Should a product or part covered by this limited warranty be proven to be defective, in material or workmanship, and during the two (2) year limited warranty period, Amantii will replace such defective product or part without charge. If Amantii is unable to replace such product, or if replacement is not commercially practicable or cannot be timely done, in its sole discretion Amantii may, in lieu of replacement, choose to refund the purchase price for such product or part. - Page 23 The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty. GENERAL Amantii reserves the right to make changes at any time without notice, in design, material, specifi cations, prices and the right to discontinue styles and products. GLASS...
